Pemko EV80 Eco-V Fire-Rated Vinyl Door Shoe 36"; with UL10C Certification Dark Brown

Professional Fire-Rated Door Bottom Sealing Solution

The Pemko EV80 Eco-V vinyl door shoe provides professional-grade door bottom sealing with dual durometer vinyl construction in a 36"; length. This fire-rated door shoe features UL10C positive pressure certification and UL1784 smoke testing compliance, making it ideal for commercial applications requiring code-compliant door sealing. The 1-3/4"; width and 5/8"; height profile delivers effective weatherstripping performance while maintaining GREENGUARD Gold certification for indoor air quality.

Professional Features & Benefits

  • Standard Door Width Compatibility: 36"; length accommodates standard commercial door widths with precise 1-3/4"; width and 5/8"; height profile for proper fit.
  • Fire-Rated Performance: UL10C positive pressure certification and UL1784 smoke testing ensure code compliance for fire-rated door assemblies.
  • Dual Durometer Construction: Eco-V vinyl material provides optimal sealing performance with long-lasting durability for high-traffic commercial applications.
  • Environmental Certification: GREENGUARD Gold certification confirms low chemical emissions for healthy indoor air quality in occupied spaces.
  • Professional Ratings: Underwriters Laboratory 4L10 listing provides additional performance validation for commercial installations.
  • Manufacturer Warranty: 5 Year warranty coverage for added confidence and protection in commercial applications.
  • Code-Compliant Sealing: Engineered specifically for fire-rated door assemblies requiring professional weatherstripping performance.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Dimension: W: 1-3/4", H: 5/8";
  • Product Finish: Brown
  • Product Group: Door Trim and Accessories
  • Product Model: EV80
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Substrate: Eco-V (Vinyl)
  • Product Type: Door Shoes
  • Subcategory: Door Bottoms & Door Shoes
  • UL Listing Type: Fire Rated UL10C Positive Pressure, Underwriters Laboratory 4L10
  • Warranty: 5 Year

Professional Applications

  • Fire-Rated Door Assemblies
  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Choose Pemko Quality?

Pemko door shoes deliver professional-grade reliability with dual durometer Eco-V vinyl construction and comprehensive fire safety certifications including UL10C positive pressure and UL1784 smoke testing. 5 Year warranty coverage and GREENGUARD Gold certification demonstrate Pemko's commitment to performance and environmental responsibility. Engineered for demanding commercial applications where code-compliant sealing and fire safety performance are essential.

Product Specs

Subcategory:
Door Bottoms & Door Shoes
Warranty:
5 Year
Product Group:
Door Trim and Accessories
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Shoes
Commercial/Residential:
Commercial
UL Listing Type:
Fire Rated UL10C Positive Pressure, Underwriters Laboratory 4L10
Product Model:
EV80
Product Finish:
Brown
Product Dimension:
W: 1-3/4", H: 5/8"
Product Category:
Door Trim and Accessories
Product Substrate:
Eco-V (Vinyl)
Department:
Door Hardware

