Milbank U9700-RXL 7 Terminal Ringless Large Hub Open Adapt To Small Closing Plate Lever Bypass Overhead

Milbank 200A 3-Phase Ringless Meter Socket with Lever Bypass and Large Hub Adapter

(No reviews yet) Write a Review

Model: U9700-RXL

In Stock (leaves warehouse same day if ordered before 3pm ET)

$863.51
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Milbank 200A 3-Phase Ringless Meter Socket with Lever Bypass and Large Hub Adapter

Professional electrical metering solution with versatile hub configuration

The Milbank 200A 3-Phase Ringless Meter Socket delivers reliable electrical metering performance with 200 continuous ampere capacity and 600V AC rating. Featuring durable G90 galvanized steel construction with powder coat finish and Type 3R enclosure rating, this surface-mount unit provides professional-grade protection for overhead cable entry applications. The 7-terminal design with lever bypass provision and large hub opening adapted to small closing plate offers versatile installation flexibility.

Professional Features & Benefits

  • 200 Continuous Ampere Rating: Handles substantial electrical loads for commercial and multi-unit residential applications with reliable current capacity.
  • 3-Phase Configuration: Supports three-phase power distribution systems commonly required in commercial and industrial electrical installations.
  • Lever Bypass Provision: Enables safe meter maintenance and replacement without interrupting power service to critical loads.
  • Type 3R Enclosure Rating: Provides weather-resistant protection suitable for outdoor installations and harsh environmental conditions.
  • G90 Galvanized Steel Construction: Ensures long-term durability and corrosion resistance with professional powder coat finish.
  • Large Hub Adapter Design: Accommodates various conduit configurations with large hub opening adapted to small closing plate for installation versatility.
  • UL Listed Certification: Meets rigorous safety standards for professional electrical installations and code compliance.

Technical Specifications

  • Amperage Rating: 200 Continuous Ampere
  • Application: Meter Socket
  • Brand Name: Milbank
  • Bypass Provision: Lever Bypass
  • Cable Entry: Overhead
  • Departent: Electrical
  • Equipment Ground: Grounding Stud
  • Frequency Rating: 60 Hertz
  • Hub Closing Plate: Large Hub Opening Adapted to Small Closing Plate
  • Insulation: Glass Polyester
  • Line Side Wire Range: 6 AWG - 350 kcmil
  • Load Side Wire Range: 6 AWG - 350 kcmil
  • Main Breaker Size: No Main Breaker
  • Number Of Jaws: 7 Terminal
  • Number Of Main Breakers: 0
  • Number Of Meter Positions: 1 Position
  • Number Of Receptacles: 0
  • Phase: 3 Phase
  • Product Family Code: HD7T
  • Product Height: 18.5 IN
  • Product Length: 4.844 IN
  • Product Material: G90 Galvanized Steel with Powder Coat Finish
  • Product Mounting: Surface Mount
  • Product Size: 4.844L x 10W x18.5H
  • Product Type: Ringless Meter Socket
  • Standard: UL Listed;Type 3R
  • Terminal: Lay in
  • Unspsc Number: 39121102
  • Voltage Rating: 600 Volts Alternating Current
  • Width: 10 IN

Professional Applications

  • Commercial Building Electrical Service
  • Multi-Unit Residential Properties
  • Industrial Facility Metering
  • Retail and Office Buildings
  • Municipal and Government Facilities
  • Educational Institution Power Distribution
  • Healthcare Facility Electrical Systems

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed certification and Type 3R weather-resistant construction. The G90 galvanized steel material with powder coat finish ensures long-term performance in demanding electrical service applications, backed by professional-grade engineering and manufacturing standards.

