Nuts M24 Hx Nut St-zn (Jar 100)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Dimensional Standard:
- DIN 934
- Division:
- Electrical H1
- Fastener Head Width:
- 35 - 36 in.
- Fastener Height:
- 17.7 - 19
- Hardness:
- Vickers HV 170-302 (Rockwell B85-C30)
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Metric_Nut_Steel-Zinc_18-8_SS_316_SS.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 5.75 in
- Product Length:
- 3.5 in
- Product Weight:
- 5.22 lbs
- Product Width:
- 3.5 in
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Nuts
- Product Type:
- Metric Hexagonal Nut
- Type2:
- Metric Hexagonal Nut
- Series:
- JNM
- Product Finish:
- Zinc
- Product Details:
- Metric Hexagonal Nut
- Product Material:
- Steel
Metallics JNM024 – Frequently Asked Questions
1) Will the Metallics JNM024 M24 nut thread onto a standard metric M24 bolt?
Yes. The JNM024 is an M24 hex nut built to DIN 934, which is the standard metric coarse-thread hex nut spec, so it mates with standard M24 coarse-pitch bolts, studs, and threaded rod. If your rod or bolt is a fine-pitch M24, this is not the nut for it.
2) Does the Metallics JNM024 hex nut qualify for a Buy American or ARRA job?
The JNM024 is flagged ARRA compliant and Buy American compliant in the manufacturer data, with country of origin China. On federally funded work, verify which clause your contract actually invokes, since the compliance flag and the origin need to be read together by your project's specification.
3) Is the M24 Metallics hex nut plated for indoor electrical work or bare steel?
Steel with a zinc finish. Zinc plating handles dry indoor and protected electrical applications such as strut, enclosure, and rack hardware. For wet, washdown, or coastal exposure, go to a stainless hex nut instead, since zinc plating on steel will eventually rust in standing moisture.
4) How many M24 nuts come in a jar of Metallics JNM024, and can I buy fewer?
The JNM024 ships as a jar of 100 nuts, and 100 count is the order minimum, so the jar is the smallest unit. Metallics does offer other sizes and quantities by request. A full jar weighs 5.22 lbs.
5) What wrench or socket size do I need for an M24 DIN 934 hex nut?
The nut height runs 17.7 to 19, per the published fastener dimensions, and the hex is sized to DIN 934 for M24. Bring a 36 mm socket or wrench, which is the across-flats size DIN 934 specifies at M24. Deep sockets help where the nut sits on long threaded rod.
6) Is this M24 nut hard enough to torque down on structural or hanger applications?
Hardness is Vickers HV 170-302, which converts to Rockwell B85 to C30. That is a general-purpose carbon steel nut range suited to strut, hanger rod, and equipment mounting. If your drawing calls out a specific property class nut for a structural bolted connection, match that callout rather than substituting a general hex nut.
7) How much shelf or bin space does a jar of Metallics M24 nuts take up?
The jar measures 5.75 in high by 3.5 in by 3.5 in and weighs 5.22 lbs loaded, so it drops into a standard parts bin or van shelf without repacking. Useful if you are standardizing MRO stock across a facility and want the fastener kept in its labeled container.
