Marks USA 195BHN LifeSaver Passage Lever Lockset - Grade 1 LifeSaver Series, Behavioral Health D-Lig Slide, Passage

Marks USA MAR195BHN 195BHN LifeSaver Behavioral Health Anti-Ligature Passage Lever Lockset — Grade 1, Stainless Steel, Lifetime Warranty

(No reviews yet) Write a Review

Model: 195BHN-32D
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$856.10
$453.05
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Marks USA 195BHN LifeSaver Behavioral Health Anti-Ligature Passage Lever Lockset — Grade 1, Stainless Steel, Lifetime Warranty

The Marks USA 195BHN is part of the LifeSaver Series, a line of ANSI A156.2 Grade 1 institutional life safety locksets engineered specifically for Behavioral Health Care Institutions, X-ray settings, and correctional facilities. Featuring a 5-Point Ligature Resistant D-Lig Slide Trim that meets the BHMA 156.34 Anti-Ligature Trim Standard, this cylindrical passage lockset is constructed entirely of solid cast stainless steel for maximum durability and corrosion resistance. Designed for 1-3/4" door thickness with a standard 2-3/4" backset, it retrofits all popular door preps and constructions, and carries a UL Listed 3-Hour Fire Rating alongside ADA compliance.

Key Features

  • 5-Point Ligature Resistant Slide Trim: D-Lig Slide design meets BHMA 156.34 Anti-Ligature Trim Standard, engineered to reduce self-harm risks in behavioral health and institutional environments.
  • ANSI A156.2 Grade 1 & UL Listed 3-Hour Fire Rating: Certified for the most demanding commercial and institutional applications requiring verified life safety performance.
  • Ergonomic Solid Cast Stainless Steel Slide: Slides down freely in both the locked and unlocked position, providing intuitive operation while maintaining institutional security requirements.
  • Solid Cast Stainless Steel Escutcheon Plate: Through-bolted for superior strength and simplified installation, ensuring long-term structural integrity under heavy use.
  • Marks Stainless Steel Retractor — Long Life: Rated at 3X the BHMA Grade 1 cycle standard for exceptional longevity in high-traffic, high-demand institutional settings.
  • Backset Flexibility: Standard 2-3/4" backset with 2-3/8", 3-3/4", and 5" options available to accommodate a wide range of door preparations.
  • Latch — #1834 Stainless Steel Nose: Deadlocking latch with 1/2" throw and 1-1/8" x 2-1/4" front size for reliable latching performance.
  • Strike — #1135, 4-7/8" ASA Curved Lip: ANSI-compliant 1-1/4" x 4-7/8" square corner strike with 1-1/4" lip for secure door frame engagement.
  • Tamper Resistant Mounting Screws: Deters unauthorized disassembly, critical for correctional and behavioral health security environments.
  • Antimicrobial Finish Available: Optional antimicrobial finish (Code AM) supports hygiene requirements in healthcare and institutional settings.
  • Cylinder Options: Conventional Key-in-Knob cylinder with Marks "C" Keyway, 6-pin with 2 keys; available in IC and all OEM cylinder preps. Marks Hi-Security Cylinder also available.
  • Marks Lifetime Mechanical Warranty: Backed by the Marks USA Lifetime Mechanical Warranty for long-term confidence and protection.

Certifications & Compliance

  • ANSI A156.2 Grade 1
  • UL Listed — 3-Hour Fire Rating
  • BHMA 156.34 Anti-Ligature Trim Standard
  • ANSI/BHMA Certified
  • ADA Compliant
  • Marks USA Lifetime Mechanical Warranty

Technical Specifications

  • Latch Throw: 1/2"
  • Product Group: Mechanical Locks
  • Product Subgroup: Bored Locksets
  • Product Type: Cylindrical Locks
  • Subcategory: Cylindrical Locks
  • ANSI/BHMA: ANSI/BHMA, UL Listed
  • Commercial/Residential: Commercial
  • Function Description: Pushing and turning button on inside locks outside knob/lever requiring use of a key until button is manually unlocked.
  • Front Size: 1-1/8" x 2-1/4"
  • ADA Compliant: Yes
  • Keyed: Yes
  • ANSI Function: F109
  • Product Attribute: Cylindrical Locks
  • Product Function: Entrance/Office
  • Door Thickness Range: 1-3/4"
  • Latch Type Specification: Deadlocking
  • Strike Classification: ANSI, 1-1/4" x 4-7/8", 1-1/4" Lip, Square Corner
  • Product Category: Mechanical Locks
  • Backset (Distance): 2-3/4"
  • Department: Door Hardware

Typical Applications

  • Behavioral Health Care Institutions
  • Correctional Facilities
  • X-Ray and Medical Imaging Settings
  • Psychiatric and Mental Health Wards
  • Healthcare and Hospital Facilities
  • Institutional and Government Buildings
  • High-Security Commercial Environments

Why Marks USA 195BHN LifeSaver?