Manufacturer Resources

Product Specs

Amperage Rating:
200 Continuous Ampere
Application:
Meter Socket
Brand Name:
Milbank
Bypass Provision:
Lever Bypass
Cable Entry:
Overhead
Equipment Ground:
Grounding Stud
Frequency Rating:
60 Hertz
Hub Closing Plate:
Large Hub Opening Adapted to Small Closing Plate
Insulation:
Glass Polyester
Line Side Wire Range:
6 AWG - 350 kcmil
Load Side Wire Range:
6 AWG - 350 kcmil
Main Breaker Size:
No Main Breaker
Number Of Jaws:
7 Terminal
Number Of Main Breakers:
0
Number Of Meter Positions:
1 Position
Number Of Receptacles:
0
Phase:
3 Phase
Product Family Code:
HD7T
Product Height:
18.5 IN
Product Length:
4.844 IN
Product Size:
4.844L x 10W x18.5H
Product Type:
Ringless Meter Socket
Standards:
UL Listed;Type 3R
Terminal:
Lay in
Unspsc Number:
39121102
Voltage Rating:
600 Volts Alternating Current
Product Material:
G90 Galvanized Steel with Powder Coat Finish
Product Mounting:
Surface Mount
Amps:
200
Product Width:
10 IN
Department:
Electrical
Product Subgroup:
Metering & Meter Sockets
Product Group:
Power Distribution

Milbank U9700-RXL – Frequently Asked Questions

1) Will a Milbank U9700-RXL meter socket work for a 3-phase 4-wire 120/208V service?
The Milbank U9700-RXL is a 7 terminal, 3 phase socket rated 600V AC at 60 Hz, which is the standard jaw configuration for 3-phase 4-wire self-contained metering at 200 amps. Seven terminals means three line, three load, and a neutral. If your utility specs a 4-jaw single-phase or a 5-jaw network socket, this is the wrong socket.
2) Does the Milbank U9700-RXL include a main breaker or distribution section?
No. It is a meter socket only, one meter position, no main breaker and no receptacles. You will need a separate service disconnect downstream (or upstream, depending on what your utility and AHJ allow) to complete the installation.
3) Can I land 4/0 aluminum or 350 kcmil copper service conductors in this Milbank socket?
Yes. Both line and load terminals on the U9700-RXL take 6 AWG through 350 kcmil, so 4/0 and 350 kcmil both land directly. They are lay-in terminals, which makes dressing large service conductors in the can easier than threading through a closed lug.
4) Is this Milbank ringless socket set up for overhead service drop or underground lateral?
Overhead. Cable entry on the U9700-RXL is overhead, and it ships with a large hub opening adapted to a small closing plate so you can fit the hub size your utility requires for the service mast. For an underground lateral you want a bottom-fed socket instead.
5) Can the Milbank U9700-RXL be mounted outdoors on an exterior wall?
Yes. It is a surface mount enclosure, Type 3R rated and UL Listed, built from G90 galvanized steel with a powder coat finish. Type 3R handles rain, sleet and snow, which covers a typical exterior service wall. It is not rated for washdown or for submersion.
6) What does lever bypass do on a meter socket, and do I need it?
The lever bypass on this 200A Milbank socket lets the utility or electrician shunt current around the meter so the meter can be pulled and changed without dropping power to the load. Utilities commonly require bypass on 3-phase commercial services and on anything feeding loads that cannot be interrupted. If your utility does not require it, a non-bypass socket is the simpler order.
7) How much wall space does the Milbank U9700-RXL need?
The socket measures 4.844 long by 10 wide by 18.5 inches high. Allow for the service hub and mast above the 18.5 inch dimension and leave the NEC working clearance in front of the can.
8) What is the difference between a ringless meter socket and a ring-type socket?
A ringless socket like the U9700-RXL uses a sealing cover that slips over the can and is sealed by the utility, rather than a separate locking ring that clamps the meter glass. Utilities specify one or the other and they are not interchangeable in the field, so match whatever your serving utility's meter department requires before ordering.
9) Is there a ground connection point in this Milbank meter socket for the grounding electrode conductor?
Yes, the can has a factory grounding stud for equipment grounding and bonding. Jaw insulation is glass polyester, which is the standard high-strength insulating base for 200A sockets.
10) What is the exact part number to order this Milbank 7-terminal ringless socket?
Order Milbank U9700-RXL. It sits in the HD7T product family: 7 terminal, ringless, lever bypass, overhead, large hub opening adapted to a small closing plate.
