Lithonia Lighting EU2C M6 LED Emergency Light

Lithonia Lighting EU2C M6 LED Emergency Light

(No reviews yet) Write a Review

Model: EU2C HO M6

In Stock (leaves warehouse same day if ordered before 3pm ET)

$80.41
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Lithonia Lighting EU2C M6 LED Emergency Lighting Unit 2W 120-277V Two-Head Wall Mount

Professional LED Emergency Lighting with Dual-Head Design

The Lithonia Lighting EU2C M6 LED Emergency Lighting Unit delivers reliable emergency illumination with its two-head LED design and 120-277V operation. This professional-grade unit features injection-molded thermoplastic housing with snap-fit components for easy installation and maintenance-free 3.6V nickel-cadmium battery providing 90 minutes of emergency power. UL damp location listed for temperatures from 50-104�F, this wall-mount emergency lighting solution meets NFPA 70, NFPA 101, and Life Safety Code requirements.

Professional Features & Benefits

  • Dual LED Design: Two 1-watt LED lamps provide 90 lumens of emergency illumination with 10-year typical lamp life for long-term reliability and reduced maintenance costs.
  • Universal Voltage Operation: 120-277V compatibility with 2W input wattage ensures flexible installation across various electrical systems and reduces inventory requirements.
  • UL Damp Location Listed: Rated for 50-104�F operation with indoor/outdoor environmental capability provides versatile installation options in challenging conditions.
  • Maintenance-Free Battery: 3.6V nickel-cadmium battery delivers 90 minutes of emergency power with integrated test switch and status indicator for simplified compliance testing.
  • Thermoplastic Construction: Injection-molded, flame-retardant, high-impact housing with snap-fit design components ensures durability and easy installation access.
  • Code Compliance: Meets NFPA 70, NFPA 101, and ULCA Title 20 standards plus state-specific Life Safety Code requirements for comprehensive regulatory compliance.
  • 2-Year Warranty: Limited warranty coverage provides professional assurance and long-term value protection for commercial installations.

Technical Specifications

  • Country Of Origin: China
  • Environmental Conditions: Indoor, Outdoor
  • Fixture Type: Emergency Lighting Unit
  • Lamp Type: LED - Static
  • Lumens: 90 LM LM
  • Mounting Method: Surface
  • Product Color: White
  • Product Material: Thermoplastic
  • Product Type: Emergency Lighting Unit
  • Product Wattage: 2 W
  • Voltage Rating: 120-277 V

Professional Applications

  • Hospitality facilities requiring reliable emergency egress lighting
  • Healthcare environments with critical safety lighting needs
  • Educational institutions and office buildings
  • Houses of worship and community centers
  • Commercial buildings with small indoor spaces
  • Banking and financial facilities
  • Retail establishments requiring code-compliant emergency lighting

Why Choose Lithonia Lighting Quality?

Lithonia Lighting delivers professional-grade emergency lighting solutions with UL damp location listing, comprehensive code compliance including NFPA 70 and NFPA 101 standards, and durable thermoplastic construction. The 2-year limited warranty and maintenance-free battery design ensure reliable long-term performance for critical safety applications.

Manufacturer Resources

Spec Sheet

Product Specs

Product Color:
White
Environmental Conditions:
Indoor, Outdoor
Lamp Type:
LED - Static
Product Wattage:
2 W
Department:
Electrical
Product Material:
Thermoplastic
Mounting Method:
Surface
Voltage Rating:
120-277V
Lumens:
90 LM LM
Product Type:
Emergency Light
Product Subgroup:
Emergency & Exit Lighting
Product Group:
Lighting

