Mersen ATMR Series Class CC Fast-Acting Fuse, 20A 600VAC/600VDC

The Mersen ATMR Series Class CC Fast-Acting Fuse delivers reliable overcurrent protection with a 20A current rating and dual 600VAC/600VDC voltage capability. Featuring ferrule terminals with tin-plated copper construction and GMG body insulating material, this fuse provides a 200 kA AC breaking capacity for demanding industrial and commercial electrical applications, with RoHS compliant construction supporting environmentally conscious installations.

Key Features

  • 20A Current Rating: Provides precise overcurrent protection for medium-load circuits and equipment protection applications.
  • 600VAC/600VDC Dual Voltage: Versatile voltage compatibility supports both AC and DC systems up to 600V for flexible installation options.
  • Class CC Fast-Acting Response: Delivers rapid fault clearing to minimize equipment damage and enhance system protection reliability.
  • 200 kA Breaking Capacity: High interrupting rating (Ac Max I R Breaking Capacity I1) handles severe fault conditions while maintaining circuit integrity and safety.
  • Ferrule Terminal Design: Tin-plated copper terminals ensure reliable connections and corrosion resistance for long-term performance.
  • GMG Insulating Material: Professional-grade body construction provides excellent electrical insulation and mechanical durability.
  • Clip Mounting System: Convenient installation method allows secure mounting in compatible fuse holders and panels.
  • Compact Footprint: Product length of 1.5 in and weight of 0.017 lb suit space-constrained panel and control cabinet layouts.

Certifications & Compliance

  • RoHS Compliant
  • Rated Voltage AC UL: 600V
  • Rated Voltage DC UL: 600V

Technical Specifications

  • Body Insulating Material: GMG
  • Rohs Compliant: Yes
  • Ampere Rating: 20 A
  • Fuse Class: Class CC
  • Speed Characteristic: Fast-Acting
  • Connection Terminal Type: Ferrule
  • Connection Terminal Material: Tin-Plated Copper
  • Mounting Method: Clip
  • Frequency: 50/60 Hz
  • Ac Max I R Breaking Capacity I1: 200 kA
  • Product Length: 1.5 in
  • Product Weight: 0.017 lb

Typical Applications

  • Industrial Control Panels and Motor Control Centers
  • Commercial Electrical Distribution Systems
  • Power Supply and UPS Protection Circuits
  • HVAC Equipment and Building Systems
  • Manufacturing and Process Control Equipment
  • Renewable Energy and Battery Storage Systems

Why Mersen?

Mersen delivers professional-grade electrical protection with RoHS compliant construction, GMG body insulation, and tin-plated copper terminals for dependable long-term performance. The ATMR Series pairs a 200 kA breaking capacity with dual 600VAC/600VDC voltage support, giving engineers and installers a compact, code-ready Class CC fuse for critical overcurrent protection applications.

Manufacturer Resources

Product Specs

Connection Terminal Material:
Tin-Plated Copper
Product Group:
Wiring Devices
Rohs Compliant:
Yes
Body Insulating Material:
GMG
Frequency Hz:
50/60 Hz
Ac Or Dc:
AC/DC
Ac Max I R Breaking Capacity I1:
200 kA
Rated Voltage Dc Ul:
600 V
Fuse Class:
Class CC
Speed Characteristic:
Fast-Acting
Product Weight:
0.017 lb
Rated Voltage Ac Ul:
600 V
Connection Terminal Type:
Ferrule
Department:
Electrical
Product Length:
1.5 in
Mounting Method:
Clip
Product Type:
Fuse

