Lithonia Lighting CSVT LED Vapor Tight Fixture Switchable

Lithonia Lighting CSVT LED Vapor Tight Fixture Switchable

(No reviews yet) Write a Review

Model: CSVT L96 AL04 MVOLT SWW3

In Stock (leaves warehouse same day if ordered before 3pm ET)

$313.18
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
CSVT LED Vapor Tight Vapor Tight LED Fixture 4 Ft Switchable

  • Features

    • Lightning speed installation right out of the box
    • Wireless, app-free solution to single room lighting control
    • Absolutely no 0-10V control wires and no mobile apps are needed to install and pair JOT enabled products


CSVT L48 AL03 MVOLT SWW3 80 CRI - spec sheet

Manufacturer Resources

Spec Sheet

Product Specs

Environmental Listing:
Wet Location
Series:
CSVT
Cct Led Color:
3 Switchable white, 3500K / 4000K / 5000K
Product Shape:
Rectangular
Dimming Protocol:
0-10V
Regulatory Listing:
CSA
Department:
Electrical
Product Color:
Grey
Compliance Listing:
DLC Standard
Dynamic Feature:
Switchable White
Product Type:
Low Bay
Voltage Rating:
Multi Volt
CRI:
80 CRI
Light Source Type:
LED - Static
Product Subgroup:
Light Fixtures
Product Group:
Lighting

Lithonia Lighting CSVT L96 AL04 MVOLT SWW3 – Frequently Asked Questions

1) Can the Lithonia CSVT vapor tight LED fixture be installed in a wet location like a car wash bay or walk-in cooler?
The CSVT is listed for wet locations, so washdown areas, parking garages, loading docks and cooler rooms are all within its rating. It is also CSA listed, which matters if you are installing in Canada or working to a spec that calls for CSA marking.
2) What lengths does the Lithonia CSVT switchable vapor tight fixture come in?
Two lengths: a 4 ft version, ordered as CSVT L48 AL03 MVOLT SWW3 80 CRI, and an 8 ft version, CSVT L96 AL04 MVOLT SWW3. The 8 ft carries the higher AL04 lumen package. Match the length to your existing strip or vapor tight layout so you are not changing hanger spacing.
3) Do I have to order separate CSVT fixtures for 3500K and 4000K, or is color temperature selectable?
One fixture covers all three. The CSVT is a switchable white product with 3500K, 4000K and 5000K selectable on the unit, so you can stock a single part number and set the color on site. That is useful when a property manager wants 4000K in the back of house and 5000K in a garage without carrying two SKUs.
4) Will the Lithonia CSVT run on 120V and 277V, or do I need to specify the voltage?
Both the 4 ft and 8 ft versions are MVOLT, a multi-volt driver, so there is no voltage suffix to choose at order time. One part number serves mixed-voltage buildings, which is why MRO buyers standardize on it across a campus.
5) Does the CSVT vapor tight fixture dim, and what control wiring does it need?
The driver is 0-10V dimming, so it needs a pair of low-voltage control conductors back to a 0-10V dimmer or control system if you want to dim it. If you are using the JOT wireless pairing feature instead, no 0-10V control wires and no mobile app are required to install and pair.
6) Can the CSVT replace an old 4 ft fluorescent vapor tight without rewiring?
It is an integrated LED fixture, not a lamp holder, so the old ballast and lamps go with the strip. Line voltage lands directly in the fixture and the MVOLT driver accepts whatever the existing circuit is running, so in most one-for-one swaps the branch wiring stays as is. Only the 0-10V control pair is new, and only if you are dimming.
7) Is 80 CRI enough for a warehouse or parking garage, and does the 8 ft CSVT have the same color rendering?
The 4 ft CSVT is specified at 80 CRI, which is the normal commercial grade for warehouse, garage, utility and back-of-house spaces where color critical work is not happening. If you need higher rendering for inspection or retail-facing areas, look at a 90 CRI fixture instead.