Lithonia Lighting EU2C HO M6 – Frequently Asked Questions

1) Will the Lithonia EU2C emergency light run on a 277V circuit, or do I need a different model for 120V?
One model covers both. The EU2C M6 is a universal-voltage unit rated 120-277V, so the same part wires to 120V or 277V without a tap change or a separate SKU. Input draw is 2W.
2) What is the difference between the EU2C M6 and the EU2C HO M6?
Output type is the only ordering choice. EU2C M6 is the standard 2W 120-277V unit; EU2C HO M6 is the high-output battery version. Both are the same two-head thermoplastic wall unit, so pick HO where you need more emergency output from a single location.
3) Can this emergency light be mounted outside or in a parking garage?
The EU2C is UL damp location listed and rated for indoor or outdoor environmental conditions, with an operating range of 50 to 104 degrees F. Damp location is not the same as wet location, so it suits covered exterior areas, garages and loading docks, but not spots exposed to direct water or to freezing temperatures below 50 degrees F.
4) What is the difference between the Lithonia EU2C M6 emergency light and the Dual-Lite LZ2?
Both are two-head emergency lighting units that accept a 120/277V input, so either can be wired into the same branch circuit. The difference is the lamp technology: the EU2C M6 uses static LED lamps drawing 2W total, while the Dual-Lite LZ2 is built around 10W halogen lamps. If you are standardizing a building on LED heads to cut lamp replacement and load, the EU2C is the LED choice of the two.
5) I need an emergency unit for a damp garage entry - is the Dual-Lite LZ2 or the Lithonia EU2C the right pick?
The Lithonia EU2C M6 is the one rated for that environment: it is UL damp location listed, rated 50-104 degrees F, and specified for indoor and outdoor conditions with a flame-retardant thermoplastic housing. The Dual-Lite LZ2 is an LZ series emergency light with 10W halogen lamps; use it where you have a conditioned interior location and the halogen heads suit the aiming you need.
6) Is 90 lumens enough coverage, or do I need more units down a corridor?
Two 1-watt LED heads produce 90 lumens total, which is sized for small indoor spaces, offices, classrooms, retail and worship spaces. On a long corridor or a large open floor you space multiple units to hold the required path illumination rather than relying on one head; where you want more output from a single box, order the EU2C HO high-output battery version instead.
7) How does this mount, and will it sit on a standard junction box?
Surface wall mount. The housing is injection-molded thermoplastic with snap-fit components, so the back plate goes to the wall and the cover snaps over the wiring and battery compartment for access later. Mounting method is listed as surface only, not recessed.
8) How do I do the monthly code-required test on this emergency light?
There is an integrated test switch and a status indicator on the unit, so the monthly 30-second functional test is a press-and-hold at the fixture with no tools. The nickel-cadmium battery is maintenance-free, so there is no electrolyte to check.
9) I have Dual-Lite halogen emergency lights in the building. Is the Lithonia EU2C a like-for-like replacement?
They do the same job but with different lamp technology. The Dual-Lite LZ2 is an emergency light using 10W halogen lamps on 120/277V input; the Lithonia EU2C is a 2W LED unit on 120-277V. Both accept the same supply voltages, so the circuit does not change, but the LED unit draws far less and the head appearance will not match existing LZ2 units. If you are matching an existing wall of LZ-series fixtures for appearance, stay with the Dual-Lite LZ2.
10) We are replacing halogen emergency units like the Dual-Lite LZ2 - will the Lithonia EU2C M6 drop into the same spot?
The EU2C M6 is a surface wall-mount unit with a snap-fit injection-molded thermoplastic housing, and it runs on the same 120-277V range the Dual-Lite LZ2 accepts at 120/277V, so the existing feed works. Confirm the new backplate covers the old mounting holes and box location, since the two are different housings. The EU2C puts out 90 lumens from two 1W LED heads rather than the LZ2's 10W halogen lamps, so re-aim the heads to cover the egress path.
11) Which emergency light gives more light output per fixture, the EU2C or the Dual-Lite LZ2?
The EU2C M6 is specified at 90 lumens from its two LED heads at 2W input, which suits small indoor spaces, corridors, and tight egress paths. The Dual-Lite LZ2 uses 10W halogen lamps, a higher-wattage lamp better suited to throwing light down longer runs. For a large open area, do a photometric check on spacing before committing either unit.
12) Do I ever have to change lamps in this unit?
Not on a normal maintenance cycle. The EU2C uses static LED lamps rated for 10-year typical lamp life, which is why it replaces older incandescent and halogen emergency heads that needed periodic lamp swaps.
13) Will this white emergency unit look out of place in a finished lobby?
The EU2C is a white thermoplastic box with two exposed heads, built as a utility egress fixture for corridors, back-of-house and general commercial spaces. In a high-finish lobby most specifiers use a recessed or architectural emergency unit instead, since this one is surface mount only.
