Pass & Seymour 691TR Combination Toggle Switch and Tamper-Resistant Receptacle

Pass & Seymour 691TR Combination Toggle Switch and Tamper-Resistant Receptacle

(No reviews yet) Write a Review

Model: 691TRI

In Stock (leaves warehouse same day if ordered before 3pm ET)

$23.17
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour 691TRW 15A 120V/125V Combination Toggle Switch & Tamper-Resistant Receptacle, White

The Pass & Seymour 691TRW is a 15A 120V/125V combination device that pairs a single-pole toggle switch with a tamper-resistant single receptacle in one white thermoplastic unit. Built to fit two devices into the space of one, it's ideal for wiring layouts where box space is limited but a switch and a protected outlet are both required. The receptacle's dual mechanical shutter system helps prevent insertion of foreign objects, and the device is cULus Listed for use in residential and commercial electrical systems.

Key Features

  • Combination Design: Single-pole toggle switch and tamper-resistant single receptacle combined into one device, fitting two functions into the space of one.
  • Durable Construction: White thermoplastic housing with a satin finish for a clean, consistent appearance.
  • Break-Off Feed Tab: Easily accessible break-off tab allows the switch and receptacle to be wired on a separate or common feed.
  • Tamper-Resistant Protection: Dual mechanical shutter system on the receptacle helps prevent insertion of foreign objects.
  • Electrical Rating: Rated 15A 120V/125V for standard residential and commercial branch circuits.
  • Power Contacts: One-piece heat-treated triple-wipe brass power contacts for a secure, long-lasting connection.
  • Code-Compliant Grounding: Grounding combination device meets NEC requirements.

Certifications & Compliance

  • cULus Listed

Technical Specifications

  • Country Of Origin: Mexico
  • Product Finish: Satin
  • Product Height: 4.06 in
  • Product Line: Pass & Seymour
  • Product Material: Thermoplastic
  • Product Width: 1.32 in
  • Product Depth: 1.15 in

Typical Applications

  • Residential and Commercial Wiring Devices
  • Combination Switch and Outlet Installations
  • Space-Constrained Electrical Boxes and Gangs
  • Kitchens, Bathrooms, and Living Areas Requiring Tamper-Resistant Receptacles
  • Renovation and New Construction Wiring

Why Pass & Seymour?

Pass & Seymour combination devices like the 691TRW are engineered with one-piece heat-treated triple-wipe brass power contacts and tamper-resistant dual shutter protection to deliver dependable, code-compliant performance. The grounding combination design meets NEC requirements, making it a practical choice for electricians who need a reliable switch-and-receptacle solution without sacrificing box space. As part of the Pass & Seymour product line, the 691TRW is backed by cULus Listing for use across professional electrical installations.

Product Specs

Product Material:
Thermoplastic
Voltage Rating:
120/125V
Listing:
cULus
Product Type:
Switch/Receptacle Combination
Department:
Electrical
Product Finish:
Satin
Product Group:
Wiring Devices
Amperage Rating:
15A
Product Subgroup:
Combination Devices
Product Depth:
1.15 in
Product Width:
1.32 in
Product Height:
4.06 in

