Norton Rixson 767 Infrared Wave Switch Battery Powered Touchless Door Operator Control

Norton Rixson 767 Infrared Wave Switch Battery Powered Touchless Door Operator Control

(No reviews yet) Write a Review

Model: 767 NOR

In Stock (leaves warehouse same day if ordered before 3pm ET)

$205.97
$147.52
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Norton Rixson 767 Infrared Wave Switch Battery Powered Touchless Door Operator Control

Professional Touchless Door Activation Solution

The Norton Rixson 767 Wave to Open Switch delivers reliable touchless door activation for commercial applications. This single gang battery operated wall switch features infrared sensors with up to 4" detection range and field-configurable bi-color LED status indicators. Compatible with Norton Rixson 5600, 5700, 6000, and 6300 Series operators, this stainless steel switch provides vandal-resistant operation with selectable time delay from 1 to 10 seconds.

Professional Features & Benefits

  • Touchless Operation: Infrared sensors with up to 4" detection range provide hands-free door activation for improved hygiene and accessibility.
  • Battery Powered Design: Self-contained battery operation eliminates wiring requirements for flexible installation locations.
  • Vandal-Resistant Construction: Stainless steel face plate with robust single gang design withstands heavy use in commercial environments.
  • Visual Status Feedback: Field-configurable bi-color (red/green) LED status indicators provide clear operational feedback to users.
  • Adjustable Timing: Selectable time delay from 1 to 10 seconds allows customization for specific application requirements.
  • Wide Operator Compatibility: Works with Norton Rixson 5600, 5700, 6000, and 6300 Series operators for versatile installation options.
  • Professional Installation: Standard single gang mounting fits existing electrical boxes for straightforward installation.

Technical Specifications

  • Commercial/Residential: Commercial
  • Compatibilty: All Low Energy Operators Except 5800
  • Department: Door Hardware
  • Electronic: Yes
  • Product Category: Electronic Access Controls
  • Product Group: Electronic Access Controls
  • Product Subgroup: Sensors, Switches, Relays and Timers
  • Product Type: Touchless Switches
  • Subcategory: Accessories

Installation & Operation

  1. Verify compatibility with existing Norton Rixson door operator system before installation.
  2. Install battery per manufacturer instructions and verify power indicator operation.
  3. Mount the switch in standard single gang electrical box at appropriate height for user access.
  4. Configure LED status indicators (red/green) and time delay settings (1-10 seconds) per application requirements.
  5. Connect control wiring to compatible door operator following manufacturer wiring diagrams.
  6. Test touchless activation at various distances within the 4" detection range and verify proper door operation.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete installation specifications and battery maintenance requirements.

Professional Applications

  • Healthcare Facility Access Control
  • Commercial Building Accessibility
  • Educational Institution Safety Systems
  • Retail Establishment Entry Points
  • Industrial Facility Clean Rooms
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties

Why Choose Norton Rixson Quality?

Norton Rixson touchless switches deliver professional-grade reliability with stainless steel construction and vandal-resistant design engineered for demanding commercial applications. The battery-powered operation and infrared sensor technology provide dependable hands-free access control where hygiene and accessibility are essential.

Manufacturer Resources

Norton Rixson Warranty

Product Specs

Product Group:
Electronic Access Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Type:
Touchless Switches
Subcategory:
Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Compatibility:
All Low Energy Operators Except 5800
Product Category:
Electronic Access Controls
Department:
Door Hardware

