Mersen USBB UltraSafe Class CC Touch-Safe Bus Bar System

Mersen USBB UltraSafe Class CC Touch-Safe Bus Bar System

(No reviews yet) Write a Review

Model: USBB3PH25K6

In Stock (leaves warehouse same day if ordered before 3pm ET)

$95.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Mersen USBB UltraSafe Class CC Touch-Safe Bus Bar System

The Mersen USBB UltraSafe bus bar system is engineered for use with UltraSafe Class CC (USCC) and Midget (USM) fuse holders, delivering a safe and reliable combination of circuits in a compact, panel-friendly design. Rated at 600V AC UL and 1000V DC UL, this touch-safe, shock-resistant bus bar system is available in 1-, 2-, and 3-phase configurations and is RoHS compliant for use in modern panel builds. Compared to traditional wire solutions, the USBB reduces installation time while saving valuable panel space for electrical panel builders and designers.

Key Features

  • Compact, Space-Saving Design: Reduces panel footprint compared to conventional wire-based circuit combinations.
  • Touch-Safe, Shock-Resistant Construction: Delivers a touch-safe, shock resistant solution for panel builders and designers.
  • UltraSafe Fuse Holder Compatibility: Designed for use with UltraSafe Class CC (USCC) and Midget (USM) fuse holders.
  • Multiple Phase Configurations: Available in 1-, 2-, and 3-phase bus bar designs, including this 6-pole, 3-phase configuration.
  • Rated Voltage: 600V AC UL and 1000V DC UL for demanding panel applications.
  • Faster Installation: Bus bar systems reduce installation time when compared to wire solutions.
  • RoHS Compliant: Meets RoHS compliance requirements for restricted substances.
  • Packaging: Supplied 50 EA per package for panel-building operations.

Certifications & Compliance

  • RoHS Compliant
  • Rated Voltage AC UL: 600V
  • Rated Voltage DC UL: 1000V

Technical Specifications

  • ROHS Compliant: Yes
  • Design Details: 3
  • Number of Poles: 6-Pole
  • Rated Voltage AC UL: 600 V
  • Rated Voltage DC UL: 1000 V

Typical Applications

  • Panelboard and Load Center Circuit Combination
  • Class CC (USCC) and Midget (USM) Fuse Holder Panel Builds
  • Commercial and Industrial Electrical Panels
  • Compact Panel Designs Requiring Touch-Safe Bus Bars
  • Multi-Phase (1-, 2-, and 3-Phase) Panel Wiring
  • Renovation and New Construction Panel Assemblies

Why Mersen?

Mersen's USBB UltraSafe bus bar system combines touch-safe, shock-resistant construction with a compact, RoHS compliant design built for reliable, code-conscious panel building. By pairing directly with UltraSafe Class CC (USCC) and Midget (USM) fuse holders, Mersen helps panel builders and designers save space and installation time while delivering the dependable performance electrical professionals expect from their bus bar systems.

Manufacturer Resources

Mersen Product Catalog

Product Specs

ROHS Compliant:
Yes
Rated voltage DC UL:
1000 V
Design Details:
3
Number of Poles:
6-Pole
Rated voltage AC UL:
600 V
list_batch:
MERSEN-20260825
Department:
Electrical
Product Group:
Power Distribution
Product Type:
Bus Bar
Product Subgroup:
Power Distribution Blocks

Mersen USBB3PH25K6 – Frequently Asked Questions

1) How many fuse holders does the USBB3PH25K6 bus bar feed, and is it single or three phase?
Model USBB3PH25K6 is a 6-pole, 3-phase bar, so it ties six fuse holder poles into three phases (two poles per phase). Mersen also builds the USBB in 1-phase and 2-phase configurations if your circuit combination is different.
2) Is this bus bar rated for a 480V or 600V industrial control panel?
Yes. The USBB UltraSafe bus bar carries a 600V AC UL rating, so a 480V or 600V AC control panel is within rating. For DC applications such as solar or battery circuits it is rated 1000V DC UL.
3) Is the Mersen USBB bus bar touch safe with the panel door open?
The USBB is a touch-safe, shock-resistant design, with the conductor shrouded so fingers cannot reach live metal during service. That is the main reason panel builders choose it over bare copper bar or exposed jumper wiring where technicians work in an energized enclosure.
4) Why use a bus bar instead of just wiring the fuse holders together?
Two reasons drive it. Wiring six poles individually means cutting, stripping and terminating a dozen jumpers; the USBB drops on and lands the whole phase group at once, cutting install labor. It also takes less room than a wire bundle, which matters in compact panels where gutter space is already tight. The trade-off is that the bar commits you to UltraSafe USCC or USM holders in adjacent positions, so if your fuse holders are scattered across a DIN rail, wire is still the answer.
5) Is the Mersen USBB sold individually or in a box?
It is supplied 50 each per package, which suits production panel-building operations rather than a one-off repair. Plan the order quantity around that pack size.
6) Is the Mersen USBB bus bar RoHS compliant for export panel builds?
Yes, the USBB UltraSafe bus bar system is RoHS compliant, which covers restricted-substance requirements on panels being shipped into markets that demand it.
