Marks USA 195AB Lever Lockset, Entry Function, Heavy-Duty Grade-1, American Lever Design, US26D Satin Chrome Finish
ANSI Function F109 – Turn / push button locking: Pushing and turning inside button locks outside lever, requiring use of key until button is manually unlocked. Pushing button locks outside lever until unlocked with key or inside lever is turned. Inside lever always free for immediate egress.
- High quality, longer lasting, lower maintenance design
- Unique stainless steel “clutch” and bronze bearings dramatically reduce wear and abuse & eliminates lever droop
- Competitively priced for exceptional value
- Exceeds BHMA Grade 1 Spec by 300%, over 3.6 million cycles
- Marks lifetime mechanical warranty
Lock Function
Manufacturer Resources
Product Specs
- Category:
- Mechanical Locks
- Latch Throw:
- 9/16"
- Backset:
- 2-3/4"
- Grade:
- Grade 1
- Product Group:
- Mechanical Locks
- Product Subgroup:
- Bored Locksets
- Product Type:
- Cylindrical Locks
- Subcategory:
- Cylindrical Locks
- ANSI/BHMA:
- ANSI/BHMA, UL Listed
- Commercial/Residential:
- Commercial
- Lock Type:
- Cylindrical
- Strike Type:
- ANSI, 1-1/4" x 4-7/8", 1-1/4" Lip, Square Corner
- Function Description:
- Pushing and turning button on inside locks outside knob/lever requiring use of a key until button is manually unlocked.
- Front Size:
- 1-1/8" x 2-1/4"
- ADA Compliant:
- Yes
- Latch Type:
- Deadlocking
- Function:
- Entrance/Office
- ANSI Function:
- F109
- Product Attribute:
- Cylindrical Locks