Norton Rixson 767 NOR – Frequently Asked Questions

1) Will the Norton Rixson 767 wave switch work with my Norton low energy door operator?
The 767 works with all Norton Rixson low energy operators except the 5800. That covers the 5600, 5700, 6000, and 6300 Series. If the opening is running a 5800, this switch is not the actuator for it.
2) Does the Norton Rixson 767 touchless switch need to be wired for power?
No power wiring to the switch. The 767 runs on its own battery, so you do not need to pull power to the switch location, which is what makes it workable on a masonry wall or a spot with no circuit nearby. You still run control wiring from the switch to the door operator per the operator's wiring diagram.
3) How close do you have to get to the Norton Rixson 767 wave switch for it to activate the door?
Up to 4 inches. The 767's infrared sensor is a short-range wave sensor, not a room presence detector, so a user waves a hand right at the plate. That short range is deliberate: it keeps passing foot traffic and carts from tripping the operator. If you want activation from several feet out, you want a long-range motion sensor instead, not this switch.
4) What is a comparable touchless wave switch from another manufacturer if the Norton Rixson 767 is not the right fit for an opening?
The MS Sedco 216 Series is an infrared touchless switch built for the same job of activating an automatic door without contact. The Norton Rixson 767 is an infrared wave switch with up to 4 inch detection range, battery powered in a single gang stainless steel plate, and it is specified for all Norton Rixson low energy operators except the 5800. The 216 Series is described for automatic door activation generally rather than tied to the Norton Rixson operator line, so on a job where the operator is a different make, the MS Sedco unit is the one to price out. Both are activated by a hand passing the sensor; the difference to confirm before ordering is which operator the actuator has to talk to and how the switch is powered at that location.
5) Which touchless actuator should be specified when the submittal calls out ADA compliant operation?
The MS Sedco NexGen IR touchless actuator switch is described with active infrared detection and ADA compliant operation, so it is the one to put on a submittal that names ADA compliance for the actuator itself. The Norton Rixson 767 uses infrared sensors with up to 4 inch detection range, field configurable bi-color red and green LED status indicators, and a selectable time delay from 1 to 10 seconds, which is the setting that governs how long the operator holds the door open after activation. For an institutional buyer standardizing across a facility, the practical split is whether the compliance language has to appear on the actuator line item or whether it is carried by the operator and the hold-open time behind it.
6) What electrical box does the Norton Rixson 767 wave switch mount in?
Standard single gang. The 767 is a single gang plate, so it drops into an existing single gang box at whatever height you set for user access. No proprietary back box to order.
7) Can you adjust how long the door stays open with the Norton Rixson 767 switch?
The 767 has a selectable time delay from 1 to 10 seconds, set at the switch. Short end for a high traffic retail or office entry, long end where you have wheelchair or cart traffic that needs more time through the opening.
8) Is the Norton Rixson 767 wave switch tough enough for a school or hospital corridor?
It is built for commercial duty: stainless steel face plate on a vandal-resistant single gang body, and because it is touchless there is no button or moving part to wear out or be pried. That is the reason it shows up in healthcare, education, and government openings.
9) What are the alternatives to the Norton Rixson 767 for touchless door activation?
Two other touchless actuators ZenSupply carries are the MS Sedco 216 Series infrared touchless switch and the MS Sedco NexGen IR touchless actuator. Both are infrared activation like the 767. The difference that usually decides it is the operator: the 767 is a Norton Rixson switch matched to Norton Rixson low energy operators, so on a Norton opening it is the same-brand part. If you are activating a different manufacturer's operator, look at the MS Sedco units.
10) Will one Norton Rixson 767 wave switch operate the door from both sides?
No. A 767 is a single actuator at one location, so a door that needs push-side and pull-side activation takes two of them, each wired back to the operator. Same thing on a vestibule with an interior and exterior approach. Count your approach points, not your doors.
11) Is an MS Sedco infrared switch a drop-in replacement for a Norton Rixson 767 on an existing Norton Rixson operator?
Treat it as a specification change, not a like-for-like swap. The Norton Rixson 767 is called out for all Norton Rixson low energy operators except the 5800, and it is battery powered in a single gang box, so it carries no supply wiring back to the operator. The MS Sedco 216 Series and the MS Sedco NexGen IR are infrared touchless actuators for automatic door activation, and either one has to be matched to the operator's actuation input and to the power arrangement at the wall box before it goes on the order. On a retrofit where the existing box has no line power run to it, the battery powered 767 keeps the box as is; where a powered actuator is acceptable, the MS Sedco units widen the choice beyond the Norton Rixson operator line.
12) What do the red and green lights on the Norton Rixson 767 switch mean?
The 767 carries a bi-color red/green LED status indicator, and it is field configurable, so you set which state reads which color when you commission it. It gives the user visual confirmation the wave registered rather than leaving them waving twice at a door that has not moved.
13) For a high traffic commercial entrance that takes abuse, what separates the Norton Rixson 767 from the other infrared actuators on the market?
The Norton Rixson 767 uses a stainless steel face plate on a single gang body and is described as vandal resistant for heavy commercial use, with bi-color red and green LED status indicators that tell a user the switch registered the wave. It is a commercial rated device. The MS Sedco 216 Series and the MS Sedco NexGen IR are also infrared touchless switches for automatic door activation, so for a property manager standardizing entries across a portfolio the decision comes down to the plate material and mounting the buildings already use, the operator brand behind each door, and whether the openings can support battery service or need a powered actuator.
