Norton Rixson 6300 Series Low Energy Electromechanical Power Operator with WiFi Interface

Intelligent Electromechanical Door Automation Solution

The Norton Rixson 6300 Series Low Energy Power Operator delivers intelligent, electromechanical door automation designed for medium- to high-traffic commercial applications. This advanced operator features a slim 2-3/4" profile design that supports doors up to 250 lbs and widths of 36"-48", with 120 VAC power input and 24VDC output capabilities. ANSI/BHMA A156.19 certified and ADA compliant, this operator combines reliable performance with modern aesthetics for interior and exterior door applications.

Professional Features & Benefits

  • Compact Profile Design: Ultra-slim 2-3/4" height fits applications with limited header space while maintaining full functionality.
  • Heavy-Duty Load Capacity: Supports maximum door weight of 250 lbs with door widths from 36" to 48" for versatile commercial applications.
  • Advanced Power Management: 120 VAC, 3A, 60Hz power input with 24VDC @ 1.3A max output for reliable operation and accessory power.
  • WiFi Programming Interface: Integrated WiFi interface allows programming without building network connection, plus onboard LCD display for easy setup and adjustments.
  • Modular Installation Design: Heavy-duty backplate doubles as mounting template with modular components for simplified one-person installation.
  • Universal Mounting Options: Non-handed design accommodates push or pull side mounting for maximum installation flexibility.
  • Intelligent Control Features: Customizable inputs/outputs support wave-to-open switches, door switches, RF devices, security override, and fire safety integration.
  • Manufacturer Warranty: 2 Year Limited warranty provides confidence and protection for commercial installations.

Technical Specifications

  • ADA Compliant: Yes
  • ANSI/BHMA: ANSI/BHMA A156.19
  • Commercial/Residential: Commercial
  • Delay Function: Yes
  • Department: Door Hardware
  • Duty Level: Heavy Duty
  • Electronic: Yes
  • Hold Open Feature: Yes
  • Product Category: Door Controls
  • Product Group: Door Controls
  • Product Subgroup: Power Operators
  • Product Type: Low Energy Operators
  • Series: 6300 Series
  • Subcategory: Surface Closers
  • Traffic Rating: High Traffic
  • Warranty: 2 Year Limited

Installation & Operation

  1. Verify electrical requirements match available power supply. Confirm 120 VAC, 3A, 60Hz capacity and 24VDC output requirements before proceeding.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
  4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
  5. Configure operational settings including adjustable opening/closing force and customizable inputs/outputs per application requirements.
  6. Restore power and test all functions including normal operation, WiFi interface connectivity, LCD display operation, and integration with connected access control systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Healthcare Institutions
  • Educational Facilities
  • Retail Establishments
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Choose Norton Rixson Quality?

Norton Rixson 6300 Series power operators deliver professional-grade reliability with heavy-duty construction rated for high-traffic commercial applications. UL 10C positive pressure and UL325/991 certified with ANSI/BHMA A156.19 compliance ensures code-compliant performance. 2 Year Limited warranty and modular design with minimal components provide long-term value and simplified maintenance for demanding commercial door automation requirements.

Product Specs

Series:
6300 Series
Duty Level:
Heavy Duty
Warranty:
2 Year Limited
ANSI/BHMA:
ANSI/BHMA A156.19
Product Group:
Door Controls
Product Subgroup:
Power Operators
Product Type:
Low Energy Operators
Subcategory:
Low Energy Operators
Commercial/Residential:
Commercial
Electronic:
Yes
ADA Compliant:
Yes
Traffic Rating:
High Traffic
Delay Function:
Yes
Hold Open Feature:
Yes
Product Category:
Door Controls
Department:
Door Hardware

