Mersen A6T10 Class T Fast-Acting Fuse, 600VAC/300VDC

Mersen A6T10 Class T Fast-Acting Fuse, 600VAC/300VDC

The Mersen A6T10 is a Class T fast-acting fuse from the Amp-Trap® line, engineered to combine high current-limitation with a compact physical size for demanding AC/DC power protection applications. Rated 600VAC and 300VDC with an AC maximum interrupting rating (I1) of 200 kA, this fuse operates at 50/60 Hz and is built with a durable glass melamine (GMG) body for superior dimensional stability. The A6T10 is available with a choice of connection type — Blade or Ferrule — letting engineers and contractors match the fuse to the physical configuration of their disconnect, panelboard, or fusible enclosure without sacrificing performance. Regardless of connection type selected, the shared 600VAC/300VDC dual voltage rating, 200 kA interrupting capacity, and GMG body construction remain constant across the family. Unique physical dimensions on every A6T10 fuse prevent substitution of fuses carrying lower voltage ratings or reduced current-limiting capability, protecting the integrity of the circuit design. The A6T10 is RoHS compliant, making it suitable for environmentally conscious commercial and industrial installations that require dependable, code-compliant overcurrent protection.

Key Features

• Voltage Rating: 600VAC / 300VDC for versatile AC and DC circuit protection in a single fuse design.
• Durable Construction: Glass melamine (GMG) body delivers superior dimensional stability for reliable long-term performance in the field.
• Fast-Acting Class T Design: Combines high current-limitation with a small physical size, ideal for space-constrained panelboards, disconnects, and enclosures.
• High Interrupting Capacity: AC maximum interrupting rating (I1) of 200 kA breaking capacity supports demanding fault-current environments.
• Connection Options: Available in Blade or Ferrule connection types to match the physical configuration of the intended fuse holder or disconnect.
• Copper Terminals: Copper connection/terminal material supports dependable, low-resistance electrical contact.
• 50/60 Hz Frequency: Compatible with standard AC power systems used throughout commercial and industrial facilities.
• Permanent Identification: Catalog numbers are stamped directly into the fuse blades for lasting, tamper-resistant identification during maintenance and replacement.
• Unique Rejection Dimensions: Sizing prevents substitution of fuses with lower voltage or current-limiting ratings, safeguarding system protection levels.

Certifications & Compliance

• RoHS Compliant

Technical Specifications

• ROHS Compliant: Yes
• Body/Insulating Material: GMG
• Connection Type Options: Blade, Ferrule

Typical Applications

• Industrial and Commercial Electrical Systems
• Motor and Equipment Overcurrent Protection
• Panelboards and Switchgear Requiring Class T Fuses
• Circuits Requiring High Current-Limiting Protection
• Combined AC/DC Power Distribution Systems
• Disconnect Switches and Fusible Enclosures

Why Mersen?

Mersen's A6T10 Amp-Trap® fuses are built with a glass melamine body for dimensional stability and feature permanently stamped catalog numbers to prevent misidentification in the field. With a 200 kA AC interrupting rating, a 600VAC/300VDC dual rating, a choice of Blade or Ferrule connection, and RoHS compliance, the A6T10 delivers code-compliant, high current-limiting protection that engineers and electrical contractors can rely on for professional installations.
