Marks USA M9900 36 in. Rim Exit Device, Exit Only with Panic Protector End Cap, US10B Oil-Rubbed Dark Bronze

Marks USA M9900 36" Rim Exit Device, Exit Only with Panic Protector End Cap

(No reviews yet) Write a Review

Model: M9900-36-32D
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$476.11
$239.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Marks USA M9900 36" Rim Exit Device, Exit Only with Panic Protector End Cap

The Marks USA M9900 is a Grade 1 rim exit device sized for 36" door widths and 1-3/4" door thickness. It carries ANSI 156.3 (2001) Grade 1 certification and UL Listing for Panic Hardware, making it a code-compliant egress solution for institutional and commercial applications. The device is non-handed, retrofits all popular preps, and features a heavy-duty cast chassis, a reduced-projection touchbar, and a mitered steel Panic Protector End Cap built for high-traffic environments including schools, universities, and commercial buildings.

Key Features

  • 36" Door Width: Sized for standard 3-foot commercial door openings.
  • 1-3/4" Door Thickness: Compatible with the most common commercial door profiles.
  • 3-Hour Fire Rated Dead Latch Bolt: Stainless steel 3/4" throw dead latch bolt carries a 3-hour fire rating, meeting fire code egress requirements.
  • Heavy-Duty Cast Chassis: Heavy gauge extrusion provides structural integrity for high-impact, high-traffic environments.
  • Panic Protector End Cap: Mitered steel flush-mounted end cap resists breakage from cart and equipment impact, extending service life.
  • Reduced-Projection Touchbar: Low-profile touchbar minimizes catch hazards in busy corridors.
  • Non-Handed, Universal Retrofit: Works on single and double doors; retrofits all popular preps for straightforward replacement and upgrade installations.
  • Hex Key Dogging: Holds the latch in the retracted position for high-traffic periods.
  • Marks Lifetime Mechanical Warranty: Backed by Marks USA's Lifetime Mechanical Warranty.

Certifications and Compliance

  • ANSI 156.3 (2001), Grade 1
  • UL Listed for Panic Hardware
  • 3-Hour Fire Rated Dead Latch Bolt

Technical Specifications

  • Product Group: Exit Devices and Trim
  • Product Subgroup: Exit Devices - Rim
  • Product Type: Exit Devices - Rim
  • Product Function: Exit Only
  • Product Size: 36"
  • For Door Thickness: 1-3/4"
  • Dogging Configuration: Hex Key Dogging
  • Standards: ANSI 156.3 (2001), Grade 1; UL Listed for Panic Hardware
  • Application: Schools, Universities and Other Institutional or Commercial Buildings; Retrofits all Popular Preps
  • Features: Marks Lifetime Mechanical Warranty, Easy Installation, Economical, Touchbar
  • Commercial/Residential: Commercial

Typical Applications

  • Schools and K-12 Educational Facilities
  • Universities and Higher Education Campuses
  • Commercial Office Buildings
  • Institutional and Government Buildings
  • Healthcare Facilities and Hospitals
  • Retail Establishments and Shopping Centers
  • Industrial and Warehouse Facilities

Why Marks USA M9900?

The M9900 delivers Grade 1 performance to ANSI 156.3 (2001) standards with UL Listing for Panic Hardware. Its 3-hour fire rated stainless steel dead latch bolt with 3/4" throw and the mitered steel Panic Protector End Cap provide the rugged construction required in high-traffic commercial and institutional environments. Backed by the Marks Lifetime Mechanical Warranty, the M9900 installs easily and retrofits all popular preps.

Manufacturer Resources

Marks USA Product Catalog

Product Specs

Product Group:
Exit Devices and Trim
Product Subgroup:
Exit Devices - Rim
Commercial/Residential:
Commercial
Subcategory:
Exit Devices - Rim
Product Type:
Exit Devices - Rim
Features:
Marks Lifetime Mechanical Warranty, Easy Installation, Economical, Touchbar
Application:
Schools, Universities and Other Institutional or Commercial Buildings and Retrofit all Popular Preps
Standards:
ANSI 156.3 (2001), Grade 1; UL Listed For Panic Hardware
For Door Thickness:
1-3/4"
ADA Compliant:
No
Wood Door Compatible:
No
Product Function:
Exit Only
Product Size:
36"
Dogging Configuration:
Hex Key Dogging
Fire Rating:
No
Product Category:
Exit Devices and Trim
Department:
Door Hardware