Norton Rixson 6311 689 – Frequently Asked Questions

1) Does the Norton Rixson 6300 operator meet ADA and the low energy standard for a barrier free entrance?
It's ADA compliant and certified to ANSI/BHMA A156.19, the standard that governs low energy power operated doors. It also carries UL 10C positive pressure and UL325/991 certification. That is the package an inspector looks for on a barrier free entrance in a school, hospital or government building.
2) My door is heavier than the LCN 6440 COMPACT is rated for. What low energy operator should I use instead?
The LCN 6440 and 6440XP COMPACT modules are rated to 185 lb doors. The Norton Rixson 6300 takes doors up to 250 lbs at widths of 36 to 48 inches, so it picks up openings the COMPACT can't drive, and it does it in a 2-3/4 inch high housing if header space was the reason you were looking at a compact unit in the first place.
3) What is the closest equivalent to a Norton Rixson 6300 low energy operator from another manufacturer?
The Norton Rixson 6300 Series is a low energy electromechanical swing door operator that mounts push or pull side and carries ANSI/BHMA A156.19 certification. The closest peers doing the same job are the LCN 9131 Benchmark low-energy electromechanical operator, which is a pull side mount unit, and the LCN 9142 Benchmark, which is the push side mount version of the same family. Because the 6300 is non-handed and offered with pull side rigid arm and slide track, push side double lever arm, or both arm packages together, one 6300 covers the mounting condition that LCN splits across the 9131 and 9142.
4) For an ADA compliant door on a healthcare or school project, which operators meet the requirement?
The Norton Rixson 6300 Series is ADA compliant and certified to ANSI/BHMA A156.19, with UL 10C positive pressure and UL325/991 listings, which is the package a facility spec usually asks for. Among the peers, the LCN 9131 Benchmark low-energy electromechanical automatic door operator is likewise identified with ADA compliance. Both are the type of low energy operator used to standardize across a facility; the 6300 adds a WiFi interface and onboard LCD so settings can be programmed and documented at each door without a building network connection.
5) What are the alternatives to the Norton Rixson 6300 low energy operator?
Several other low energy swing door operators cover the same job. From LCN, the 9131 Benchmark is the pull side mount version and the 9142 Benchmark is the push side, both electromechanical like the 6300. Dormakaba offers the ED50LE, also rated heavy duty, along with the ED100LE and the ED900 in a push side top jamb mount for single door applications. SDC's AUTOP Series is a microprocessor controlled low energy operator, and Cal-Royal's 8600 Series includes obstacle detection. The 6300's differentiators are its 2-3/4 inch profile and the onboard WiFi programming interface.
6) Should I use a low energy operator like the Norton Rixson 6300 or a full automatic operator?
A low energy operator is the right call when the door is activated by a person pressing an actuator or waving at a switch, and it opens slowly enough that no guide rails or presence sensors are required. That is what ANSI/BHMA A156.19 covers and it's how most restroom, vestibule and accessible entrance doors are done. A full power automatic operator is what you want when the door has to open fast on approach for continuous traffic, and it brings the sensor and safety guarding requirements with it. The 6300 is the low energy type.
7) Can I program a Norton Rixson 6300 operator without getting on the building network?
Yes. The 6300 has a built in WiFi interface that lets you program the unit directly, no connection to the building network required, which keeps IT out of the install. There is also an onboard LCD display for setup and adjustment at the door if you'd rather not use a phone or laptop.
8) What can I wire into a Norton Rixson 6300 operator for access control and fire alarm?
The inputs and outputs are customizable and take wave to open switches, door switches, RF devices, a security override, and fire safety integration. So a card reader releasing an electric strike and then triggering the open cycle, plus a fire alarm relay that drops the operator out, is inside what the controller handles. Accessory power comes from the operator's own 24VDC 1.3A output.
9) Can the Norton Rixson 6300 be set to hold the door open, and can I slow the closing down?
Both. The 6300 has a hold open feature and an adjustable delay function, plus adjustable opening and closing force. That combination is what you set for a hospital corridor or a memory care wing where someone needs longer to clear the opening than a standard closer allows.
