BEST Precision 5203 Series 36" Surface Vertical Rod Exit Device with Key Retracts Latchbolt

BEST Precision 5203 Series 36" Surface Vertical Rod Exit Device with Key Retracts Latchbolt

(No reviews yet) Write a Review

Model: 5203 689 36
$1,257.00
$904.76
Selected Finish is
Selected Trim is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,257.00
$904.76
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEST Precision 5203 Series 36" Surface Vertical Rod Exit Device with Key Retracts Latchbolt

Professional Grade 1 Exit Device for Commercial Applications

The BEST Precision 5203 Series delivers Grade 1 performance for commercial door applications requiring reliable vertical rod exit hardware. This 36" surface-mounted exit device accommodates doors from 1-3/4" to 2-1/4" thick and up to 4'-0" wide by 10'-0" high openings, with key retract latchbolt functionality for enhanced security control. UL Listed for both panic and fire exit hardware applications, this reversible device features heavy wrought steel construction with powder coated finish for long-term durability. ANSI/BHMA certified to ANSI 156.3 Grade 1 standards for demanding commercial environments.

Professional Features & Benefits

  • Door Compatibility: Designed for 1-3/4" to 2-1/4" thick doors up to 4'-0" wide by 10'-0" high openings for versatile commercial applications.
  • Grade 1 Certification: ANSI/BHMA certified to ANSI 156.3 Grade 1 standards ensuring reliable performance in high-traffic commercial environments.
  • Heavy-Duty Construction: Heavy wrought steel active case and touchbar sub-assembly with zinc dichromate plating for exceptional durability and corrosion resistance.
  • UL Listed Performance: UL Listed for both panic and fire exit hardware applications providing code compliance and safety assurance.
  • Key Retract Latchbolt: Stainless steel deadlocking latchbolt with 3/4" throw and key retract functionality for enhanced security control.
  • Reversible Design: Field reversible for all functions and trims allowing flexible installation for various door configurations.
  • Precision Bottom Bolt: Steel plated independent action bottom bolt with 5/8" throw and adjustment range to suit 3/4" door undercut.
  • Standard Dogging Feature: 1/4 turn hex key dogging standard for convenient maintenance access (not available for fire exit hardware).

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Fire Rating: No
  • Product Category: Exit Devices and Trim
  • Product Group: Exit Devices and Trim
  • Product Subgroup: Exit Devices - Vertical Rod
  • Product Type: Exit Devices - Surface Vertical Rod
  • Series: 5200 Series
  • Subcategory: Surface Vertical Rod

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose BEST Quality?

BEST Precision 5200 Series exit devices deliver professional-grade reliability with heavy wrought steel construction and zinc dichromate plating rated for Grade 1 commercial applications. UL Listed for both panic and fire exit hardware with ANSI/BHMA certification to ANSI 156.3 standards. Engineered for demanding commercial applications where dependable performance and code compliance are essential.

Product Specs

Series:
5200 Series
Product Group:
Exit Devices and Trim
Product Subgroup:
Exit Devices - Vertical Rod
Product Type:
Exit Devices - Surface Vertical Rod
Subcategory:
Surface Vertical Rod
Commercial/Residential:
Commercial
Fire Rating:
No
Product Category:
Exit Devices and Trim
Department:
Door Hardware

