Panduit Pan-Lug™ LCD500 Series Two-Hole Copper Compression Lug

Panduit Pan-Lug™ LCD500 Series Two-Hole Copper Compression Lug

(No reviews yet) Write a Review

Model: LCD500-12-6

In Stock (leaves warehouse same day if ordered before 3pm ET)

$5,093.11
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit Pan-Lug™ LCD500 Series Two-Hole Copper Compression Lug

The Panduit Pan-Lug™ LCD500 Series Two-Hole Copper Compression Lug is a standard barrel compression connector engineered to terminate 500 kcmil copper cable in industrial and commercial power distribution systems. Built with a 1/2" stud hole and 1.75" hole spacing to NEMA-standard sizing, this two-hole lug provides a secure, code-compliant termination for high-ampacity copper conductors. The tin-plated copper barrel, beveled entry, and inspection window support reliable, verifiable crimp connections, and the lug is rated for use up to 35kV with a 90°C temperature rating.

Key Features

  • Cable & Hole Sizing: Accepts 500 kcmil copper conductor with a 1/2" stud hole and 1.75" hole spacing per NEMA hole sizes and spacing standards.
  • Durable Construction: Copper base material with a tin-plated finish (color code brown) for enhanced corrosion resistance and long-term conductivity.
  • Two-Hole Standard Barrel Design: Beveled barrel entry eases conductor insertion, and the built-in inspection window allows visual verification of proper conductor seating before and after crimping.
  • Precision Dimensions: Barrel length of 1.75" (44.5mm), tongue thickness of 0.22" (5.6mm), tongue width of 1.54", straight tongue angle, and a recommended wire strip length of 1-13/16".
  • Voltage & Temperature Rating: Maximum voltage rating of 35kV with a 90°C CSA/UL temperature rating for demanding electrical environments.
  • Packaging: Supplied 6 pieces per package for professional electrical and utility installations.

Certifications & Compliance

  • CSA Certified to C22.2 No. 65-13
  • UL Listed to 486A-486B, File #E52164
  • NEBS Level 3 Compliant

Technical Specifications

  • CSA Temperature Rating (°C): 90
  • UL Temperature Rating (°C): 90
  • Maximum Voltage (kV): 35
  • Stud Hole Size (In.): 1/2
  • Inspection Window: Yes
  • Tongue Thickness (mm): 5.6
  • Overall Length (mm): 136.4
  • Product Segment: IEI
  • T & B Die Index Number: 87
  • UOM EA PK: PK
  • Std Package Width In: 3.4
  • Std Package Width MM: 86.36
  • Std Package Height In: 3.35
  • Lead Content Indicator: N
  • Mercury Content Indicator: N
  • REACH Status: N
  • California Pro65 Cancer: No
  • Country of Origin: Mexico
  • Product Type: Compression Lug

Typical Applications

  • Switchgear and Panelboard Cable Terminations
  • Grounding and Bonding Connections
  • Industrial Power Distribution Systems
  • Utility and Substation Cable Terminations
  • Commercial and Institutional Electrical Installations

Why Panduit?

Panduit's Pan-Lug™ compression connectors are built from copper for dependable conductivity, tin-plated for corrosion resistance, and backed by CSA certification and UL Listing to 486A-486B along with NEBS Level 3 compliance. The precise NEMA-standard hole sizing and inspection window help electrical professionals achieve consistent, verifiable, code-compliant terminations on critical 500 kcmil copper cable runs.

Manufacturer Resources

Product Specs

Barrel Length (In.):
1.75
Standard Package Volume Ft3:
0.0528
Standard Package Weight Pounds:
3.6000
Std. Pkg. UOM:
Piece
Tongue Thickness (In.):
0.22
CSA Temperature Rating (°C):
90
Barrel Entry:
Beveled
Inspection Window:
Yes
Standard Carton Volume Ft3:
0.0000
Color Code:
Brown
Lead Content Indicator:
N
Mercury Content Indicator:
N
Std Package Length MM:
196.85
Sub Brand:
Pan-Lug™
Stud Hole Spacing (In.):
1.75
Wire Strip Length (In.):
1-13/16
Stud Hole Size (mm):
12.7
Tongue Thickness (mm):
5.6
Product Segment:
IEI
Standard Carton Weight Pounds:
0.0000
Min Order Qty:
1.0000
GTIN Package:
00074983901067
T & B Die Index Number:
87
UOM EA PK:
PK
Barrel Length (mm):
44.5
Pallet Volume:
0.000000
Std Package Width In:
3.4
Any Reason Not to Sell:
N
Barrel Type:
Standard
Stud Hole Spacing (mm):
44.5
Tongue Width (In.):
1.54
Copper Conductor Size:
500 kcmil
Tongue Angle:
Straight
REACH Status:
N
Base Material:
Copper
California Pro65 Cancer:
No
Std Package Length In:
7.75
Maximum Voltage (kV):
35
Finish/Coating:
Tin-Plated
Overall Length (mm):
136.4
UL Temperature Rating (°C):
90
Country of Origin:
Mexico
Std Ctn Qty:
0
Stud Hole Size (In.):
1/2
Product Type:
Compression Lug
Std Package Width MM:
86.36
Pallet Quantity:
0
Std Package Height In:
3.35
Department:
Electrical
Product Group:
Wiring Devices
