Panduit PNF14-6LF-M Pan-Term PNF14-6LF-M Fork Terminal, Funnel, Blue, Nylon, 14-16 AWG, #6 Stud

Panduit Pan-Term Locking Fork Terminal 14-16 AWG #6 Stud Blue Nylon Insulated

(No reviews yet) Write a Review

Model: PNF14-6LF-M
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$375.77
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit Pan-Term Locking Fork Terminal 14-16 AWG #6 Stud Blue Nylon Insulated

Professional electrical connection solution with secure locking design

The Panduit Pan-Term Locking Fork Terminal delivers reliable electrical connections for 14-16 AWG conductors with #6 stud compatibility. Featuring blue nylon insulation and tin-plated copper construction, this terminal provides secure connections with funnel entry barrel design for easy wire insertion. UL Listed and CSA Certified for professional electrical applications requiring dependable performance up to 600V and 105�C operating temperature.

Professional Features & Benefits

  • 14-16 AWG Wire Range: Accommodates standard conductor sizes for versatile electrical connection applications
  • Locking Fork Design: Provides secure mechanical connection that resists vibration and maintains reliable contact
  • 600V Maximum Voltage Rating: Suitable for commercial and industrial electrical systems with high voltage requirements
  • Tin-Plated Copper Construction: Ensures excellent conductivity and corrosion resistance for long-term reliability
  • 105�C Operating Temperature: Maintains performance in high-temperature environments and demanding applications
  • UL Listed & CSA Certified: Meets rigorous safety standards for professional electrical installations
  • Funnel Entry Barrel: Simplifies wire insertion and reduces installation time while ensuring proper connection

Technical Specifications

  • Arra Compliant: Y
  • Barrel Length In: 0.32
  • Barrel Length Mm: 8.3
  • Barrel Type: Funnel Entry
  • Base Material: Copper
  • California Pro65 Cancer: No
  • Color Code: Blue
  • Country Of Origin: Mexico
  • Ean: 74983810376
  • Finish Coating: Tin-Plated
  • Flammability Rating: UL94-HB
  • For Use With: CT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)
  • Fork Type: Locking Fork
  • Gtin Package: 74983810376
  • Hazardous Material Flag: N
  • Inside Diameter In: 0.08
  • Inside Diameter Mm: 2
  • Insulation Material: Nylon
  • Insulation Type: Nylon
  • Maximum Copper Conductor Size Awg: 14
  • Maximum Copper Conductor Size Awg Sol: 14
  • Maximum Copper Conductor Size Awg Str: 14
  • Maximum Metric Conductor Size Mm: 2.5
  • Maximum Operating Temperature C: 105
  • Maximum Operating Temperature F: 221
  • Maximum Voltage Kv: 0.6
  • Maximum Voltage V: 600
  • Maximum Wire Insulation Diameter In: 0.162
  • Maximum Wire Insulation Diameter Mm: 4.1
  • Maximum Wire Size Awg: 14
  • Mercury Content Indicator: N
  • Min Order Qty: 1,000.00
  • Minimum Copper Conductor Size Awg: 16
  • Minimum Copper Conductor Size Awg Sol: 16
  • Minimum Copper Conductor Size Awg Str: 16
  • Minimum Metric Conductor Size Mm: 1.5
  • Minimum Wire Size Awg: 16
  • Outer Diameter In: 0.16
  • Outer Diameter Mm: 4.1
  • Overall Length In: 0.87
  • Overall Length Mm: 22.1
  • Overall Width In: 0.25
  • Overall Width Mm: 6.4
  • Packaging Type: Box
  • Pallet Quantity: 864,000
  • Pallet Volume: 0
  • Pallet Weight: 2,030.40
  • Product Segment: IEI
  • Product Type: Locking Fork Terminal
  • Reach Status: N
  • Rohs Compliant: Compliant
  • Seam Type: Butted
  • Standard Carton Volume Ft3: 0
  • Standard Carton Weight Pounds: 0
  • Standard Package Volume Ft3: 0.0468
  • Standard Package Weight Pounds: 2.35
  • Std Ctn Qty: 0
  • Std Package Height In: 3.4
  • Std Package Height Mm: 86.36
  • Std Package Length In: 7.15
  • Std Package Length Mm: 181.61
  • Std Package Width In: 3.35
  • Std Package Width Mm: 85.09
  • Std Pkg Qty: 1000
  • Std Pkg Uom: Piece
  • Stud Hole Size In: #6
  • Stud Hole Size Mm: 3.5
  • Stud Size: #6
  • Tongue Length In: 0.55
  • Tongue Length Mm: 13.8
  • Tongue Thickness In: 0.03
  • Tongue Thickness Mm: 0.8
  • Tongue Width In: 0.25
  • Tongue Width Mm: 6.4
  • Wire Strip Length In: Jul-32
  • Wire Strip Length Mm: 5.6

