Square D TeSys Deca DIN-Rail Mounting Plate
The Square D TeSys Deca mounting plate is a motor-starter accessory designed to pair GV2ME motor circuit breakers (or LS1D32 fuse carriers) with LC1D09-D38 contactors so the front faces of the assembled devices line up cleanly on the panel. The plate clips directly onto a standard 35mm DIN-rail, simplifying assembly inside control panels and motor control centers. As part of the Square D TeSys range, this mounting accessory is built for panel builders, OEMs, and electricians assembling compact motor starter combinations.
Key Features
- DIN-Rail Mounting: Clips onto standard 35mm DIN-rail for fast, tool-minimal installation in control panels.
- Aligned Device Faces: Positions the motor circuit breaker and contactor so their front faces are aligned for a clean, compact starter assembly.
- Broad Compatibility: Works with GV2ME, GV2DP, GV2AF4, and GV2DM motor circuit breakers, LS1D32 fuse carriers, and LC1D09-D38 contactors.
- TeSys Deca Range: Part of the Schneider Electric / Square D TeSys Deca and TeSys product range (compatibility code LAD).
- Accessory Category: Classified as a mounting accessory for motor starter assemblies, not a standalone protective device.
Technical Specifications
- Toxic Heavy Metal Free: Yes
- Warranty: 18 months
- Take Back: No
- Tier: 1
- Returnability: Yes
- Warranty Period: 18 months
- Compatibility Code: LAD
- Sustainable Packaging: Yes
- Mercury Free: Yes
- Packaging Without Single Use Plastic: Yes
- Reach Free Shvc: Yes
- Tier Id: 1
- ROHS Eur In Scope: Yes
- Recycled Metal Content At Cr Level: 0 %
- Legacy WEEE Scope: In
- Packaging Made With Recycled Cardboard: Yes
- China ROHS Label: 1
- Serviceability: No
- With Recycled Cardboard: Yes
- WEEE Product Category: 5
- Without Single Use Plastic: Yes
- ROHS Exemption Information: Yes
- Traceability: No
- Device Short Name: LAD
- Reach Free Of Svhc: Yes
- China ROHS In Scope: No
Typical Applications
- Motor Control Centers and Control Panels
- Motor Starter Assembly for GV2ME Circuit Breakers
- Panel Building with LC1D09-D38 Contactors
- Commercial and Industrial Motor Control Installations
- OEM Machine Control Panel Design
Why Square D?
Square D by Schneider Electric engineers TeSys motor control components to align cleanly and mount securely, helping panel builders and electricians assemble compact, reliable motor starter combinations. This mounting plate reflects that standard, giving GV2ME breakers and LC1D09-D38 contactors a consistent DIN-rail mounted, front-aligned fit for professional motor control panels.
Manufacturer Resources
Product Specs
- Product Type:
- DIN Rail Adapter
- Series:
- TeSys Deca
- Connection Type:
- Clip-On DIN-Rail
- Department:
- Electrical
- Product Group:
- Motor Control & Automation
- Product Subgroup:
- DIN Rail & Accessories
Square D LAD31 – Frequently Asked Questions
1) What does the Square D LAD31 mounting plate actually do in a motor starter assembly?
The LAD31 is a mounting plate, not a protective device. It holds a GV2ME motor circuit breaker (or an LS1D32 fuse carrier) together with an LC1D09 through D38 contactor so the front faces of both devices line up on the panel. You still buy the breaker and contactor separately; the plate just sets their relative position and carries the pair on the rail.
2) Will the LAD31 plate clip onto standard 35mm DIN rail?
Yes. The plate is a clip-on DIN-rail part sized for standard 35mm rail, so it snaps on without separate screw mounting to the panel back plate.
3) Which TeSys breakers and contactors is the LAD31 compatible with?
On the breaker side it works with GV2ME, GV2DP, GV2AF4 and GV2DM motor circuit breakers, and with LS1D32 fuse carriers. On the contactor side it covers LC1D09 through LC1D38. Contactors above D38 in the TeSys D range are outside what the plate is stated to pair with.
4) Can I use the LAD31 to mount an Eaton or other brand circuit breaker to DIN rail?
No. The LAD31 is built around Square D / Schneider TeSys geometry (GV2 breakers and LC1D contactors) and carries the LAD compatibility code for that range. For Eaton gear, the Eaton Series G DIN Rail Adapter for GD/GC/GHC frame breakers is the equivalent brand-specific adapter, and the Eaton M22 Modular Pushbutton DIN Rail Mounting Adapter handles M22 pushbutton bodies.
5) Can an Eaton Series G DIN rail adapter be used in place of the Square D LAD31 mounting plate?
No. The LAD31 is a TeSys Deca mounting plate that pairs GV2ME motor circuit breakers (or LS1D32 fuse carriers) with LC1D09-D38 contactors so their front faces align on the panel. The Eaton 1225C79G01 is a DIN rail adapter for Eaton Series G GD, GC and GHC frame circuit breakers, so it adapts a molded-case breaker to rail mounting rather than joining a breaker and contactor into a starter assembly. The two solve different problems and are not interchangeable.
6) I need to DIN-rail mount a pushbutton station, not a motor starter - is the LAD31 the right part?
No. The LAD31 clips onto standard 35mm DIN rail but is built to carry a GV2ME, GV2DP, GV2AF4 or GV2DM motor circuit breaker alongside an LC1D09-D38 contactor. For a modular pushbutton, the Eaton M22-IVS is a DIN rail mounting adapter for M22 pushbutton devices and is rated IP66/NEMA 4X/13. Choose by the device you are mounting.
7) Do I need the LAD31 if I am mounting the GV2 breaker and the contactor separately on the rail?
Not strictly. The plate exists to combine a GV2 breaker with an LC1D contactor as one front-aligned starter block. If you are mounting each device on its own rail position and wiring between them, the plate adds nothing. Use it when you want the compact, face-aligned starter combination inside a control panel or MCC.
8) What exact part number do I order for the TeSys Deca DIN-rail mounting plate?
Order Square D LAD31. It is a single part number with no finish, size, or handing options to specify, and it belongs to the TeSys Deca range.
9) Is the LAD31 plate suitable for OEM machine panels and motor control centers?
That is its intended use. Typical applications are motor control centers, control panels, panel building with LC1D09-D38 contactors, commercial and industrial motor control, and OEM machine control panel design. It is a panel-builder accessory rather than field-service hardware.
10) Is the Square D LAD31 RoHS compliant and free of mercury or heavy metals?
Yes on all three. The LAD31 is in scope for and compliant with European RoHS, and is listed mercury free and toxic heavy metal free. It is also REACH free of SVHC, and ships in recycled cardboard packaging with no single-use plastic. It is made in France.
