Pass & Seymour Wattstopper Digital Timer Switch, 100-300VAC

Pass & Seymour Wattstopper Digital Timer Switch, 100-300VAC

(No reviews yet) Write a Review

Model: TS400I

In Stock (leaves warehouse same day if ordered before 3pm ET)

$100.78
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour TS400I Wattstopper Digital Timer Switch, 100-300VAC, Ivory

The Pass & Seymour TS400I Wattstopper Digital Timer Switch is a countdown-style timer switch built for simplified terminal-style wiring installation. Rated 100-300VAC with a 0-800/1200W lighting load capacity, this ivory-finished digital timer switch automatically turns connected lighting off after a preset time, making it a practical choice for energy-conscious lighting control in commercial and residential settings. Digital pushbutton operation and a bright electroluminescent LCD countdown display make setup and daily use straightforward for electricians and end users alike.

Key Features

  • Terminal Style Wiring: Simplified terminal-style wiring connections speed up installation.
  • Digital Operation: Simple pushbutton set-up lets users program timer settings quickly and accurately.
  • Electroluminescent LCD Display: A bright electroluminescent LCD shows the timer's countdown clearly, even in low light.
  • Automatic Shutoff: Automatically turns lights off after the preset time, helping reduce unnecessary energy use.
  • Time Scroll Adjustment: Time scroll feature allows the countdown timer to be adjusted up or down as needed.
  • Alert Options: Optional audible or visual alerts warn occupants before lights turn off.
  • Electrical Rating: Rated 100-300VAC with a 0-800/1200W lighting load capacity for compatible fixtures.
  • Ivory Finish: Matte ivory finish blends with a wide range of wall and trim colors.

Technical Specifications

  • Country Of Origin: China
  • Product Finish: Matte
  • Product Line: Pass & Seymour
  • Voltage Rating: 100-300VAC
  • Load Rating: 0-800/1200W
  • Color: Ivory

Typical Applications

  • Commercial and Residential Lighting Control
  • Energy-Saving Automatic Timer Lighting
  • Terminal-Wired Switch Installations
  • Renovation and New Construction Wiring
  • Occupant Alert Lighting Shutoff Systems

Why Pass & Seymour?

Pass & Seymour brings Wattstopper digital timer technology into a compact switch form factor, combining terminal-style wiring for straightforward installation with digital pushbutton programming for reliable, repeatable performance. The bright electroluminescent LCD countdown, adjustable time scroll, and optional alerts give installers and building occupants clear control over lighting shutoff, supporting energy-conscious, code-compliant electrical work in both new construction and renovation projects.

Manufacturer Resources

Spec Sheet

Product Specs

Voltage Rating:
100-300VAC
Product Type:
Time Switch
Department:
Electrical
Country of Origin:
China
Product Finish:
Matte
Product Group:
Wiring Devices
Product Subgroup:
Lighting Controls & Sensors

Pass & Seymour TS400I – Frequently Asked Questions

1) How much lighting load can the TS400 timer switch handle?
The TS400 is rated 0-800/1200W of lighting load. Total up the fixture wattage on the circuit before you commit; a bank of high-wattage HID or older fluorescent ballasts can exceed that, in which case you switch a contactor with the timer rather than the load directly.
2) Is the TS400 a countdown timer or a 7-day programmable timer?
It's a countdown timer. The TS400 turns the connected lighting off after a preset interval, adjusted up or down with the time scroll feature and shown on the LCD. If you need lights to come on and off at set times of day on a weekly schedule, this is the wrong type of device, you want an astronomic or 7-day programmable time switch instead.
3) Does the TS400 timer switch use screw terminals or push-in wire leads?
Terminal-style wiring. The TS400 uses screw terminal connections rather than pigtail leads, which keeps the box fill down and makes it faster to land conductors in a crowded single-gang box on a retrofit.
4) What colors does the Pass & Seymour TS400 digital timer switch come in?
Two: white (TS400W, ordered as TS-400-W) and ivory (TS400I). Both carry a matte finish, so they sit alongside standard matte-finish device plates without a gloss mismatch. Pick the one matching the other devices on the wall.
5) Can occupants tell before the lights shut off with the TS400?
Yes, there are optional audible or visual alerts that warn occupants ahead of shutoff. That matters in restrooms, stairwells and storage rooms where someone may still be in the space; they get a cue to press the button and add time rather than being dropped into the dark.
6) Can you read the TS400 timer display in a dark room?
The countdown is shown on a bright electroluminescent LCD, so it stays readable in low light. Useful for the applications these timers usually land in, closets, mechanical rooms and unlit corridors.
7) Is the TS400 suitable for residential use or is it a commercial-only device?
Both. Pass & Seymour positions the TS400 Wattstopper digital timer for commercial and residential lighting control, including new construction and renovation wiring. Property managers use it for the same reason contractors do: it enforces automatic shutoff in spaces where switches get left on.