Mersen ATMR20 – Frequently Asked Questions

1) Will a Mersen ATMR fuse fit a standard 10x38mm Class CC fuse holder?
The ATMR is a Class CC ferrule fuse with a 1.5 inch body length, which is the standard Class CC dimension (10x38mm), so it drops into any Class CC rejection holder or clip base. Class CC holders are rejection-style by design: they accept Class CC only and physically block Class G, J, or midget fuses, so if your holder is marked Class CC the ATMR seats correctly.
2) Can I use the Mersen ATMR fuse on a 600V DC battery or solar circuit, not just AC?
Both. The ATMR carries a 600V AC and a 600V DC rating, so it's usable in DC systems such as battery storage and PV strings as well as AC control power. That dual rating is not a given on midget fuses, and it's the reason this one shows up in UPS and renewable energy panels. AC frequency rating is 50/60 Hz.
3) Is a fast-acting Class CC fuse like the ATMR right for protecting a motor circuit?
Not for motor branch-circuit protection. The ATMR is fast-acting, so it clears quickly and will not ride through a motor's inrush current on start; you'd get nuisance openings. Fast-acting is the right choice where there is little or no inrush: control transformers on the secondary side, PLC and I/O power, semiconductor and electronic loads, instrumentation, and general feeder protection. For motor starting duty you want a time-delay Class CC fuse instead of this one.
4) Will a Class CC fuse fit where I currently have a 13/32 x 1-1/2 midget fuse?
Physically yes, the other way around no. The ATMR is 1.5 inches long with the same ferrule ends as a standard midget fuse, so it seats in a plain midget clip or holder. But a Class CC rejection holder will not accept a plain midget fuse in return, because the rejection feature keys to the Class CC ferrule. If you are replacing into a rejection-style CC holder you must use a Class CC fuse such as the ATMR.
5) What amperages does the Mersen ATMR fuse come in?
Eighteen ratings, from 1/4 amp up to 30 amps: 0.25, 0.5, 1, 1.5, 2, 2.5, 3, 4, 5, 6, 7, 8, 10, 12, 15, 20, 25 and 30 amps. Part numbers follow the amperage directly, so 20A is ATMR20, 15A is ATMR15, and fractional ratings use fractions, ATMR1/2 for half an amp and ATMR2-1/2 for 2.5 amps. Thirty amps is the ceiling because that's the top of the Class CC class.
6) How do I pick the right amp rating of ATMR fuse for a control transformer secondary?
Size to the load, not to the wire. On a control transformer secondary you'd typically pick the next standard rating above full load current, and the ATMR range gives you fine granularity down low where control circuits live: 0.25, 0.5, 1, 1.5, 2, 2.5 and 3 amps are all separate part numbers, so you are not forced to jump from 1A straight to 5A. Fast-acting response means the fuse won't ride out a downstream short, which is the behavior you want ahead of electronics.
7) What is the difference between buying a PowerLogic meter fuse pack and buying Mersen ATMR fuses individually?
The Square D PowerLogic fuse pack is a matched set of three fuses at one rating, 0.5A 600V, intended to refuse all three phases of a meter at once. The Mersen ATMR is ordered by individual ampere rating across a range that runs from 0.25A through 30A, so a panel builder standardizing on one Class CC fuse family can pull 0.5A for metering taps and larger ratings for control transformers and motor circuits from the same 600V AC/DC fast-acting series. Buy the pack when the job is a three-phase meter refuse at a single rating; buy ATMR by rating when the ampere values differ across the circuits being protected.
8) Is the Mersen ATMR fuse RoHS compliant for a spec that requires it?
Yes, ATMR fuses are built RoHS compliant. Terminals are tin-plated copper rather than a leaded plating, and the body uses GMG insulating material.
9) Are Mersen ATMR fuses sold individually or in packs of three?
ATMR fuses are ordered as single fuses by amperage, one part number per rating. If you're fusing all three phases you order three of the same part number. Some meter fuse products do ship as a matched set, for example the Square D PowerLogic Energy Meter Fuse Pack, which comes as a set of three, but the ATMR is not packaged that way.
10) Will Mersen ATMR fuses hold up in an outdoor or humid control cabinet?
Terminals are tin-plated copper, which resists the surface corrosion that raises contact resistance and heats a fuse clip over time, and the body is GMG insulating material. Those are the two parts that degrade in a damp cabinet, and both are specified here.
