Mersen GSA Time-Delay Miniature Fuse, 250VAC, Ceramic Ferrule

Mersen GSA Time-Delay Miniature Fuse, 250VAC, Ceramic Ferrule

(No reviews yet) Write a Review

Model: GSA20

In Stock (leaves warehouse same day if ordered before 3pm ET)

$725.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Mersen GSA10 Time-Delay Miniature Fuse 10A 250VAC Ceramic Ferrule Terminal

The Mersen GSA10 Time-Delay Miniature Fuse delivers reliable supplemental circuit protection rated 10A at 250VAC, built around a rugged ceramic body with ferrule terminal connections for secure electrical contact. Sized at a compact 6.3x32mm with clip mounting, this Mersen fuse is engineered with a time-delay speed characteristic that rides out momentary inrush conditions while still tripping on sustained overloads and faults. Each unit is RoHS compliant for use in commercial and industrial equipment, and this listing covers a 100 Pack quantity for stocking panels, control cabinets, and maintenance inventories.

Key Features

  • Compact Size: 6.3x32mm ceramic fuse body fits standard miniature fuse holders and electrical panels.
  • Durable Construction: Ceramic body construction provides superior insulation properties and thermal stability under load.
  • Ferrule Terminal Design: Ferrule terminals ensure a secure, professional-grade connection in clip-mount fuse holders.
  • Time-Delay Characteristic: Rides out temporary overcurrent conditions while still protecting against sustained faults and overloads.
  • 10A Current Rating: Sized for precise overcurrent protection on medium-load circuits and equipment.
  • 250VAC Voltage Rating: Suitable for standard AC electrical systems requiring reliable voltage handling.
  • Clip Mounting: Supplemental-class fuse mounts via clip contacts for straightforward installation and replacement.
  • 100 Pack Quantity: Supplied in a 100-count pack for stocking maintenance and production needs.

Certifications & Compliance

  • RoHS Compliant

Technical Specifications

  • Ac Or Dc: AC
  • Rohs Compliant: Yes
  • Fuse Class: Supplemental
  • Fuse Size: 6.3x32mm
  • Body Insulating Material: Ceramic
  • Connection Terminal Type: Ferrule
  • Mounting Method: Clip
  • Speed Characteristic: Time Delay
  • Rated Voltage AC UL: 250V
  • Product Length: 1.25 in

Typical Applications

  • Industrial Control Panels and Automation Systems
  • Commercial Electrical Distribution Equipment
  • Motor Control Centers and Drive Applications
  • Instrumentation and Control Circuits
  • Electronic Equipment Protection
  • Supplemental Circuit Protection Systems

Why Mersen?

Mersen builds the GSA Series around a ceramic body for superior thermal performance and a ferrule terminal interface for dependable, professional-grade connections. With a time-delay characteristic that distinguishes harmless transient surges from true overloads, RoHS compliance, and a compact 6.3x32mm clip-mount format, this fuse is a dependable choice for supplemental circuit protection in commercial and industrial electrical systems.

Manufacturer Resources

Product Specs

Product Group:
Wiring Devices
Rated Voltage Ac Ul:
250 V
Rohs Compliant:
Yes
Body Insulating Material:
Ceramic
Fuse Size:
6.3x32
Fuse Class:
Supplemental
Speed Characteristic:
Time Delay
Product Weight:
0.01 lb
Ac Or Dc:
AC
Connection Terminal Type:
Ferrule
Department:
Electrical
Product Length:
1.25 in
Mounting Method:
Clip
Product Type:
Fuse

Mersen GSA20 – Frequently Asked Questions

1) Will a Mersen GSA fuse fit a standard 6.3x32mm fuse holder?
Yes. The GSA Series is a 6.3x32mm ferrule fuse, so it drops into any holder or clip block built for that size (commonly called 1/4 x 1-1/4 inch). Stated body length is 1.25 in. The terminals are ferrule type and the mounting is clip contact, so there are no solder tabs or screw lugs to deal with, just pull the old fuse and press the new one into the clips.
2) What amp ratings does the Mersen GSA time-delay fuse come in?
Nine ratings: 1A, 2A, 3A, 5A, 8A, 10A, 12A, 15A and 20A, ordered as GSA1 through GSA20. All of them share the same 6.3x32mm ceramic body and the same 250VAC rating, so the holder and panel prep do not change when you move up or down the range. That makes it straightforward to standardize one holder type across a control cabinet and stock only the amperages you actually use.
3) Can I use a Mersen GSA fuse as the branch circuit protection in a panel?
No. The GSA is a supplemental-class fuse. Supplemental fuses protect a specific piece of equipment or an internal circuit downstream of a device that is already providing branch circuit protection. They do not replace the branch circuit fuse or breaker feeding the panel. If you are protecting the branch itself, you need a branch-rated device, not a 6.3x32mm supplemental fuse.
4) My fuse keeps blowing when the motor or power supply starts up, will a time delay fuse fix it?
That is what the GSA is built for. It has a time-delay speed characteristic, so it tolerates the brief inrush current of a motor start, a transformer energizing, or a switching power supply charging its capacitors, while still opening on a sustained overload or a fault. A fast-acting fuse of the same amp rating will nuisance-trip on that same inrush. Swapping to a time-delay fuse of the same rating and the same 6.3x32mm size is the usual fix, as long as the nuisance trips are genuinely startup related and not a real overload.
5) Is the Mersen GSA rated for DC circuits?
The GSA carries an AC rating only: 250V AC, UL rated. If your circuit is DC, this is not the right fuse. DC arcs do not self extinguish at a current zero the way AC arcs do, so a fuse used on DC needs a published DC voltage rating and interrupting capability. Use the GSA on AC control and equipment circuits at 250V or less.
6) Can a Square D PowerLogic energy meter fuse pack be used in place of a Mersen GSA fuse?
No - they protect different things. The Mersen GSA is a 6.3x32mm ceramic time-delay supplemental fuse rated 250VAC, sold as single fuses in amperages from 1A up to 20A for control panels and equipment circuits. The Square D PowerLogic Energy Meter Fuse Pack is a set of three 0.5A 600V fuses intended for the metering inputs on a PowerLogic energy meter. The 0.5A rating and 600V class put it in metering-circuit service, not on a 10A or 15A load circuit, and the GSA amperage range does not extend down to 0.5A. Order the GSA for equipment and control-circuit protection, and the PowerLogic pack when you are replacing the fuses that came with the meter itself.
7) Ceramic or glass fuse, which should I put in a control panel?
Ceramic, which is what the GSA body is. A ceramic body handles heat better and gives higher interrupting performance than a glass tube of the same 6.3x32mm size, which matters in an enclosed control cabinet where ambient temperature is already elevated. The tradeoff is that you cannot see the element, so you cannot tell a blown ceramic fuse by eye. Check it with a meter on continuity instead. Glass is the choice only when visual inspection is worth more to you than thermal margin.
8) Is the Mersen GSA fuse RoHS compliant for equipment we build and ship?
Yes, the GSA Series is RoHS compliant, which is what an OEM or panel builder needs when the finished assembly has to carry a RoHS declaration. That is the compliance statement carried on this fuse; treat any other listing or marking requirement for your assembly as separate.
9) How many Mersen GSA fuses come in a pack?
The GSA time-delay fuses are supplied 100 to a pack, one amperage per pack. For an MRO crib or a production line that is the sensible way to buy them, since a single fuse weighs about 0.01 lb and stocking two or three of the amperages you actually use covers most panel work. Order the amperage separately for each rating you want to carry.