Marks USA LifeSaver locksets are purpose-built for the most demanding institutional environments, combining solid cast stainless steel construction with a retractor rated at 3X the BHMA Grade 1 cycle standard for unmatched longevity. The 195BHN meets ANSI A156.2 Grade 1, carries a UL Listed 3-Hour Fire Rating, and complies with BHMA 156.34 Anti-Ligature standards — delivering the verified life safety performance and managed liability protection that behavioral health and correctional facilities require.

Manufacturer Resources

Marks USA Product Catalog

Product Specs

Latch Throw:
1/2"
Grade:
Grade 1
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Cylindrical Locks
Subcategory:
Cylindrical Locks
ANSI/BHMA:
ANSI/BHMA, UL Listed
Commercial/Residential:
Commercial
Lock Type:
Cylindrical
Function Description:
Pushing and turning button on inside locks outside knob/lever requiring use of a key until button is manually unlocked.
Front Size:
1-1/8” x 2-1/4”
ADA Compliant:
Yes
Keyed:
Yes
ANSI Function:
F109
Product Attribute:
Cylindrical Locks
Product Function:
Entrance/Office
Door Thickness Range:
1-3/4"
Latch Type Specification:
Deadlocking
Strike Classification:
ANSI, 1-1/4" x 4-7/8", 1-1/4" Lip, Square Corner
Product Category:
Mechanical Locks
Backset (Distance):
2-3/4"
Department:
Door Hardware

