Medeco Medeco 2020097 - 6 Pin Knob Cylinder for Schlage S Series MED-2020097

Medeco 2020097 6-Pin Key-in-Knob Cylinder for Schlage S Series

(No reviews yet) Write a Review

Model: 2020097T-06-DLT
$179.00
$149.95
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$179.00
$149.95
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Medeco 2020097 6-Pin Key-in-Knob Cylinder for Schlage S Series

The Medeco 2020097 is a 6-pin Key-in-Knob/Lever retrofit cylinder engineered to replace cylinders in knob-type cylindrical locksets, lever-type cylindrical locksets, padlocks, and bored-type auxiliary deadlatches and deadlocks. Constructed of durable machined brass components, this cylinder is part of Medeco's M4 (Medeco 4) platform, which carries UL437 listing for drill and pick resistance along with utility patent-pending key control. With ANSI A156.30 Level A and ANSI A156.5 Grade 1 certifications, the 2020097 delivers patent-protected key control and consistent quality for heavy-use commercial applications.

Key Features

  • 6-Pin Cylinder Configuration: Features a 6-pin tumbler design for enhanced security and key control in commercial-grade cylindrical locksets.
  • Retrofit Compatibility: Designed to retrofit knob-type cylindrical locksets, lever-type cylindrical locksets, padlocks, and bored-type auxiliary deadlatches and deadlocks — including the Schlage S Series.
  • UL437 Listed: Medeco M4 Key-in-Knob cylinders are UL437 listed for drill and pick resistance, providing a high level of physical attack protection.
  • Patent-Pending Key Control: Utility patent-pending key control technology restricts unauthorized key duplication for enhanced access management.
  • Machined Brass Construction: Cylinders are constructed of durable machined brass components for long-lasting performance in demanding commercial environments.
  • Industry-Leading Retrofit Range: Medeco offers over 100 different cylinder designs and tailpiece configurations, enabling the largest retrofit capability in the industry and reducing the need for complete lockset replacements.
  • Multiple Finish Options: Available in 14 finishes including Bright Brass (05), Satin Brass (06), Antique Brass (09), Satin Brass Blackened (10), Bright Bronze (11), Satin Bronze (12), Oil Rubbed Bronze (13), Bright Nickel (18), Satin Nickel (19), Antique Nickel (20), Black (22), Dark Bronze (24), Bright Chrome (25), and Satin Chrome (26).

Certifications & Compliance

  • UL437 Listed — Drill and Pick Resistance (Medeco M4)
  • ANSI A156.30 Level A — Patent-Protected Key Control and Physical Strength (M4, M3)
  • ANSI A156.5 Grade 1 — Consistent Quality for Heavy-Use Applications (M4/M4 BiLevel, M3)

Technical Specifications

  • Product Family: Key-in-Knob/Lever Cylinder
  • Pinning: 6-Pin
  • Compatible Hardware: Schlage S Series
  • Certification: UL 437 Listed; ANSI/BHMA A156.30 (M4); ANSI/BHMA A156.5 Grade 1 (M4)
  • Construction: Durable machined brass components
  • Warranty: 2-year manufacturer's warranty

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Retail Establishments
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Medeco?

Medeco Key-in-Knob cylinders are built from durable machined brass components and engineered to meet the rigorous demands of commercial security applications. The M4 platform's UL437 listing for drill and pick resistance, combined with ANSI A156.30 Level A and ANSI A156.5 Grade 1 certifications, ensures that the 2020097 delivers both patent-protected key control and the physical strength required for heavy-use environments. With over 100 retrofit cylinder designs available, Medeco provides unmatched flexibility for upgrading existing hardware without full lockset replacement.

Manufacturer Resources

Medeco Product Catalog

Product Specs

Product Group:
Parts and Accessories
Series:
2020097
Product Subgroup:
Cylinders
Product Type:
Key-in-Knob/Lever Cylinder
Commercial/Residential:
Commercial
Subcategory:
Cylinders
Cylinder Classification:
6Pin
Product Category:
Parts and Accessories
Department:
Door Hardware

Medeco 2020097T-06-DLT – Frequently Asked Questions

1) Will the Medeco 2020097 cylinder fit a Schlage S Series lockset?
That is exactly what it is built for. The Medeco 2020097 is a 6-pin key-in-knob/lever retrofit cylinder for Schlage S Series hardware, so you can upgrade the key control on an existing S Series lockset without replacing the lock body. It also fits knob-type and lever-type cylindrical locksets, padlocks, and bored-type auxiliary deadlatches and deadlocks of the same style.
2) What do I need to specify when ordering a Medeco 2020097 knob cylinder?
Three choices decide the part. Keyway and technology: Biaxial or M3. Pinning state: Pinned, Sub-Assembled, or Sub-Assembled with No Slider. And finish, from 13 options. If you are keying it yourself in the shop, the sub-assembled options let you pin it to your existing system; if you want it delivered ready to install, order it Pinned.
3) Can I key a Medeco 2020097 into my existing Medeco master key system?
Yes, if your system is Biaxial or M3. Those are the two keyway technologies the 2020097 comes in, so order the one that matches the system already in the building. For shop keying, the sub-assembled versions ship uncombinated so a locksmith can pin them to the existing bitting. Note the description ties the UL437 listing and the ANSI A156.30 Level A key control rating to the M4 platform this cylinder belongs to.
4) Is this Medeco knob cylinder rated for a high-traffic commercial building?
It is a commercial-duty part. The 2020097 carries ANSI A156.5 Grade 1 for heavy-use applications and ANSI A156.30 Level A for patent-protected key control and physical strength, and the M4 cylinders are UL437 listed for drill and pick resistance. Body components are machined brass. That combination is what schools, hospitals, government buildings and multi-tenant residential specify.
5) What is the difference between Sub-Assembled and Sub-Assembled No Slider on the Medeco 2020097?
Both are shop-keying options, shipped for a locksmith to combinate rather than ready-to-use. The No Slider version leaves out the slider component, which is what you want when you are building the cylinder around parts you already stock or working a particular keying platform. If you have no pinning capability, order Pinned instead.
6) Does the Medeco 2020097 cylinder come with a tailpiece for my lockset?
The 2020097 is the Schlage S Series configuration within Medeco's key-in-knob line, and Medeco publishes over 100 cylinder designs and tailpiece configurations across that line. If your lockset is not an S Series bored lock, the right move is a different Medeco key-in-knob cylinder number rather than this one, because the tailpiece drive is what makes the retrofit work.
7) Can I match the Medeco 2020097 cylinder to the existing finishes on my doors?
Thirteen finishes are offered: Antique Nickel (20), Bright Brass (605), Satin Brass (606), Antique Brass (609), Bright Bronze (611), Satin Bronze (612), Dark Bronze Oil-Rubbed (613), Bright Nickel (618), Satin Nickel (619), Flat Black (622), Dark Bronze (624), Bright Chrome (625), and Satin Chrome (626). For most commercial openings 626 satin chrome or 613 oil-rubbed bronze will match what is already on the knob.
8) Is a 6-pin cylinder better than a 5-pin for key control on a commercial property?
The 2020097 is a 6-pin cylinder, which gives more chambers to work with when you are building a master key system across a building and more theoretical key changes before duplication becomes an issue. Combined with Medeco's utility patent-pending key control, it restricts unauthorized duplication at the keyway level, which is the part that actually stops a tenant cutting extras at a hardware store.