Pemko EV80D36 – Frequently Asked Questions

1) Will the Pemko EV80 door shoe fit a standard 36 inch commercial door?
The EV80 Eco-V door shoe comes in a 36 inch length, which covers a standard 36 inch door leaf. The profile measures 1-3/4 inches wide by 5/8 inch high, so you need that much clearance at the bottom rail and under the door for the shoe body plus its vinyl seal. On a door narrower than 36 inches the extrusion is cut down to the leaf width on site, which is normal practice for door bottoms.
2) Is the Pemko EV80 door shoe approved for a fire-rated door assembly?
Yes. The EV80 carries a Fire Rated UL10C Positive Pressure listing plus Underwriters Laboratories 4L10. That is the listing an inspector looks for on a labeled opening under positive pressure test conditions, so it can go on a fire door assembly rather than only on a non-rated exterior or interior opening.
3) How much clearance do I need under the door for a Pemko EV80 door shoe?
Plan for the 5/8 inch height of the shoe profile between the door bottom and the threshold or floor. The extrusion is 1-3/4 inches wide across the door bottom, so it suits a standard 1-3/4 inch commercial door leaf. If your undercut is tight, the door has to be trimmed or rehung before the shoe will seat and seal.
4) What is the difference between the Pemko EV80 door shoe and the NGP 112 neoprene door shoe?
They seal the door bottom the same way but use different sealing materials. The Pemko EV80 uses a dual durometer Eco-V vinyl seal on a 1-3/4 inch wide, 5/8 inch high profile and carries a Fire Rated UL10C Positive Pressure listing along with Underwriters Laboratory 4L10. The NGP 112 is a neoprene door shoe on aluminum alloy construction rated for a temperature range of -20 F to 200 F. If the opening is a fire-rated assembly and the inspector wants the UL10C positive pressure listing on the door bottom, the EV80 is the one that carries it. If the door sees extreme heat or cold at a loading dock or an unconditioned mechanical space, the NGP 112 states the temperature range for that service.
5) What is the EV80 door shoe made of, and will the seal hold up in a high traffic corridor?
The wearing part is Eco-V vinyl in a dual durometer construction, meaning a firmer body carrying a softer sealing edge. It is specified for commercial use, so it is built for the door cycles you get in an office corridor, school, or multi-tenant building rather than a residential entry.
6) Should I use a door shoe or a surface door sweep at the bottom of my door?
A door shoe like the EV80 wraps the bottom edge of the leaf, so the extrusion sits on the underside and the seal rides on the threshold or floor. That is the right choice when you want the seal protected by the door edge and you can take the door off its hinges to install. A surface sweep instead screws to the face of the door near the bottom and can be fitted without pulling the door, but it sits in the open where it takes abuse. On a fire-rated opening, check that whichever you pick carries a UL10C positive pressure listing; the EV80 does.
7) Is the EV80 door shoe OK to install in a school or healthcare building with indoor air quality requirements?
The EV80 Eco-V vinyl shoe is GREENGUARD Gold certified for low chemical emissions, which is the certification specifiers ask for on occupied spaces like classrooms and patient areas. Combined with the UL10C positive pressure fire listing, it covers both the life safety and the IAQ side of an institutional spec.
8) I need a door shoe that holds up in freezing or high heat conditions. Is the EV80 the right pick?
For a stated temperature range, look at the NGP 112 instead. It is a neoprene door shoe on an aluminum alloy body rated from -20 F to 200 F, which is the one to specify for a mechanical room, a walk-in vestibule, or an unconditioned warehouse opening. The Pemko EV80 is the choice when the driver is the UL10C positive pressure fire listing and low-emission GREENGUARD Gold material on an interior rated opening.
9) Does the Pemko EV80 door shoe help with smoke as well as fire?
Yes. Alongside the UL10C positive pressure fire listing, the EV80 is compliant with UL1784 smoke testing, which is the air leakage test used for smoke and draft control assemblies. That matters on corridor and stair doors in healthcare and multi-tenant buildings where the opening has to control smoke migration, not just resist flame.
10) Can I use a door sweep instead of the Pemko EV80 door shoe?
They are not the same part. The Pemko EV80 is a door shoe: an extruded channel that wraps the bottom edge of the door with a dual durometer Eco-V vinyl seal, measuring 1-3/4 inches wide by 5/8 inch high, and it carries Fire Rated UL10C Positive Pressure and Underwriters Laboratory 4L10 for rated assemblies. A sweep fastens flat to one face of the door and does not wrap the bottom edge. The peer door shoes are built the same wrap-the-edge way - the Cal-Royal DS-403 as an aluminum shoe with a vinyl insert, the NGP 12T on a mill aluminum base with vinyl fins - so those are true swaps in form, while a sweep is a different detail and will not satisfy a schedule that calls for a shoe.
11) What is the difference between a vinyl door shoe and a thermoplastic door shoe?
It is the seal material and how it contacts the threshold. The Pemko EV80 uses dual durometer Eco-V vinyl, which pairs a rigid section with a softer sealing edge in one extrusion. The NGP 12T is a thermoplastic door shoe built on a mill aluminum base with vinyl fins, so the seal is multiple thin fins rather than a single dual durometer profile. Fins flex easily and suit a door with an uneven or slightly out-of-level threshold; a dual durometer vinyl seal gives one continuous contact line. The EV80 is the one that carries Fire Rated UL10C Positive Pressure and Underwriters Laboratory 4L10 for rated assemblies.
12) Which door shoe should I standardize on across a facility with both rated and non-rated openings?
Standardizing on the Pemko EV80 lets one part number cover both, because it is a commercial door shoe carrying Fire Rated UL10C Positive Pressure and Underwriters Laboratory 4L10, and a shoe that satisfies a rated opening will also serve a non-rated one. The EV80 is a 1-3/4 inch wide, 5/8 inch high Eco-V vinyl profile in Brown. If you are stocking a second line for specific service conditions, the NGP 112 is a neoprene shoe on aluminum alloy rated -20 F to 200 F for temperature extremes, and the Cal-Royal DS-403 is an aluminum shoe with a vinyl insert. One SKU across the doors keeps maintenance carts simpler; two only makes sense if you have openings the temperature range speaks to.