Marks USA 195BHN-32D – Frequently Asked Questions

1) Will the Marks USA 195BHN anti-ligature lockset fit a 1-3/4 inch door?
1-3/4 inches is the door thickness the 195BHN LifeSaver lockset is built for, and it is a single-thickness device, so a 1-3/8 inch older interior door or a 2 inch thick door is out. Backset is 2-3/4 inches as standard. If your openings are thinner or thicker, a lock with a range is the answer instead: the Cal-Royal CAL30 passage lockset covers 1-3/8 to 2 inches, and the Dorma C150 covers 1-3/8 to 2-1/4 inches.
2) Can I drop the Marks 195BHN into a door already prepped for a standard cylindrical lock?
Yes on a standard commercial prep. The 195BHN is a cylindrical (bored) lockset with a 2-3/4 inch backset and a 1-1/8 x 2-1/4 inch latch front, and Marks states it retrofits all popular door preps and constructions. It also ships with the #1135 ANSI strike, 1-1/4 x 4-7/8 inch square corner with a 1-1/4 inch lip, which is the same ASA cutout most commercial frames already carry. If the existing lock sits on a 2-3/8 inch backset, Marks lists 2-3/8, 3-3/4 and 5 inch backsets as options.
3) What does the D-Lig slide trim on the Marks LifeSaver 195BHN actually do for a behavioral health unit?
The trim is a 5-point ligature resistant slide rather than a lever or knob, so there is no projecting shape to tie off to. The solid cast stainless slide moves down freely whether the lock is locked or unlocked, which is what lets staff and patients operate the door without a graspable handle. Marks states the trim meets the BHMA 156.34 Anti-Ligature Trim Standard. Mounting screws are tamper resistant to deter disassembly on the unit.
4) Is the Marks 195BHN LifeSaver lockset fire rated for a 3-hour opening?
UL Listed with a 3-hour fire rating, and ANSI A156.2 Grade 1. The latch is deadlocking with a 1/2 inch throw and the lockset is ANSI/BHMA certified and ADA compliant, which covers the usual spec-sheet checkboxes for a corridor or stair door in a hospital or correctional facility.
5) Does the Marks 195BHN lock with a key, or is it a passage set?
It is keyed. The 195BHN is an ANSI F109 function: pushing and turning the button on the inside locks the outside trim, and it stays locked until a key is used or the button is manually released. It takes a conventional key-in-knob cylinder in the Marks C keyway, 6-pin with two keys, and Marks offers it in IC and all OEM cylinder preps plus a Marks Hi-Security cylinder if you are keying it into an existing institutional system.
6) What is a comparable Grade 1 cylindrical lockset for a behavioral health door if the anti-ligature slide trim is not required?
The Marks USA 195BHN carries an ANSI A156.2 Grade 1 rating with a 2-3/4 inch backset and a 1-3/4 inch door thickness, and its distinguishing feature is the 5-point ligature resistant D-Lig slide trim. On a door where standard lever trim is acceptable, the Dorma C150 is a Grade 1 heavy-duty cylindrical lock in entrance/office function, listed for a 1-3/8 inch to 2-1/4 inch door thickness range. The C150 uses a conventional lever rather than a ligature resistant slide, so it suits corridor and office openings rather than patient rooms where ligature resistance is specified.
7) Will the 1/2 inch latch throw on the Marks 195BHN latch into my existing ASA strike?
The #1834 latch throws 1/2 inch and is deadlocking, and it is sized to the 1-1/4 x 4-7/8 inch ANSI square corner strike with a 1-1/4 inch lip that comes with the lock. If your frame is cut for that standard ASA pocket you are fine. Where a frame has a deeper or non-ASA pocket, or the door has settled and the gap has opened up, half an inch of throw does not have much margin, so check the existing strike depth before you reuse it.
8) Should I use an anti-ligature lockset or a standard Grade 1 cylindrical lock on a psychiatric ward door?
On patient-accessible doors in a behavioral health or correctional setting, the ligature resistant trim is the whole point, and a conventional lever lock does not give you that no matter how heavy duty it is. The 195BHN uses a slide trim meeting BHMA 156.34 instead of a lever. For staff-side offices, storage and mechanical rooms in the same building, a standard Grade 1 cylindrical lock is the cheaper right answer, and the Dorma C150 is an entrance/office function Grade 1 that covers 1-3/8 to 2-1/4 inch doors. Where you want keypad access on a staff door instead of keys, the TownSteel XCE-2000 is a Grade 1 electronic cylindrical set for 1-3/4 to 2 inch doors.
9) What alternative suits a patient bathroom door needing privacy rather than the 195BHN entrance function?
The Marks USA 195BHN is an entrance/office function keyed lock. For a privacy opening, the Cal-Royal CAL20 Calypso Series is a Grade 1 extra heavy duty privacy lock in privacy/bed/bath function for 1-3/8 inch to 2 inch doors, the Alarm Lock Trilogy 4100 is a Grade 1 electronic cylindrical lock in privacy/bed/bath function with keypad for 1-5/8 inch to 1-7/8 inch doors, and the Orca Hardware OCL240 is a Grade 2 medium duty privacy cylindrical lockset. None carries the ligature resistant slide trim of the 195BHN, which is the deciding factor on patient-accessible bathroom doors.
10) What is the Grade 1 alternative if the door needs keypad or credential access instead of a key?
The Marks USA 195BHN is a mechanical keyed cylindrical lock with a Marks C keyway cylinder. Where access control is wanted on the same 1-3/4 inch door, the TownSteel XCE-2000 Series is a Grade 1 heavy duty electronic cylindrical lockset with a keypad in classroom function for 1-3/4 inch to 2 inch doors, and the Schlage CO-100 is a Grade 1 heavy duty standalone electronic cylindrical lock in privacy function with keypad and cylinder options for 1-3/4 inch doors. Both replace the key-only operation of the 195BHN with credential entry and use conventional lever trim rather than a ligature resistant slide.
11) Is a keyless pushbutton knob lock an equivalent to the Marks USA 195BHN in a behavioral health setting?
The Marks USA 195BHN uses a solid cast stainless steel ligature resistant slide meeting the BHMA 156.34 anti-ligature trim standard, with ANSI A156.2 Grade 1 and a UL listed 3-hour fire rating. The Lockey 2830 is a mechanical pushbutton keyless knob lock with auto-locking passage function for 1-1/8 inch to 2 inch doors, and the Lockey 1600 is a heavy duty mechanical keyless knob lock with adjustable backset for the same thickness range. Both use knob trim and pushbutton entry, a projecting profile rather than the flush slide trim the 195BHN provides.
12) Does the Marks USA 195BHN accept interchangeable core cylinders, and what are the IC alternatives?
The Marks USA 195BHN ships with a conventional key-in-knob cylinder in the Marks C keyway, 6-pin with two keys, and is available in IC and all OEM cylinder preps, with a Marks Hi-Security cylinder option. Among Grade 1 cylindrical peers, the Alarm Lock Trilogy T2 DL2700 is listed as IC/SFIC compatible, and the BEST 9KZ EZ Series electronic keypad cylindrical lock includes a key override function. A facility standardizing on one small format core should confirm the core format on the order rather than assuming the default.
13) What finish does the Marks 195BHN come in, and can I get an antimicrobial option?
Satin stainless steel, US32D, is the finish it ships in, which matches the solid cast stainless construction of the escutcheon and slide. An antimicrobial finish is offered under code AM for healthcare and behavioral health spaces where infection control drives the hardware spec.
14) How durable is the Marks LifeSaver 195BHN in a high-traffic institutional corridor?
The retractor is stainless steel and rated at 3X the BHMA Grade 1 cycle standard, and the escutcheon plate is solid cast stainless, through-bolted through the door rather than screwed to the face. The whole lockset is solid cast stainless, so corrosion in a wash-down or high-humidity area is not the failure mode it would be on a plated zinc trim.
15) What Grade 1 cylindrical lock supports audit trail or user codes where the 195BHN is mechanical only?
The Marks USA 195BHN is a mechanical Grade 1 cylindrical lock keyed to a Marks C keyway. Where a facility wants code management, the Alarm Lock Trilogy T2 DL2700 is a Grade 1 standalone electronic cylindrical entrance lock with a digital keypad, 100 user codes and IC/SFIC compatibility for 1-5/8 inch to 1-7/8 inch doors, and the Alarm Lock T3 DL3075 is a Grade 1 electronic cylindrical lock with audit trail and keypad access. Both are battery electronic locks with conventional trim rather than ligature resistant slide trim, and the DL2700 thickness range stops short of the 1-3/4 inch doors the 195BHN is built for.
