OATEY 42192 1-1/2 in. 151 Cast...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$118.57
$68.57
OATEY 42192 1-1/2 in. 151 Cast Iron with 1-1/2 in. NPT Connection

OATEY 42192 1-1/2 in. 151 Cast Iron with 1-1/2 in. NPT Connection

(No reviews yet) Write a Review

Model: 42192
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$118.57
$68.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
1-1/2 in. 151 Cast Iron with 1-1/2 in. NPT Connection

  • Features

    • Crown ring set is removable for cleaning the drain line
    • Shower floor drain made with durable cast iron construction
    • Use over the outlet of a drainage pipe
    • Compatible with cast iron pipe
    • Cast-iron drain body with female pipe thread
    • Drain for use with tile and marble shower bases
    • Includes 3-1/4 in. stainless steel crown ring set that screws into the drain top
    • Cast-iron pipe is secured to drain body with 1-1/2 in. NPT connection
    • For shower bases where a hot mop membrane is required
    • Low-profile design allows for installation in tight spaces
    • Packaged with 3-1/4 in. Dia stainless steel strainer


42192 - spec sheet

Manufacturer Resources

Product Specs

Drain Orientation:
Shower
Volume:
0.058
Department:
Plumbing
Product Group:
Plumbing
Product Subgroup:
Fittings
Product Type:
Metal Fittings
Product Finish:
Stainless Steel
Product Material:
Cast Iron
Product Weight:
4.25

OATEY 42192 – Frequently Asked Questions

1) How does the Oatey 42192 shower drain connect to the waste pipe?
The Oatey 42192 drain body is cast iron with a female 1-1/2 inch NPT thread, so the pipe threads directly into the drain body. It is meant for use with cast iron pipe, set over the outlet of the drainage line. If your rough-in is 2 inch pipe or you are working in solvent-weld PVC or ABS, this is not the drain for that opening.
2) Will the Oatey 42192 work with a hot mop shower pan?
That is exactly what it is built for. The 151 cast iron drain is intended for tile and marble shower bases where a hot mop membrane is required, so it suits a mud-set shower floor rather than a prefabricated acrylic or fiberglass base with a molded drain opening.
3) What size strainer comes with the Oatey 42192 cast iron shower drain?
A 3-1/4 inch diameter stainless steel crown ring and strainer set ships with the drain and screws into the drain top. The ring comes back out for rodding or cleaning the drain line, which matters on multi-family and hospitality floors where hair blockages are routine maintenance.
4) Can this drain be installed where the floor structure is shallow?
The 42192 uses a low-profile body specifically so it can go into tight spaces, which helps on slab work or retrofits where there is little depth between the finished shower floor and the framing below. Depth still has to accommodate the 1-1/2 inch NPT pipe entering the body.
5) Is a cast iron shower drain worth it over a plastic one for commercial work?
Cast iron body with a stainless top is the durable combination for high-traffic showers, gyms, dorms, and hotel bathrooms, and it is the correct pairing when the waste line itself is cast iron. Plastic drains are for PVC or ABS systems and lighter-duty residential use. The 42192 weighs about 4.25 lbs, which tells you it is a full cast body rather than a thin shell.
6) Do I need to buy the strainer separately for this Oatey drain?
No. The 3-1/4 inch stainless steel strainer and crown ring set are packaged with the drain body. What you supply is the cast iron pipe and the threaded connection into the 1-1/2 inch NPT body, plus the mop membrane and mortar bed for the shower floor.
7) What is the Oatey part number for the 1-1/2 inch 151 cast iron shower drain?
Order it as Oatey 42192. That is the 151 series cast iron shower drain with the 1-1/2 inch NPT female connection and the 3-1/4 inch stainless crown ring set included.