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Commercial Electrical Systems
  • Industrial Control Panels
  • Motor Control Centers
  • Distribution Equipment
  • Electrical Maintenance & Repair
  • Professional Electrical Installations

Why Choose Panduit Quality?

Panduit Pan-Term terminals deliver proven reliability with UL Listed and CSA Certified performance standards. The tin-plated copper construction and nylon insulation provide long-term durability in demanding electrical environments, while RoHS compliance ensures environmental responsibility for professional installations.

Manufacturer Resources

Product Specs

Arra Compliant:
Y
Barrel Length In :
0.32
Barrel Length Mm :
8.3
Barrel Type:
Funnel Entry
Base Material:
Copper
California Pro65 Cancer:
No
Color Code:
Blue
Country Of Origin:
Mexico
Ean:
74983810376
Finish Coating:
Tin-Plated
Flammability Rating:
UL94-HB
For Use With:
CT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)
Fork Type:
Locking Fork
Gtin Package:
74983810376
Hazardous Material Flag:
N
Inside Diameter In :
0.08
Inside Diameter Mm :
2
Insulation Material:
Nylon
Insulation Type:
Nylon
Maximum Copper Conductor Size Awg :
14
Maximum Copper Conductor Size Awg Sol :
14
Maximum Copper Conductor Size Awg Str :
14
Maximum Metric Conductor Size Mm :
2.5
Maximum Operating Temperature C :
105
Maximum Operating Temperature F :
221
Maximum Voltage Kv :
0.6
Maximum Voltage V :
600
Maximum Wire Insulation Diameter In :
0.162
Maximum Wire Insulation Diameter Mm :
4.1
Maximum Wire Size Awg :
14
Mercury Content Indicator:
N
Min Order Qty:
1,000.00
Minimum Copper Conductor Size Awg :
16
Minimum Copper Conductor Size Awg Sol :
16
Minimum Copper Conductor Size Awg Str :
16
Minimum Metric Conductor Size Mm :
1.5
Minimum Wire Size Awg :
16
Outer Diameter In :
0.16
Outer Diameter Mm :
4.1
Overall Length In :
0.87
Overall Length Mm :
22.1
Overall Width In :
0.25
Overall Width Mm :
6.4
Packaging Type:
Box
Pallet Quantity:
864,000
Pallet Volume:
0
Pallet Weight:
2,030.40
Product Segment:
IEI
Product Type:
Locking Fork Terminal
Reach Status:
N
Rohs Compliant:
Compliant
Seam Type:
Butted
Standard Carton Volume Ft3:
0
Standard Carton Weight Pounds:
0
Standard Package Volume Ft3:
0.0468
Standard Package Weight Pounds:
2.35
Std Ctn Qty:
0
Std Package Height In:
3.4
Std Package Height Mm:
86.36
Std Package Length In:
7.15
Std Package Length Mm:
181.61
Std Package Width In:
3.35
Std Package Width Mm:
85.09
Std Pkg Qty :
1000
Std Pkg Uom:
Piece
Stud Hole Size In :
#6
Stud Hole Size Mm :
3.5
Stud Size:
#6
Tongue Length In :
0.55
Tongue Length Mm :
13.8
Tongue Thickness In :
0.03
Tongue Thickness Mm :
0.8
Tongue Width In :
0.25
Tongue Width Mm :
6.4
Wire Strip Length In :
Jul-32
Wire Strip Length Mm :
5.6
