Milbank 20 Amps Ring-Type CT Rated Sockets, Plunger Bypass

Milbank 20 Amp Ring-Type CT Meter Socket with Auto Bypass - 600V Surface Mount

(No reviews yet) Write a Review

Model: UC1300-RL

In Stock (leaves warehouse same day if ordered before 3pm ET)

$384.81
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Milbank 20 Amp Ring-Type CT Meter Socket with Auto Bypass - 600V Surface Mount

Professional metering solution with automatic bypass capability

The Milbank 20 Amp Ring-Type CT Meter Socket delivers reliable electrical metering with automatic bypass functionality for continuous service during meter changes. Constructed with G90 galvanized steel and powder coat finish for durability, this UL Listed Type 3R enclosure provides single-position metering with 600V AC rating and surface mount installation for versatile overhead or underground cable entry applications.

Professional Features & Benefits

  • 20 Continuous Ampere Rating: Provides reliable current handling capacity for residential and light commercial metering applications
  • Auto Bypass Provision: Enables uninterrupted power during meter maintenance and replacement operations
  • 600V AC Rating: Supports standard electrical system voltages with professional-grade insulation and safety margins
  • G90 Galvanized Steel Construction: Delivers superior corrosion resistance and long-term durability in outdoor environments
  • UL Listed Type 3R Enclosure: Meets stringent safety standards for outdoor installation with weather protection
  • Glass Polyester Insulation: Provides excellent electrical isolation and thermal performance for safe operation
  • Flexible Cable Entry: Accommodates both overhead and underground service connections for installation versatility

Technical Specifications

  • Amperage Rating: 20 Continuous Ampere
  • Application: Meter Socket
  • Brand Name: Milbank
  • Bypass Provision: Auto Bypass
  • Cable Entry: Overhead or Underground
  • Departent: Electrical
  • Equipment Ground: Ground Lug
  • Frequency Rating: 60 Hertz
  • Hub Closing Plate: Small Hub Opening
  • Insulation: Glass Polyester
  • Line Side Wire Range: 12 - 10 AWG
  • Load Side Wire Range: 12 - 10 AWG
  • Main Breaker Size: No Main Breaker
  • Number Of Main Breakers: 0
  • Number Of Meter Positions: 1 Position
  • Number Of Receptacles: 0
  • Product Family Code: CT20
  • Product Height: 14 IN
  • Product Length: 3.313 IN
  • Product Material: G90 Galvanized Steel with Powder Coat Finish
  • Product Mounting: Surface Mount
  • Product Size: 3.313L x 8W x14H
  • Product Type: Ring Type Meter Socket
  • Standard: UL Listed;Type 3R
  • Terminal: Single Mechanical
  • Unspsc Number: 39121102
  • Voltage Rating: 600 Volts Alternating Current
  • Width: 8 IN

Professional Applications

  • Residential electrical service metering
  • Small commercial facility metering
  • Multi-unit property individual metering
  • Professional office electrical monitoring
  • Retail establishment power metering
  • Light industrial current measurement
  • Emergency services facility metering

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed certification and Type 3R weather protection. The G90 galvanized steel construction with powder coat finish ensures long-term durability, while the glass polyester insulation provides superior electrical performance for safe, dependable metering operations.

Manufacturer Resources

Product Specs

Amperage Rating:
20 Continuous Ampere
Application:
Meter Socket
Brand Name:
Milbank
Bypass Provision:
Auto Bypass
Cable Entry:
Overhead or Underground
Equipment Ground:
Ground Lug
Frequency Rating:
60 Hertz
Hub Closing Plate:
Small Hub Opening
Insulation:
Glass Polyester
Line Side Wire Range:
12 - 10 AWG
Load Side Wire Range:
12 - 10 AWG
Main Breaker Size:
No Main Breaker
Number Of Main Breakers:
0
Number Of Meter Positions:
1 Position
Number Of Receptacles:
0
Product Family Code:
CT20
Product Height:
14 IN
Product Length:
3.313 IN
Product Size:
3.313L x 8W x14H
Product Type:
Ring Type Meter Socket
Standards:
UL Listed;Type 3R
Terminal:
Single Mechanical
Unspsc Number:
39121102
Voltage Rating:
600 Volts Alternating Current
Product Material:
G90 Galvanized Steel with Powder Coat Finish
Product Mounting:
Surface Mount
Amps:
20
Product Width:
8 IN
Department:
Electrical
Product Subgroup:
Metering & Meter Sockets
Insulation Type:
Glass Polyester
Hub Style:
Small Hub Opening
Installation Category:
Surface Mount
Terminal Type:
Single Mechanical
Frequency:
60 hertz
Product Details:
Ring Type Meter Socket
Product Group:
Power Distribution

