Minerallac 61182J Sammys Vertical Mount Threaded Rod Anchor, Steel

Minerallac 61182J Sammys Vertical Mount Threaded Rod Anchor, Steel

(No reviews yet) Write a Review

Model: 61182J

In Stock (leaves warehouse same day if ordered before 3pm ET)

$80.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
"

Minerallac 61182J Sammys Vertical Mount Threaded Rod Anchor, Steel

The Minerallac 61182J Sammys screw anchor is engineered for fast, one-step installation of threaded rod directly into wood structural members. Sized at 3/8 x 2-1/2" and designed for vertical mounting, this Model #GST 25-380 anchor accepts 3/8" threaded rod and is built from durable steel with an Electro-Zinc finish for corrosion resistance. Each jar contains a 100 pack, giving electrical and mechanical contractors a ready supply for hanger and support installations without the need for pre-drilling or separate hardware. Sammys anchors are widely used by electrical, mechanical, and fire-protection trades that need to hang threaded rod quickly from overhead wood framing without the labor of drilling pilot holes and installing separate expansion anchors, making them a practical choice for high-volume commercial installations. The vertical mount design allows the anchor to be driven straight up into the underside of a wood joist, beam, or truss, so the threaded rod hangs plumb and ready to accept hangers, clevises, or all-thread couplings for conduit, cable tray, and mechanical support runs. This design eliminates a separate pre-drilling step and a separate anchor, cutting installation time significantly on large overhead support runs where dozens or hundreds of rod drops are required.

Key Features

  • Trade Size: 3/8 x 2-1/2" Sammys screw anchor sized for 3/8" threaded rod applications.
  • Vertical Mounting: Installs vertically into the bottom of wood structures for hanging threaded rod, streamlining overhead support work.
  • One-Step Installation: Reduces installation time and labor cost compared to traditional drilling-and-anchoring methods, since no pre-drilling or separate hardware is required.
  • Durable Construction: Manufactured from steel for long-term strength and load-bearing reliability in structural support applications.
  • Finish: Electro-Zinc plated finish helps resist corrosion in typical indoor construction environments.
  • Head Type: 5/8" AF end-drilled head accepts and secures 3/8" threaded rod.
  • Head Color: Silver head finish for easy visual identification on the jobsite.
  • Packaging: Supplied in a jar, 100 pack, for convenient bulk stocking on commercial job sites.

Technical Specifications

  • Country Of Origin: United States
  • Head Color: Silver
  • Head Type: 5/8" AF End-Drilled
  • Product Finish: Electro-Zinc
  • Product Length: 2-1/2 in
  • Product Material: Steel
  • Rod Size: 3/8"
  • Product Type: Threaded Rod Anchor

Typical Applications

  • Hanging Threaded Rod from Wood Joists and Beams
  • Electrical Conduit and Cable Tray Support Systems
  • HVAC Duct and Mechanical Hanger Installations
  • Commercial and Residential Wood-Frame Construction
  • Overhead Support for Fire Sprinkler and Plumbing Lines

Why Minerallac?

Minerallac's 61182J Sammys screw anchor delivers steel construction with an Electro-Zinc finish designed for durable, corrosion-resistant performance in wood-frame support applications. The one-step vertical installation design saves labor time on the jobsite, and the bulk jar packaging of 100 pieces keeps crews stocked for larger installation runs without interruption. For contractors installing threaded rod for conduit, cable tray, HVAC, or fire sprinkler support, the 61182J offers a dependable, code-friendly way to speed up overhead work while maintaining strong, corrosion-resistant connections in wood structural members. With a silver 5/8" AF end-drilled head sized for 3/8" threaded rod, the 61182J is easy to identify and install using a standard drill/driver, cutting labor time versus predrilling and setting a separate expansion anchor for every hanger point.

"

Manufacturer Resources

Product Specs

Country Of Origin:
United States
Head Color:
Silver
Head Type:
5/8" AF End-Drilled
Product Finish:
Electro-Zinc
Product Length:
2-1/2 in
Product Material:
Steel
Product Size:
8-Mar
Product Type:
Threaded Rod Anchor
Rod Size:
8-Mar
Department:
Electrical
Product Subgroup:
Electrical Fasteners

Minerallac 61182J – Frequently Asked Questions

1) Can I hang 3/8 inch threaded rod from a wood joist with the Minerallac 61182J Sammys anchor?
That is exactly what it is for. The GST 25-380 screws vertically up into the bottom of a wood structural member, and the end-drilled head is tapped for 3/8 inch threaded rod. One-step install: drive the screw, thread the rod in, no pre-drilled anchor or insert needed.
2) Is this the right Sammys anchor for a steel beam or a concrete deck?
No. The GST 25-380 is a wood-thread version, made to screw into wood framing only. For steel purlins or bar joist you need the steel-thread Sammys style, and for concrete or masonry you need a concrete Sammys or a separate rod-hanging anchor. Using the wood screw in steel or concrete will not hold.
3) What size wrench or socket drives the Minerallac GST 25-380 Sammys?
The head is 5/8 inch across the flats, so a 5/8 inch socket on an impact or a drill adapter drives it. There is no hex key or slot involved, you drive it from the outside of the head.
4) How far does the 61182J Sammys screw penetrate into the wood?
Overall length is 2-1/2 inches, so plan on roughly that much embedment into a nominal 2x or heavier member. It is not intended for thin sheet material or for panel products that cannot develop thread hold over that depth.
5) Is the Minerallac 61182J rated for outdoor or damp locations?
Construction is steel with an electro-zinc finish, which is a light corrosion coating suited to dry interior use. For exterior, high-humidity, or corrosive environments, specify a hot-dip galvanized or stainless rod hanger instead.
6) Do I need a different Sammys if I am hanging rod at an angle instead of straight down?
Yes. The GST 25-380 is the vertical-mount configuration, designed to be driven straight up into the underside of the member. Sideways or angled attachment to a wood member calls for the horizontal-mount Sammys style, which has the drilled head oriented for that pull.
7) Where is the Minerallac 61182J Sammys anchor made?
Made in the United States. That matters on public work and institutional projects where domestic-sourcing language shows up in the specification.