BEST 5203 689 36 – Frequently Asked Questions

1) Do I need to order a left hand or right hand version of the Precision 5203?
No handing to specify. The 5203 is field reversible for all functions and trims, so one device covers either swing and you can flip it on site if the opening changes.
2) Will a surface vertical rod exit device like the 5203 work on a pair of doors without a mullion?
That is exactly what it is for. A surface vertical rod device latches at the head and at the sill rather than into the jamb, so a pair of doors can be secured with no center mullion and the full clear opening stays available. If you have a single door in a frame, a rim device is the simpler choice; if you want a pair with a mullion, use rim devices plus a removable mullion.
3) What does key retracts latchbolt mean on the BEST Precision 5203?
The top latchbolt is a stainless steel deadlocking bolt with a 3/4 inch throw, and turning the key through the outside trim pulls that bolt back so the door can be opened from outside. It is a security function, not a passage function: the bolt relatches when the key is released. Push the touchbar and you always get out from the inside.
4) Can I order the Precision 5203 without a bottom rod?
Yes. Less bottom rod is an option on every dogging and trim combination of the 36 inch 5203. Buyers pick LBR to keep the floor clear of a bottom strike, which cuts down on debris jams and trip hazards in high traffic openings. Ordered with the bottom bolt, you get a steel plated independent action bottom bolt with a 5/8 inch throw that adjusts to suit up to a 3/4 inch door undercut.
5) What dogging choices does the BEST Precision 5203 come with?
Three: hex key dogging, cylinder dogging, or less dogging. Hex dogging is the standard 1/4 turn hex key type and is fine for a maintenance crew that wants to hold the latch retracted during business hours. Cylinder dogging puts that under a keyed cylinder so only keyholders can dog the device, which is what most schools and healthcare facilities specify. Less dogging is the choice where the door must always latch.
6) My opening is a narrow stile aluminum door - is the BEST Precision 5203 the right device?
The 5203 is built for doors 1-3/4 inch to 2-1/4 inch thick on openings up to 4 feet wide by 10 feet high. For a narrow stile door, devices specified as narrow stile include the Von Duprin 3327A-3ft grooved case and the Von Duprin 7527-3ft, both Grade 1 at 3 feet, the Corbin Russwin ED4400 Grade 1 at 36 inch, the Falcon 19-V-EO at 36 inch exit only, and the TownSteel ED3727 at 36 inch by 84 inch. The Adams Rite 8200 Series is a narrow stile life safety device at 30 inch.
7) The BEST Precision 5203 is not fire rated - what surface vertical rod device should I use on a fire rated opening instead?
The 5203 carries a Fire Rating value of No, so for a labeled opening choose a device listed as fire rated: the TownSteel EF9727 is a fire rated Grade 1 heavy duty surface vertical rod device in 36 inch by 84 inch, the Adams Rite 3100 Series is a fire rated Grade 1 wide stile device at 30 inch for 1-3/4 inch doors, the Sargent 2727 is a Grade 1 fire rated reversible wide stile device, and the Arrow S1150 is a fire rated device only, less trim, at 30 inch. Fire exit hardware does not use dogging, so the hex and cylinder dogging options on the 5203 have no counterpart on those devices.
8) My door is over 1-3/4 inch thick - which surface vertical rod devices will fit besides the BEST Precision 5203?
The BEST Precision 5203 covers doors from 1-3/4 inch to 2-1/4 inch thick, which is the wider range in this class. Many comparable surface vertical rod devices are listed for 1-3/4 inch doors only, including the Von Duprin 2227-3FT, the Von Duprin 7827-3ft, the Corbin Russwin ED5400, the Falcon 20 Series, and the Arrow 3700 Series. On a door thicker than 1-3/4 inch the 5203 is the one in this group whose published thickness range reaches 2-1/4 inch.
9) What outside trim can I get with the Precision 5203, and can I buy the device only?
Three trim choices on the 36 inch 5203: 603 keyed trim, 703A keyed handle trim, or none at all if you only need the device. Take the 703A handle trim where users expect a pull handle to enter with the key; the 603 is the plainer keyed trim. Ordering device only makes sense when you are reusing existing pull hardware or the outside face stays blank.
10) Is the Precision 5203 heavy duty enough for a school or hospital corridor?
It is built for that traffic. The active case and touchbar sub-assembly are heavy wrought steel with zinc dichromate plating under a powder coated finish, and the device is ANSI/BHMA certified to ANSI 156.3 Grade 1, the highest durability class for exit hardware. It is a commercial-rated product, not a light duty one.
11) What are the alternatives to the BEST Precision 5203 for a 36 inch door?