Milbank UC1300-RL – Frequently Asked Questions

1) Does the Milbank UC series 20A ring-type socket carry the service load, or is it only for CT secondary wiring?
It is a CT-rated meter socket, so the service conductors never pass through it. The 20 continuous amp rating and the 12-10 AWG line and load terminals are sized for current transformer secondary leads and potential leads only. The actual service current stays in the CT cabinet. If you need a socket that carries the full service, you want a self-contained 100A, 200A or 320A socket instead, not this one.
2) What is the difference between the terminal options 5, 6, 8 and 13 on the Milbank UC CT meter socket?
Terminal count is the only ordering choice, and it has to match the metering configuration your utility specifies. Four builds are offered: 5 terminal (UC1291-RL), 6 terminal (UC1300-RL), 8 terminal (UC7544-RL) and 13 terminal (UC7545-RL). Get the terminal count off the utility's metering spec sheet before you order, because the socket jaw arrangement has to match the meter the utility will set.
3) Can this Milbank CT meter socket be mounted outdoors on an exterior wall?
Yes. The enclosure is UL Listed and rated Type 3R, which is the outdoor rain-tight classification, and the body is G90 galvanized steel with a powder coat finish for corrosion resistance. It mounts to the surface of the wall or structure, and cable can come in overhead or underground.
4) Will the utility be able to change the meter without dropping power to the tenant?
Yes. The socket includes an auto bypass provision, which shorts the CT secondaries and maintains the circuit while the meter is pulled, so the load stays energized during a meter change or test. That is the main reason to spec this over a non-bypass CT socket on a building you cannot take offline.
5) Is this a ring type or ringless meter socket, and does that matter for my utility?
It is a ring type socket, meaning the meter is retained by a sealing ring rather than a removable ringless cover. Utilities specify one or the other and will not set a meter in the wrong style, so confirm the requirement with your serving utility before ordering. If they require ringless, this socket will not be accepted.
6) How much wall space do I need for the Milbank 20A ring-type CT socket?
Plan on a footprint of 3.313 x 8 x 14 inches, with 14 inches the height and 8 inches the width. It is a single meter position enclosure, so it is narrow enough to sit beside the CT cabinet on most service walls.
7) Is there a main breaker or disconnect in this Milbank meter socket?
No. This is a metering enclosure only, with no main breaker and no receptacles. Overcurrent protection and the service disconnect have to be provided separately, typically in the panel or the CT cabinet assembly downstream.
8) What voltage and frequency can the Milbank UC CT socket be used on?
It is rated 600 volts AC at 60 hertz, which covers standard 120/240V, 120/208V and 277/480V metering installations in North America.
9) How do the equipment ground and the conduit entry work on this Milbank CT socket?
Grounding is made up at a ground lug inside the enclosure. The top is furnished with a small hub opening closing plate, so you pick a hub sized for your conduit or leave the plate in place for underground entry from below. Terminals are single mechanical type, taking 12 to 10 AWG on both line and load sides.
10) I'm standardizing meter sockets across a multi-building property. Can I spec one part number for all of them?
Only if every opening uses the same metering configuration. The enclosure, the 600V 60Hz rating, the Type 3R construction and the single meter position are common across the range, but the terminal count varies by utility requirement: 5, 6, 8 or 13 terminal. Pull the terminal count for each service and order accordingly; the rest of the assembly is identical, so spares interchange within a given terminal count.
11) What is the insulation material inside this Milbank meter socket, and how does it hold up outdoors?
The internal insulating base is glass polyester, which is the standard dielectric barrier material for CT metering enclosures and tolerates the heat and moisture cycling of an exterior Type 3R installation. The outer shell is G90 galvanized steel with a powder coat finish.
