Nuts 5/8-11 Hx Nut St-zn (Jar 25)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Division:
- Electrical H1
- Fastener Head Width:
- 0.922 - 0.938 in.
- Fastener Height:
- 0.535 - 0.559
- Fastener Width:
- 0.535 - 0.559
- Field Application:
- Electrical, Plumbing, Heating and Air Conditioning Industries
- Grade:
- 2
- Hardness:
- Rockwell B68-C32
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Nut_Domestic_Gr_2_Gr_5_Gr_8_Gal_18-8_SS_316_SS.pdf
- Order Minimum Imperial:
- 25
- Order Minimum Uom Imperial:
- EA
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 3.6 in
- Product Length:
- 3 in
- Product Weight:
- 1.81 lbs
- Product Width:
- 3 in
- Sub Division:
- Electrical-E H2
- Thread Per Inch:
- 11
- Thread Standard:
- ASME B18.2.2
- Department:
- Electrical
- Product Subgroup:
- Nuts
- Product Type:
- Hexagonal Nut
- Type2:
- Hexagonal Nut
- Series:
- JN
- Product Finish:
- Zinc
- Product Details:
- Hexagonal Nut
- Product Material:
- Steel
Metallics JN167 – Frequently Asked Questions
1) Is the JN167 hex nut strong enough to pair with Grade 5 or Grade 8 bolts?
No. The JN167 is a Grade 2 steel nut, hardness Rockwell B68 to C32. Grade 2 is the general-purpose strength class and is intended to be matched with Grade 2 rod or bolts. If your drawing calls for Grade 5 or Grade 8 fasteners, the nut has to match that grade or it becomes the weak link in the joint.
2) Will these nuts qualify on a Buy American or ARRA funded job?
No. The JN167 is not Buy American compliant and is not ARRA compliant, with country of origin listed as multiple. On federally funded work with domestic sourcing requirements you will need a domestic-origin hex nut instead.
3) What wrench or socket size does the Metallics JN167 5/8-11 nut take?
Across the flats the nut measures 0.922 to 0.938 inch, so a 15/16 inch wrench or socket is the fit. Nut thickness runs 0.535 to 0.559 inch, which matters when you are stacking a nut and washer under limited rod projection.
4) Can these zinc plated hex nuts be used outdoors or in a damp mechanical room?
The JN167 is zinc plated steel. Zinc plating handles indoor and sheltered conditions and light moisture, but it is not a marine or chronically wet finish. For rooftop, coastal, or continuously wet locations, specify stainless or hot dip galvanized nuts instead.
5) Do Metallics JN167 nuts meet a dimensional standard for submittals?
Yes. The JN167 is made to ASME B18.2.2, the standard governing hex nut dimensions, so the across-flats and thickness figures line up with any spec calling out a B18.2.2 5/8-11 hex nut.
6) How many nuts come in a jar of Metallics JN167?
They ship 25 to a jar, and 25 each is also the order minimum. The jar packaging keeps them together on a cart or in a gang box rather than loose in a tray.