Marks USA M9900-36-32D – Frequently Asked Questions

1) Do I need to specify handing for the Marks M9900 exit device?
No handing to specify. The M9900 is non-handed and works on single doors and on double doors, so one part number covers left and right hand openings. That matters if you're standardizing a building: you order the same device for every 36 inch opening instead of tracking swing door by door.
2) Will the M9900 latch into the strike that's already on my frame?
The M9900 uses a stainless steel dead latch bolt with a 3/4 inch throw and retrofits the popular preps, so on a standard rim strike it drops straight in on a replacement job. Measure the throw your existing rim strike is cut for; if it was set up for a 3/4 inch rim latch you are on spec, and a rim device latches into the strike on the frame stop rather than into the door edge.
3) I need a fire rated 36 inch rim exit device. Is the Marks M9900 the right one?
No. The M9900 is not a fire rated device, so it does not belong on a fire rated opening. For a fire rated rim device at 36 inches, the Orca Hardware OED85 Series is a 36 inch exit only fire rated rim device. The Dexter ED1000 Series is also offered in a Grade 1 fire rated rim version, and the Arrow FS1250 is a fire rated rim device in a 32 inch size for a 1-3/4 inch door.
4) Is a concealed vertical rod exit device a substitute for the Marks USA M9900 rim device?
No - they latch into different points and take different door prep. The M9900 is a rim device whose 3/4 inch dead latch bolt engages a strike on the door frame at the latch case. The Hager 4501 is a Grade 1 36 inch concealed vertical rod device with a wide stile pushpad and the Hager 4601 is the Grade 1 36 inch narrow stile concealed vertical rod version; both latch at the head and sill through rods concealed inside the door, which requires a door prepped for that hardware. A concealed vertical rod device is used where a pair of doors needs to latch without a mullion; a rim device on a pair normally works against a removable mullion.
5) The Marks USA M9900 is exit only - which rim exit devices accept outside trim or a night latch function?
The M9900 is an exit only device, meaning there is no outside operating trim. When the opening needs outside entry, the Corbin Russwin ED5200 is a Grade 1 36 inch wide stile rim device listed as exit only and accepts trim, and the Corbin Russwin ED4200 is the Grade 1 36 inch narrow stile equivalent that also accepts trim. The Sargent 8504 is a Grade 1 narrow design rim device in a night latch function, and the Detex V4003A/03AN is a Grade 1 wide stile rim device with night latch trim. Night latch trim gives key retraction of the latch from the outside while the inside stays free egress.
6) The opening is a narrow stile aluminum storefront door - what rim exit device should be used instead of the Marks USA M9900?
The M9900 is built as a touchbar rim device for 36 inch commercial openings and is not a narrow stile device. For an aluminum storefront stile, the TownSteel ED3700 and ED8900 are both 36 inch Grade 1 narrow stile rim exit devices, and the Falcon 19-R-EO is a Grade 1 narrow stile rim device, exit only, at 36 inch for 1-3/4 inch doors. Adams Rite also builds narrow stile rim devices in the 8700 and 8800 Series, both Grade 1, with the 8800 rated for 1-3/4 inch to 2-1/4 inch door thickness. Narrow stile devices are dimensioned to fit the reduced door stile of a glass front entrance, which is the deciding factor on a storefront opening.
7) Can an SDC pressure sense bar or switch bar be used in place of the Marks USA M9900 rim exit device?
They are not the same class of hardware. The M9900 is a mechanical rim exit device with a 3/4 inch throw dead latch bolt that latches into a rim strike. The SDC MSB550 36 inch mechanical switch bar and the SDC SureExit PSB560 36 inch pressure sense bar release an electromagnetic lock rather than throwing a latch of their own, and both are built to fit narrow or wide stile doors. The Securitron EMB is likewise an electromechanical exit bar. Those are the right answer only when the opening is secured by a maglock or an access control system; on a door that needs its own latching, the mechanical rim device is what the opening requires.