Pass & Seymour 691TRI – Frequently Asked Questions

1) Can the switch and receptacle on the Pass & Seymour 691TR be fed from separate circuits?
Yes. The 691TR has a break-off feed tab between the switch and the receptacle. Leave the tab intact and both halves share a common feed; snap it off and you can wire the toggle and the outlet on separate feeds, which is how you keep the receptacle hot while the switch controls a light or a fan.
2) Is the receptacle on the 691TR a duplex or a single outlet?
Single. The 691TR gives you one tamper-resistant receptacle alongside the toggle switch, not a duplex pair. If you need two outlets plus a switch in one strap, this is not the device. Leviton's T5225 is a tamper-resistant duplex combination switch/receptacle and is the one to look at when you need both plug positions.
3) What is the closest alternative to the Pass & Seymour 691TR combination switch and tamper-resistant receptacle?
The Leviton T5225 is the nearest equivalent: a tamper-resistant combination switch/receptacle built to commercial grade. The main difference is the outlet portion - the 691TR pairs a single-pole toggle switch with a tamper-resistant single receptacle, while the Leviton T5225 is a duplex combination, giving two outlet faces instead of one. Both are tamper-resistant devices, so if an electrician needs two cord positions at the switch location, the duplex version is the one to specify.
4) What amperage and voltage is the Pass & Seymour 691TR rated for?
15A at 120/125V, so it drops onto a standard 15-amp branch circuit on #14 copper. Do not use it on a 20-amp circuit where a 20A device is specified, and the switch side is single-pole only, so it will not work as part of a three-way pair.
5) What colors does the 691TR combination device come in?
Two: white (691-TRW) and ivory (691TRI). Both are thermoplastic with a satin finish, so they match the rest of a satin-finish Pass & Seymour trim run on a property without standing out. Order by the exact part number if you are matching existing devices across a building.
6) Do I need a special wall plate for a combination switch and receptacle like the 691TR?
Yes. A combination switch/receptacle needs a single-gang plate with the combination cutout, one toggle opening plus one round receptacle opening. A standard toggle plate or a standard duplex plate will not cover it. No plate ships with the device, so add one in the matching white or ivory.
7) For a high-traffic commercial corridor, should I use the 691TR or the Leviton T5225 combination device?
The Leviton T5225 is specified as a commercial grade combination switch/receptacle, which is the usual basis for standardizing in heavy-use commercial space. The Pass & Seymour 691TR is a 15A 120V/125V combination device with one-piece heat-treated triple-wipe brass power contacts and is cULus Listed for use in residential and commercial electrical systems. Facility buyers writing a single spec line across a building typically choose on that grade designation; both are tamper-resistant.
8) Is the Leviton T5225 a drop-in replacement for a Pass & Seymour 691TR?
They serve the same purpose but are not identical devices. The Pass & Seymour 691TR combines a single-pole toggle switch with a single tamper-resistant receptacle, while the Leviton T5225 is a duplex combination switch/receptacle. Swapping one for the other changes the receptacle face from one outlet to two, so verify what the wall plate opening and the circuit were laid out for before substituting. The 691TR also has a break-off feed tab that lets the switch and receptacle be fed separately or in common.
9) We need tamper-resistant outlets in a pediatric clinic - do both the 691TR and the Leviton T5225 qualify?
Yes, both are tamper-resistant combination devices. The Pass & Seymour 691TR uses a dual mechanical shutter system on the receptacle to help prevent insertion of foreign objects and is cULus Listed, and the Leviton T5225 is likewise a tamper-resistant combination switch/receptacle in a commercial grade. Choose between them on whether the opening calls for a single or duplex receptacle face and on the grade your facility spec requires.
10) Are the contacts on the Pass & Seymour 691TR durable enough for a commercial corridor or rental turnover?
The power contacts are one-piece heat-treated triple-wipe brass, which is what keeps plug retention from going slack after repeated use, and the body is thermoplastic. It is cULus Listed for residential and commercial electrical systems. If your spec calls out a commercial-grade device by name, the Leviton T5225 is listed as commercial grade.
11) Can I match the 691TR in ivory, or do I have to switch brands for a color match?
The Pass & Seymour 691TR is offered in both white (691-TRW) and ivory (691TRI) with a satin thermoplastic housing, so an ivory opening can be matched within the same part family rather than mixing manufacturers. The Leviton T5225 comparable is a tamper-resistant duplex combination switch/receptacle in commercial grade, which is a different receptacle configuration, so matching color across two brands also means matching the device face.
12) Where is the Pass & Seymour 691TR made?
Mexico. That matters on public and institutional jobs where country of origin has to be documented on the submittal, so it is worth recording alongside the cULus listing.