10) What low energy operator should I use if I want obstacle detection called out on the submittal?
The Cal-Royal 8600 Series low energy automatic swing door operator is specified with obstacle detection, so it is the unit to put on the drawing when that feature has to appear by name. The Norton Rixson 6300 Series is specified instead around its customizable inputs and outputs, which take wave-to-open switches, door switches, RF devices, security override, and fire safety integration, plus an onboard LCD display and WiFi interface for programming without a building network connection.
11) How does the Norton Rixson 6300 compare to the Dormakaba ED50LE for a heavy duty interior opening?
Both are heavy duty rated low energy swing door operators. The Norton Rixson 6300 Series is a heavy duty electromechanical operator rated for high traffic and certified to ANSI/BHMA A156.19, non-handed for push or pull side mounting. The DORMA ED50LE is described as a medium to heavy duty swing door operator in the ED50 Series. The practical difference for a spec is the arm package: the 6300 is ordered with a pull side rigid arm and slide track, a push side double lever arm, or both together, and in lengths of 37-3/8 inch or 39-5/8 inch to suit the frame.
12) Which low energy operator suits an opening that needs to swing past 110 degrees?
The Norton Rixson 6300 Series is ordered in a pull side rigid arm and slide track configuration rated up to 130 degree door swing, and that version is handed - left hand and right hand are separate items, in both the 37-3/8 inch and 39-5/8 inch lengths. That is the configuration to quote for a wide-swing opening. The standard pull side rigid arm and slide track and the push side double lever arm versions are non-handed. Among the peers, the LCN 9131 Benchmark is a pull side mount operator and the DORMA ED900 is a push side top jamb mount unit.
13) What looks like an alternative to the 6300 but is a different kind of unit?
The LCN 6440 COMPACT is an automatic operator module with 24VDC power and touchless access rated for 185 lb doors - a module built around a compact envelope and a lighter leaf, not a like-for-like swap for a 250 lb door. The Norton Rixson 6300 Series runs on 120 VAC, 3A, 60Hz input with 24VDC at 1.3A max output for powering accessories, so it feeds its own auxiliary devices from line voltage. Confirm which power arrangement the opening already has before treating the two as interchangeable.
14) Is there a simpler low energy operator than the 6300 if I do not need the WiFi programming?
The SDC AUTOP Series is a low energy automatic door operator with microprocessor control, and the DORMA ED100LE in the ED100 Series is a low energy swing door operator - both cover the basic automatic swing function. The Norton Rixson 6300 Series carries the additional WiFi interface and onboard LCD display for programming, along with hold open and delay functions and adjustable opening and closing force. If the door only needs to open and close on a switch, the added programming interface is the part of the 6300 you would not be using.
15) We already run LCN 6440XP operators in the building - can we add a Norton Rixson 6300 on a wider door?
Yes, on the doors the 6440XP does not reach. The LCN 6440XP COMPACT automatic door operator is a 24VDC low-energy unit with 185 lb door capacity. The Norton Rixson 6300 Series takes doors up to 250 lbs at 36 to 48 inch widths, so it covers the heavier entry leaves while the compact units stay on the lighter interior doors. Finishes line up across a mixed fleet too - the 6300 comes in 689 Aluminum, 690 Dark Bronze, BSP Black Suede Powder, and WSP White Suede Powder.
16) What finishes does the Norton Rixson 6300 operator cover come in?
Four: 689 aluminum, 690 dark bronze, BSP black suede powder and WSP white suede powder. All four are offered in both the 37-3/8 inch and 39-5/8 inch case lengths and on every arm configuration, so matching a header run across a building doesn't force you into a different arm than the opening needs.
17) Is the Norton Rixson 6300 a one person install?
It's built for it. The heavy duty backplate doubles as the mounting template, so you lay out and hang off the same piece, and the rest of the operator goes on as modules. That takes the two-person lift out of setting the header unit.
18) Is the Norton Rixson 6300 heavy enough for a main entrance that gets hammered all day?
Yes. It's rated heavy duty and high traffic, and it's a commercial only operator, not a light residential unit. Combined with the 250 lb door capacity, that covers a main entrance, a lobby vestibule or a hospital corridor door rather than an occasional use interior opening.
