Pass & Seymour Industrial Extra Heavy-Duty Spec-Grade Duplex Receptacle, 20A 125V

Pass & Seymour Industrial Extra Heavy-Duty Spec-Grade Duplex Receptacle, 20A 125V

(No reviews yet) Write a Review

Model: 5362AW
Selected Color is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour Industrial Extra Heavy-Duty Spec-Grade Duplex Receptacle, 20A 125V

The Pass & Seymour Industrial Extra Heavy-Duty Spec-Grade Duplex Receptacle is a 20A 125V back-and-side wire device built for demanding industrial and commercial power distribution. A one-piece brass mounting strap with integral ground and .036 inch thick, brass, triple-wipe power contacts deliver long-term retention and reliable connections. Rated cULus Listed, this receptacle is engineered for tough duty-cycle applications where consistent performance and code-compliant construction matter.

Key Features

  • Electrical Rating: 20A 125V duplex configuration for standard industrial and commercial branch-circuit loads.
  • Durable Construction: One-piece brass mounting strap with integral ground for a rigid, corrosion-resistant base.
  • Triple-Wipe Power Contacts: .036 inch thick brass triple-wipe contacts provide lasting plug retention and connection reliability.
  • Back and Side Wire Termination: External screw-pressure-plate back wire clamps with #10 brass terminal screws give visual assurance of a secure connection, plus oversized #10 deep tri-drive head brass terminal and ground screws.
  • Reinforced Strap Assembly: Two drive screws anchor the strap to the back body and face for added mechanical strength.
  • Thermal Performance: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current; operates continuously from -40°C to +60°C.
  • Exclusive Design Features: Patented circuit-identification label on the face and an external screw-pressure-plate back wire clamp on the ground terminal for faster, easier installation, plus an easily accessed break-off, line-contact connecting tab for fast split-circuit wiring.
  • Finish: Matte finish face.

Certifications & Compliance

  • cULus Listed

Technical Specifications

  • Country of Origin: MEX
  • Spec Sheet: https://media.distributordatasolutions.com/legrand_synd/2025q4/documents/b71d7ae3307ed5c846108209a70266f7b9e938bf.pdf
  • Finish: Matte
  • Product Line: Pass & Seymour
  • Packaging: 10 EA

Typical Applications

  • Industrial and Commercial Electrical Installations
  • High-Cycle, Heavy-Duty Power Outlets
  • Split-Circuit Branch Wiring
  • Renovation and New Construction Projects
  • General Purpose 20A 125V Receptacle Replacement

Why Pass & Seymour?

Pass & Seymour builds this Industrial Extra Heavy-Duty Spec-Grade receptacle with a one-piece brass strap, triple-wipe brass contacts, and oversized brass terminal screws to withstand demanding duty cycles. Backed by cULus Listing, it delivers the reliable, code-compliant performance professional electricians expect from spec-grade wiring devices.

Manufacturer Resources

Product Specs

list_batch:
PASS-20260820
Product Type:
Receptacle
Configuration:
Duplex
Voltage Rating:
125V
Amperage Rating:
20A
Connection Type:
Back and Side Wire
Product Finish:
Matte
Listing:
cULus
Country of Origin:
Mexico
Department:
Electrical
Product Group:
Wiring Devices
Finish:
Matte
