Bussmann S-3/10 Plug Fuse

Bussmann Time Delay Plug Fuse 3/10A 125V with Rejection Base

(No reviews yet) Write a Review

Model: S-3/10
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$85.14
$33.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann Time Delay Plug Fuse 3/10A 125V with Rejection Base

Professional Time Delay Protection for Low-Current Applications

The Bussmann Time Delay Plug Fuse delivers reliable overcurrent protection with 3/10A rating and 125V capacity. Featuring a rejection base design with plastic construction and threaded mounting, this time delay fuse provides professional-grade protection for sensitive electrical circuits requiring controlled response to temporary overloads.

Professional Features & Benefits

  • 3/10A Time Delay Rating: Provides precise overcurrent protection while allowing temporary overloads for motor starting and inrush current applications.
  • 125V Voltage Rating: Suitable for standard residential and light commercial electrical systems with reliable voltage handling.
  • Rejection Base Design: Prevents incorrect fuse installation and ensures proper amperage rating compliance for enhanced safety.
  • 10 kAIC Interrupt Rating: Capable of safely interrupting high fault currents up to 10,000 amperes for comprehensive circuit protection.
  • Plastic Base Construction: Durable material provides electrical insulation and mechanical strength for long-term reliability.
  • Threaded Mounting: Secure installation method ensures proper electrical contact and prevents accidental disconnection.
  • Heavy Duty Design: Built for demanding applications with robust construction for extended service life.

Technical Specifications

  • Amperage Rating: 3/10A
  • Base: Rejection
  • Department: Electrical
  • Height: 12.56 IN
  • Interrupt Rating: 10 kAIC
  • Material Type: Plastic base
  • Mounting: Threaded
  • Product Details: Time delay
  • Product Group: Fuses
  • Product Length: 12.88 IN
  • Product Subgroup: Time Delay Fuses
  • Product Type: Time delay
  • Special Features: Heavy duty, packaging type blister pack
  • Voltage Rating: 125V
  • Weight: .6 LB
  • Width: 6.75 IN

Professional Applications

  • Residential electrical panels and distribution boards
  • Light commercial electrical systems
  • Motor control circuits requiring time delay protection
  • Sensitive electronic equipment protection
  • HVAC system overcurrent protection
  • Appliance and equipment branch circuits
  • Electrical maintenance and repair applications

Why Choose Bussmann Quality?

Bussmann time delay fuses provide dependable overcurrent protection with heavy duty construction and rejection base safety features. The plastic base material and threaded mounting ensure reliable installation and long-term performance in demanding electrical applications.

Manufacturer Resources

Product Specs

Amperage Rating:
3/10A
Base:
Rejection
Interrupt Rating:
10 kAIC
Material Type:
Plastic base
Special Features:
Heavy duty, packaging type blister pack
Voltage Rating:
125V
Product Group:
Fuses
Department:
Electrical
Product Subgroup:
Time Delay Fuses
Product Type:
Time delay
Product Length:
12.88 IN
Product Details:
Time delay
Mounting Method:
Threaded
Product Height:
12.56 IN
Product Weight:
.6 LB
Product Width:
6.75 IN

Bussmann S-3/10 – Frequently Asked Questions

1) Will a Bussmann S-3/10 plug fuse screw into a standard Edison plug fuse socket?
No. The S-3/10 is a Type S rejection base fuse, so it will not thread directly into a plain Edison (Type T/W) fuseholder. It needs the matching Type S adapter for its amperage installed in the socket first. That is the whole point of the rejection design: once the adapter is in, only a fuse of the correct rating will fit, so nobody can swap in a heavier fuse later.
2) Why choose a time delay fuse over a fast acting one for a motor circuit?
A time delay fuse rides through the brief inrush a motor, transformer, or compressor draws at startup and only opens on a sustained overload or a short. A fast acting fuse of the same rating would nuisance blow every time the load started. The S-3/10 is built as a time delay element, which is why it suits motor control and HVAC control circuits rather than purely resistive loads.
3) What fault current can the Bussmann S-3/10 safely interrupt?
It is rated 10 kAIC, meaning it can clear a fault of up to 10,000 amperes without rupturing. That matters when the available fault current at your panel is specified on the drawing or the label, since the protective device has to equal or exceed it. For a small control circuit fed from a residential or light commercial service, 10 kAIC is normally more than enough headroom.
4) Can I put a higher amperage Type S fuse in the same socket later if this one keeps blowing?
Not without changing the adapter. The rejection base is sized to the amp rating, so once the 3/10A adapter is installed only a fuse of that class will thread in. If the fuse keeps opening, the circuit is drawing more than 0.3 amps and the load needs investigating, not the fuse upsizing. Upsizing means pulling the adapter and re-evaluating what the conductors and the equipment are rated for.
5) Is the base of this plug fuse metal or insulated?
The S-3/10 uses a plastic base with the threaded shell for contact. The plastic body keeps the current carrying parts insulated from your fingers while you are turning the fuse into a live fuseholder.
6) How does the Bussmann S-3/10 come packaged for stocking on a service truck?
It ships in a blister pack, which keeps the fuse identifiable on a shelf or in a van bin rather than loose in a drawer. Handy if you are carrying several Type S ratings and need to grab the right one fast.
