Littelfuse LPSM001 LPSM Series 1-Pole Midget Fuse Holder, 600V, 30A

Littelfuse LPSM001 LPSM Series 1-Pole Midget Fuse Holder, 600V, 30A

(No reviews yet) Write a Review

Model: LPSM001

In Stock (leaves warehouse same day if ordered before 3pm ET)

$37.37
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Littelfuse LPSM001 LPSM Series 1-Pole Midget Fuse Holder, 600V, 30A

The Littelfuse LPSM001 LPSM Series fuse holder is a POWR-SAFE "Dead Front" holder engineered to provide optimum protection to personnel working around live circuits. Sized for Midget fuses in a compact 1-pole configuration, it is rated 600 VAC / 600 VDC at 30A and mounts easily on standard 35mm DIN rail. This LPSM001 model is the non-indicating version; indicating versions of the LPSM Series are also available for applications where blown-fuse identification above 80 volts is required.

Key Features

  • 1-Pole Configuration: Sized for Midget fuses in a single-pole arrangement, rated 600 VAC / 600 VDC at 30A.
  • Dead Front Protection: Meets "Dead Front" requirements to shield personnel from live parts during fuse handling and replacement.
  • DIN Rail Mounting: Mountable on standard 35mm DIN rail for quick, secure installation in panels and enclosures.
  • Tool-Free Fuse Access: Easy installation and removal of fuses, with no special fuse pullers or tools required for routine maintenance.
  • Ventilated Housing: Ventilated design promotes cooler operation under continuous load.
  • Compact Footprint: Compact design conserves valuable space in crowded control panels and enclosures.
  • Non-Indicating Version: This LPSM001 holder is the standard non-indicating configuration; it does not include the blown-fuse indication feature reserved for indicating (ID) versions.

Certifications & Compliance

  • UL Listed for branch circuit protection (Class CC versions only)
  • CSA test report on file (Report 6225-01 007316)
  • China RoHS compliant
  • Backed by manufacturer ICP (Interrupting Capacity) test documentation

Technical Specifications

  • VAC (V): 600
  • VDC (V): 600
  • Ampere Rating (A): 30
  • Indicating: No

Typical Applications

  • Branch Circuit Protection (Class CC Applications)
  • Control Panels and Industrial Enclosures
  • DIN Rail Mounted Electrical Assemblies
  • Commercial and Industrial Electrical Systems
  • Machine Building and OEM Panel Wiring

Why Littelfuse?

Littelfuse POWR-SAFE fuse holders combine dead-front personnel safety, a ventilated housing for cooler operation, and tool-free serviceability to keep Midget fuse protection reliable in demanding panel environments. Rated 600 VAC / 600 VDC at 30A and mountable on 35mm DIN rail, the LPSM Series is supported by manufacturer CSA test reporting, China RoHS documentation, and interrupting-capacity (ICP) test data, giving electrical professionals confidence in code-compliant, low-maintenance fuse protection for branch circuit applications.

Product Specs

Product Type:
Fuse Holder
Voltage Rating:
600V
Amperage Rating:
30A
Configuration:
1-Pole
Standards:
China RoHS
Department:
Electrical
Product Group:
Circuit Protection
Product Subgroup:
Fuse Holders & Blocks

Littelfuse LPSM001 – Frequently Asked Questions

1) What size fuse does the Littelfuse LPSM001 fuse holder take?
The LPSM001 is sized for Midget fuses (13/32 x 1-1/2 inch class), one pole per holder, rated 600 VAC / 600 VDC at 30A. It will not accept Class J, Class R, or ferrule fuses of other body sizes, so confirm the fuse on your drawing is a Midget or Class CC type before ordering.
2) Does the LPSM001 mount on standard DIN rail or does it need panel screws?
It snaps onto standard 35mm DIN rail, which is what most control panels and industrial enclosures already use. No separate mounting plate or screw pattern is involved for that installation method.
3) Will the Littelfuse LPSM001 show me which fuse has blown?
No. The LPSM001 is the non-indicating version of the LPSM Series. If your crew needs blown-fuse identification at the panel, you want an indicating (ID) version of the LPSM Series instead, which provides indication above 80 volts.
4) Is a Midget fuse holder like the LPSM001 acceptable for branch circuit protection?
UL Listing for branch circuit protection applies to Class CC versions only. So if the holder is being used for branch circuit protection in a code-reviewed installation, the fuse and holder combination has to be the Class CC arrangement. Used with a plain Midget fuse, treat it as supplementary protection rather than branch circuit protection.
5) Can electricians change fuses in the LPSM001 without opening up live parts?
That is the point of the POWR-SAFE dead-front construction: live parts stay shielded while the fuse is handled, so maintenance techs are not reaching into an exposed energized clip. Fuse access is tool-free as well, no fuse puller needed for routine replacement.
6) I need three-phase protection. Can I use LPSM001 holders?
The LPSM001 is a single-pole holder, so a three-phase circuit needs three of them, one per phase, mounted side by side on the DIN rail. Other configurations in the LPSM Series cover multi-pole needs if you would rather have one assembled block.
7) Is the LPSM001 rated for DC circuits as well as AC?
Yes, 600 volts on both, AC and DC, at 30 amps. That makes it usable in DC control and drive circuits as well as standard AC panel work, as long as the fuse itself carries a matching DC rating.
8) Will the LPSM001 overheat if the circuit runs at full load continuously?
The housing is ventilated specifically to run cooler under continuous load, which is why these are common in tightly packed OEM panels. Keep the fuse rating inside the holder's 30A ceiling and derate the fuse per the load as you normally would.
9) Does the Littelfuse LPSM001 meet RoHS requirements for export builds?
It is China RoHS compliant, and there is a CSA test report on file (Report 6225-01 007316) plus manufacturer interrupting-capacity test documentation, which is usually what a machine builder's submittal package needs.
10) What exact part number do I order for the non-indicating 30A Midget holder?
Littelfuse LPSM001. That is the manufacturer part number for the single-pole, 600V, 30A non-indicating LPSM Series POWR-SAFE holder.