8) What is the closest Grade 1 alternative to the Marks USA M9900 36 inch rim exit device on a wide stile aluminum or hollow metal door?
The Von Duprin 22-3FT is a Grade 1 wide stile pushpad rim exit device sized for 36 inch doors, non-handed, for 1-3/4 inch door thickness - the same width, thickness and non-handed setup the M9900 covers. The Corbin Russwin ED2200-WO36 is another Grade 1 wide stile rim device in a 36 inch exit only configuration, and the TownSteel ED1100 covers 36 inch wide stile in a heavy duty Grade 1 build. All three are touchbar or pushpad rim devices mounted on the door face with a surface strike, so the door prep logic matches what the M9900 uses.
9) Which rim exit devices carry a fire rating if the Marks USA M9900 does not suit a fire rated opening?
For a labeled fire door assembly, the Dexter ED1000-R-F-EO is a Grade 1 fire rated rim exit device, the Orca OED85 is a 36 inch fire rated rim device in an exit only function, the Arrow FS1250 is a fire rated 32 inch rim device for 1-3/4 inch doors, and the Adams Rite 3700 Series is a Grade 1 fire rated narrow stile rim device. Fire rated exit devices omit dogging, since the latch must never be held retracted on a fire door - a difference worth confirming against the M9900, which uses hex key dogging.
10) Is a Cal-Royal A9800 or 5000 rim exit device the same performance level as the Marks USA M9900?
They are not the same certification level. The M9900 is certified to ANSI 156.3 (2001) Grade 1 and UL Listed for Panic Hardware. The Cal-Royal A9800 36 inch rim device and the Cal-Royal 5000 36 inch touch bar rim device are both catalogued as Grade 2 heavy duty, as is the Cal-Royal 5500 48 inch push bar device. Where a specification calls out ANSI Grade 1 exit hardware, a Grade 2 device will not satisfy it, so confirm the grade the drawing requires before substituting.
11) What rim exit device covers a 48 inch door leaf when the Marks USA M9900 is sized for a 36 inch opening?
The M9900 is sized to 36 inch door widths. For a wider leaf, the Corbin Russwin ED3200 is a Grade 1 48 inch crossbar rim device for 1-3/4 inch doors, the Dormakaba 9300A is a Grade 1 heavy duty 48 inch wide stile rim device in exit only function for 1-3/4 inch to 2-1/4 inch doors, and the Sargent 2828 and 3828 are Grade 1 reversible wide stile rim devices for 48 inch doors in an exit only function. The Dexter ED1000-R-EO-4FT covers the same 4 foot width in a Grade 1 rim device. Exit device length is matched to the door leaf width, so this is the dimension to confirm before ordering.
12) Which 36 inch rim exit device should be specified when the opening needs electrified access control rather than the mechanical Marks USA M9900?
The M9900 is a mechanical exit only device with no electrical option. For an access controlled opening, the SDC S6136 Spectra S6000 Series is a 36 inch electrified architectural rim exit device with a 4 inch wide stile, for 1-3/4 inch to 2 inch doors. The Dormakaba E2103 is a 36 inch electrified rim exit device supplied with 4908A trim in a classroom function. The Sargent 12-8810-LTRIM is a Grade 1 fire rated wide stile rim device with request to exit switching and motorized electric latch retraction. Electrified devices need a power transfer at the hinge edge and a power supply, which the mechanical M9900 does not.
13) Can I hold the M9900 unlocked during the school day?
Yes, the M9900 has hex key dogging. Insert the hex key and the touchbar holds the latch retracted, so the door pushes open freely through arrival, lunch, or dismissal, then you dog it back down to relatch. You need the hex key on hand, this is not a keyed cylinder dogging setup. Note that dogging is only permitted on non fire rated openings.
14) What's the difference between the Marks M9900 and the Von Duprin 22 Series?
Both are 36 inch non-handed Grade 1 rim exit devices for a 1-3/4 inch door, and neither is fire rated, so they cover the same opening. The M9900 differentiates on the end cap: a mitered steel Panic Protector flush-mounted cap that resists breakage from cart and equipment impact, plus a reduced-projection touchbar to cut catch hazards in a busy corridor. The Von Duprin 22 is a wide stile pushpad device, so it needs the stile width a pushpad chassis requires.
15) Which exit device holds up best where carts and equipment hit the doors?
