Pass & Seymour R Series Preset Rotary Incandescent Dimmer, 600W

The Pass & Seymour R Series Rotary Dimmer is a preset incandescent dimmer rated 600W at 120V, engineered for reliable residential and light commercial lighting control. This family-page covers the full R Series 600W rotary dimmer lineup, available in Ivory and Light Almond finishes and offered in 1-pole and 3-way (3-pole) configurations, so installers can match color scheme and switching needs while keeping the same trusted 600W performance and RFI/EMI filtering in every version. Every option in the R Series 600W line is cULus listed and RoHS compliant, giving installers confidence in both safety and environmental compliance across the range.

Key Features

  • Power Rating: Rated 600 watts at 120V across the family, with no de-rating of 600 watt models in multi-gang applications.
  • Available Finishes: Choose from Ivory or Light Almond to complement any décor.
  • Pole Configurations: Offered in 1-pole and 3-pole (3-way) versions for single-location or multi-location switching.
  • RFI/EMI Filtering: Excellent filtering performance that won't impact sensitive electronic devices nearby.
  • Ergonomic Knob Design: Easy-to-grip knob with soft, contemporary curves that goes with any décor and is interchangeable with older-style knobs.
  • Slimmer Profile: Among the trimmest rotary dimmers available, with 1/4 in. less depth than the leading competitor's models.
  • Precise Control: Rotary design makes small adjustments in lighting levels easier for smoother dimming control.
  • Fast Installation: Pre-stripped leads speed termination and leave more room in the box for faster, easier installation.

Certifications & Compliance

  • UL Listed
  • cULus Listed
  • RoHS Compliant

Technical Specifications

  • Watts: 600
  • Product Series: R
  • UL Listing No: Yes
  • cULus: Yes
  • RoHS: Yes
  • Available Colors: Ivory, Light Almond
  • Available Pole Configurations: 1, 3

Typical Applications

  • Residential and Light Commercial Lighting Control
  • Incandescent Lighting Circuits
  • Multi-Gang Switch Box Installations
  • Decorative and Ambient Lighting Adjustment
  • Renovation and New Construction Wiring

Why Pass & Seymour?

Pass & Seymour engineers the R Series 600W Rotary Dimmer family for reliable, code-compliant performance, backed by cULus listing and RoHS compliance across every finish and pole configuration. With excellent RFI/EMI filtering, a slim in-box profile, and pre-stripped leads for faster termination, this dimmer line is built to simplify installation while delivering smooth, dependable lighting control for professional electrical work, whatever finish or switching configuration the job calls for.

Manufacturer Resources

Product Specs

list_batch:
PASS-20260820
Product Type:
Rotary Dimmer
Series:
R
Voltage Rating:
120V
Listing:
cULus
Country of Origin:
China
Department:
Electrical
Product Group:
Wiring Devices
Standards:
RoHS
Configuration:
1-3 Pole
Product Subgroup:
Dimmer Switches

Pass & Seymour R600-PIV – Frequently Asked Questions

1) Which Pass & Seymour R600 do I order for a 3-way setup with two switch locations?
For two-location switching you need the 3-pole (3-way) version: R603-PIV in Ivory or R603-PLAV in Light Almond. The 1-pole single-location models are R600-PIV (Ivory) and R600-PLAV (Light Almond). In a 3-way pair only one device is the dimmer; the other location uses a standard 3-way switch.
2) Do I have to derate the R600 dimmer when I gang several of them in one box?
No derating is needed. Pass & Seymour states the 600 watt R Series rotary models hold their full 600W rating in multi-gang applications, so you can gang them without cutting back the load per device. The slim body also takes about 1/4 inch less depth than the leading competitor's rotary dimmers, which helps in a crowded box.
3) Is the Pass & Seymour R600 rotary dimmer approved for commercial work?
It is cULus Listed and RoHS compliant, and Pass & Seymour positions the R Series 600W rotary as a residential and light commercial lighting control. For heavier commercial loads or non-incandescent sources, specify a device rated for that application.
4) Does the R600 dimmer have screw terminals or wire leads?
Pre-stripped wire leads, not screw terminals. You wire-nut them to the circuit conductors, which speeds termination and leaves more free space in the box.
5) Will a rotary dimmer knob match the ivory switches already on my other walls?
The R Series 600W rotary comes in Ivory and Light Almond, so it can be matched to existing ivory or light almond device plates across a building. Both colors are offered in 1-pole and 3-pole, so a mixed-switching job keeps one color scheme throughout.
6) Can I keep my old rotary knob when I swap in this dimmer?
Yes. The R Series knob is interchangeable with older-style Pass & Seymour rotary knobs, so a knob you want to keep for appearance can be carried over. The supplied knob has softer contemporary curves and an easy grip.
7) Will a rotary dimmer interfere with nearby audio or electronics?
The R Series 600W rotary includes RFI/EMI filtering, which Pass & Seymour states won't impact sensitive electronic devices nearby. That matters in media rooms, conference rooms, and hospitality spaces where dimmers sit near AV gear.
8) Is this a preset dimmer or does it turn off when you rotate it down?
It is a preset rotary dimmer: the knob sets and holds a light level, and rotating gives fine control for small adjustments rather than stepped changes. The rotary action is what makes low-level trimming easier than with a slide control.