Several Grade 1 surface vertical rod devices cover a 36 inch door. The Von Duprin 2227-3FT and the Falcon 20 Series are wide stile Grade 1 devices for 1-3/4 inch doors. Corbin Russwin ED5400 is a wide stile Grade 1 device that accepts trim; the ED4400 is its narrow stile counterpart. TownSteel ED8927 is a wide stile Grade 1 device sized 36 by 84 inches and listed as wood door compatible. If your door is thicker than 1-3/4 inches, stay with the 5203, since it is the one rated up to 2-1/4 inches.
12) Will the bottom bolt on the 5203 still catch if my door has an undercut for carpet?
Up to 3/4 inch of undercut, yes. The steel plated independent action bottom bolt throws 5/8 inch and has an adjustment range that suits a 3/4 inch door undercut. Beyond that, order the device less bottom rod and latch at the head only.
13) I do not need the key retract latchbolt or keyed trim - what is a simpler surface vertical rod device?
The BEST Precision 5203 pairs a key retract latchbolt with keyed trim choices such as 603 and 703A handle trim, and can also be ordered as device only with no trim. If the opening never needs key entry, exit only devices carry no outside trim function at all: the Falcon 25-V-EO wide stile at 3 ft, the Falcon 24-V-EO narrow stile at 36 inch, the Arrow 3700 Series wide stile pushpad at 30 inch, the Sargent 3727 wide stile Grade 1, and the Orca OED56 at 36 inch, which is supplied less bottom rod and non-handed.
14) Is a Grade 2 surface vertical rod device an acceptable substitute for the BEST Precision 5203?
The 5203 is certified to ANSI 156.3 Grade 1 with a heavy wrought steel active case and touchbar sub-assembly. Grade 2 surface vertical rod devices in the same format include the Dexter ED2000 Series panic device and the TownSteel TS5100 Series at 36 inch by 84 inch, a heavy duty wide stile device. If the door schedule or spec calls out Grade 1, those two will not satisfy it; where no grade is called out they are the same device format.
15) What looks like a substitute for the BEST Precision 5203 but will not actually latch the door?
The Sargent 12-8710 is a fire rated Grade 1 wide stile surface vertical rod device, but its function is dummy - it provides the appearance and push action without the latching function. The BEST Precision 5203 is an operating device with a stainless steel deadlocking latchbolt at 3/4 inch throw and an independent action bottom bolt at 5/8 inch throw, so the two are not interchangeable on an active leaf.
16) I need a surface vertical rod exit device on a wood door - does the BEST Precision 5203 apply?
The BEST Precision 5203 is specified for commercial doors 1-3/4 inch to 2-1/4 inch thick without a stated door material restriction. If wood door compatibility has to be confirmed on the submittal, the TownSteel ED8927, ED3727 and EF9727 are all listed as wood door compatible. The Von Duprin 7527-3ft and 7827-3ft are listed as not wood door compatible.
17) I want a crossbar style device instead of the touchbar on the BEST Precision 5203 - what is the option?
The 5203 uses a touchbar sub-assembly of heavy wrought steel, and its touchbar monitoring switch options such as TS and TDS are built around that bar. For a crossbar style surface vertical rod device, the Corbin Russwin ED7400 is a Grade 1 narrow stile crossbar device at 36 inch that accepts operator trim. That is a different push style and a different aesthetic on the opening.
18) Are there other reversible, non-handed surface vertical rod devices like the BEST Precision 5203?
The 5203 is field reversible for all functions and trims, so one device covers either hand. Among comparable devices, the Sargent 2727 is described as reversible, the Von Duprin 2227-3FT is non-handed at 36 inch, and the Orca OED56 at 36 inch is non-handed and supplied less bottom rod. Non-handed stock is what lets a facility hold one part number across left and right hand openings.
19) I want a less bottom rod device to avoid the floor strike - what are my choices against the BEST Precision 5203?
The BEST Precision 5203 can be ordered with the less bottom rod option, keeping the same 36 inch device, hex or cylinder dogging, and 689 aluminum or 695 dark bronze painted finish. The Orca OED56 at 36 inch is also supplied less bottom rod, as a standard duty non-handed exit only device. Less bottom rod removes the bottom rod and floor strike from the opening, which matters where the floor is uneven or gets wet mopped.
20) What is a standard duty alternative to the BEST Precision 5203 for a lower traffic back door?
The 5203 is a Grade 1 device with heavy wrought steel construction and zinc dichromate plating, aimed at high traffic commercial openings. For lighter duty openings, the Design Hardware 2000V at 33 inch is a standard duty surface vertical rod device and the Orca OED56 at 36 inch is a standard duty exit only device. Design Hardware also offers the 1000V at 33 inch as a heavy duty device if the traffic is heavier than standard duty allows.
21) What finishes does the BEST Precision 5203 come in for matching other doors in a building?
Two painted finishes: 689 aluminum painted and 695 dark bronze painted. Both are available across every dogging, trim, and less bottom rod combination of the 36 inch device, so you can standardize a whole building on one color without giving up any option.
