Pamex DD05-10 Adjustable Ball Catch with Round Corner Faceplate and Strike

Bore a 7/8 inch diameter hole, 1-1/8 inches deep, into the top edge of the door. The DD05-10 body drops into that hole and the 13/16 inch diameter bullet sits proud to engage the strike. Drill the hole deep enough for the full 1-1/8 inches or the catch will stand high and hold the door off the stop.

The strike is a full lip round corner plate measuring 1-3/8 x 2-1/4 inches, so mortise the frame stop for that footprint. Round corner means it drops straight into a prep cut with a router and a corner radius, no squaring off with a chisel.

The DD05-10 is a residential grade catch. Use it on closet, pantry, and interior passage doors in a home or an apartment unit. For a commercial corridor or any door on a traffic path or a fire rated opening, a ball catch is the wrong part entirely, you want a latching lockset or a closer and latch.

Yes, the DD05-10 is an adjustable ball catch, so the bullet tension can be set after install rather than being fixed at the factory. That is what you want on a closet or pantry door that either drifts open or takes two hands to pull free.

Everything for one door comes in the box: the ball catch body, the 1-3/8 x 2-1/4 inch round corner full lip strike, and four screws. Nothing else to order to hang one door.

Six finishes, all standard BHMA numbers so they match across brands: 605 bright brass, 609 antique brass, 613 oil rubbed bronze, 619 satin nickel, 622 matte black, and 625 polished chrome. If you are standardizing a building, order by the number rather than the name, 619 on this catch matches 619 on your hinges and levers.

The Pamex DD05-10 has a faceplate, so it mortises flush into the door edge and gives a finished look plus screw holding into the mortise. A drive-in catch, like the Delaney Drive-In Ball Catch or the Orca Hardware 70DR Series, has no plate and taps straight into the bored hole, which is faster and leaves nothing to rout. Faceplate for visible work and doors that get pulled hard, drive-in when you are doing volume and the top edge is out of sight anyway.

Only if the door has a solid top rail deep enough to take a 7/8 inch bore at 1-1/8 inches deep. Most hollow core doors have a stile and rail frame of about that depth, so it usually works, but check the rail before you drill. If the bit breaks into the void, the catch has nothing to hold and you need a surface mounted roller or magnetic catch instead.

The Pamex DD05-10 ships complete with a 1-3/8 inch by 2-1/4 inch round corner full lip strike and four screws, so the strike is in the box. The Orca Hardware 70DR Series is also furnished as a ball catch with a radius strike. Both give you the rounded-corner strike profile that matches a router-cut mortise in the door frame; the Orca 70DR is the drive-in body style, while the DD05-10 is the adjustable body with its own faceplate.

Both are door ball catches for holding an inactive or closet door closed at the top or edge, so they fill the same role in an opening. The Pamex DD05-10 is the adjustable type with a 13/16 inch diameter bullet, a 7/8 inch by 1-1/8 inch deep bore, and a round corner full lip strike included, and it is offered in six finishes including 605 bright brass, 613 oil rubbed bronze, and 625 polished chrome. Confirm the Emtek 8802 bore and strike prep against the mortise already cut in your door before swapping, since the two are different bodies rather than a drop-in exchange.

The Pamex DD05-10 is a residential-duty ball catch with an adjustable bullet, so tension can be dialed in after the door hangs and settles - useful on a pair of French doors where the inactive leaf needs to hold without being fought open. The Delaney 4201 is a drive-in ball catch, a fixed press-in body with no faceplate to mortise, which is the faster prep on a new closet door. Match the choice to the prep in the door edge: an existing mortise takes the DD05-10 faceplate, a bare 7/8 inch bore takes the drive-in.

Strike corner style is the thing to match. The Orca Hardware 70DR Series drive in ball catch ships with a radius strike, so the corner profile reads the same in the opening. The Emtek 8802 door ball catch is another option in the same family. If your existing prep is a square corner mortise, a round corner plate will leave gaps at the corners and you will be chiseling.