Cart damage on an exit device almost always starts at the end cap. The M9900 answers that with a mitered steel Panic Protector end cap mounted flush so there is no lip for a cart corner to catch, over a heavy-duty cast chassis in heavy gauge extrusion. That is why it gets specified in schools, universities, hospitals, and warehouses. Same idea if you want an alternative: the Detex 10 Advantex Series 36 inch is an extra heavy duty Grade 1 wide stile rim device.
16) My doors are 48 inches wide. Can I still use the Marks M9900?
No, the M9900 is a 36 inch device and an exit device has to be sized to the door leaf. For a 48 inch leaf, the Cal-Royal A9820 Series is a 48 inch exit only rim device and the CRL Jackson 1095 Series is a 48 inch crossbar rim panic device, exit only. The Dormakaba DORMA 9300 Series is a 48 inch Grade 1 heavy duty wide stile rim device covering 1-3/4 inch to 2-1/4 inch doors.
17) Which rim exit devices also use hex key dogging like the Marks USA M9900?
The M9900 uses hex key dogging to hold the latch retracted during high traffic periods. The Design Hardware 1000R is a 33 inch heavy duty rim device with hex key dogging, the Design Hardware 2000R is the standard duty wide stile version at the same 33 inch length with hex key dogging, and the Stanley Security QED200 Series is a Grade 1 heavy duty narrow stile rim device with hex key dogging. Hex key dogging means the maintenance staff needs an Allen wrench rather than a keyed cylinder dogging cylinder, which matters when standardizing tools across a building.
18) What rim exit device stands up better than the Marks USA M9900 in an extreme abuse opening like a stadium or a loading dock?
The M9900 is built for high-traffic institutional and commercial use with a heavy-duty cast chassis and a mitered steel Panic Protector End Cap that resists cart and equipment impact. Where the specification calls for a step above heavy duty, the Detex 10 Advantex Series 36 inch wide stile device is rated extra heavy duty at Grade 1, and the Detex 40 Advantex is the extra heavy duty Grade 1 narrow stile version. Detex also builds an Advantex 00 Series Grade 1 wide stile dummy device for the inactive leaf of a pair, which matches the look without latching.
19) Is there a crossbar or paddle style rim panic device instead of the touchbar on the Marks USA M9900?
Yes, the actuator style differs across rim panic devices. The M9900 uses a reduced-projection touchbar. The CRL Jackson 1095 Series is a 48 inch crossbar rim panic device in a wide stile exit only configuration, and the CRL Jackson 1095P is the paddle version of that same wide stile exit only device. The CRL Jackson 1295 Series is a non-handed push pad wide stile rim panic device for 1-3/4 inch doors. Crossbar devices project further from the door face than a touchbar, which is the trade-off in a tight corridor.
20) What are the simpler Grade 1 rim exit device options at 36 inches besides the Marks USA M9900?
For a straightforward 36 inch Grade 1 rim device without added features, the Hager 4701 is a standard duty 36 inch rim device with Grade 1 BHMA certification, the Dexter ED1000-R-EO-3FT is a Grade 1 rim device at 3 foot, the Imperial USA ED-501 is a Grade 1 36 inch wide stile rim panic device in exit only function, and the Falcon Monarch 18 Series is a Grade 1 36 inch rim device. The Orca OED55 is a 36 inch rim device in exit only function. Each covers the same 36 inch exit only application the M9900 addresses; the difference is the feature set on the bar rather than the opening it fits.
21) What finishes does the Marks USA M9900 come in?
Two finishes: US32D satin stainless steel and US10B oil-rubbed dark bronze. US32D is the usual pick when you're matching existing institutional hardware across a building, since most commercial exit devices, hinges, and closers are specified in it. US10B is the darker option for openings where the rest of the hardware is bronze.
22) Is the Marks M9900 rated for residential use?
The M9900 is commercial hardware only. It is a Grade 1 panic device built for institutional traffic, and panic hardware belongs on required egress doors in commercial and institutional buildings, not on a house or an apartment unit door. Property managers do use it on common-area and stairwell egress doors in multi-family buildings, which is a commercial application.
