BEST PHI 671DR Apex 2000 Series Rigid Dummy Touch Bar for Wide Stile Doors

Professional Dummy Touch Bar for Inactive Door Applications

The BEST PHI 671DR Apex 2000 Series Rigid Dummy Touch Bar provides a fixed pushpad solution for inactive door leaves and non-latching door applications. Designed for wide stile doors with minimum 4-1/2" stile width, this rigid dummy touchbar accommodates standard 1-3/4" to 2-1/4" thick doors and offers complete field reversibility for versatile installation. Constructed from durable aluminum, brass, bronze, or stainless steel depending on finish selection.

Professional Features & Benefits

  • Wide Stile Compatibility: Designed for doors with minimum 4-1/2" stile width for proper mounting and operation.
  • Door Thickness Range: Accommodates standard 1-3/4" to 2-1/4" thick doors for versatile commercial applications.
  • Rigid Dummy Design: Fixed pushpad provides consistent appearance without latching mechanism for inactive door leaves and matching applications.
  • Field Reversible Installation: Non-handed design allows complete field reversibility for flexible door configuration changes.
  • Durable Construction: Available in aluminum, brass, bronze, or stainless steel materials depending on finish selection for long-lasting performance.
  • Complete Fastener Package: Furnished standard with machine screws and full-thread wood/sheet metal screws, with optional Sex Nuts and Bolts (SNB) or Torx Security Screws (SEC) available.
  • Apex 2000 Series Integration: Part of the comprehensive Apex 2000 Series system for coordinated door hardware solutions.

Technical Specifications

Feature Specification
Manufacturer Precision Hardware Inc. (PHI) / BEST (dormakaba)
Series Apex 2000 Series
Device Type Rigid Dummy Pushbar
Action Inactive (Rigid touchpad; no latching mechanism)
Stile Type Wide Stile (Minimum 4-1/2" stile width recommended)
Handing Non-handed (Completely field reversible)
Fire-Rated No
Base Material Aluminum, Brass, Bronze, or Stainless Steel (depending on the chosen finish)
Door Thickness Accommodates standard 1-3/4" to 2-1/4" thick doors
Fasteners Furnished standard with machine screws and full-thread wood/sheet metal screws. (Sex Nuts and Bolts [SNB] or Torx Security Screws [SEC] are optional).

Installation & Operation

This accessory component is designed for use with compatible Apex 2000 Series exit devices and door hardware systems. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose BEST Quality?

BEST PHI 671DR dummy touch bars deliver professional-grade reliability with durable aluminum, brass, bronze, or stainless steel construction rated for demanding commercial applications. The Apex 2000 Series provides comprehensive system integration with field-reversible design for maximum installation flexibility. Engineered for commercial environments where dependable performance and coordinated appearance are essential.

Manufacturer Resources

Precision 2000 Series Catalog

Product Specs

Series:
Apex 2000
Subcategory:
Exit Devices Accessories
Product Group:
Exit Devices and Trim
Product Subgroup:
Exit Devices Accessories
Commercial/Residential:
Commercial
Product Type:
Case Assembly
Product Category:
Parts and Accessories
Department:
Door Hardware

BEST 671DR-3 630 – Frequently Asked Questions

1) Does the BEST PHI 671DR dummy touch bar actually latch the door?
No. The 671DR is a rigid dummy pushbar with no latching mechanism at all. The touchpad is fixed and does not move. It exists to put a matching push bar on an inactive leaf or a non-latching door so the pair looks the same from the pull side. If you need the door to latch and release, you need a working Apex 2000 exit device, not the 671DR.
2) What stile width and door thickness does the PHI 671DR dummy bar need?
Wide stile only: a minimum of 4-1/2 inches of stile width is required for proper mounting. Door thickness range is 1-3/4 to 2-1/4 inches, so it covers standard commercial doors and thicker leaves. On an aluminum storefront door with a narrow 2 inch stile it will not mount; that opening needs a narrow stile dummy bar instead.
3) Can I use the PHI 671DR on a fire rated door pair?
The 671DR is not fire rated. For a labeled opening, the hardware on both leaves has to carry the appropriate listing, so this dummy bar is not the part for that application. Use it on non-rated inactive leaves and non-latching doors.
4) Do I have to order the 671DR handed for a left or right hand door?
No handing to specify. The 671DR is non-handed and completely field reversible, so one part covers left and right hand leaves. That also means if the opening gets reconfigured later, the same bar can be flipped rather than replaced.
5) What sizes and finishes does the Apex 2000 671DR dummy touch bar come in?
Two lengths, 3 foot and 4 foot, each offered in 628 satin aluminum and 630 satin stainless steel. Pick the length that matches the working exit device on the active leaf so the two bars line up visually. Base material follows the finish, aluminum, brass, bronze or stainless depending on selection.
6) Do mounting screws come with the 671DR, or do I need to order fasteners separately?
Fasteners are included as standard: machine screws plus full-thread wood and sheet metal screws, which covers hollow metal and wood doors out of the box. If the job calls for through-bolting or tamper resistance, sex nuts and bolts (SNB) and Torx security screws (SEC) are available as options and have to be specified on the order.
7) My building has Apex 2000 exit devices on the active doors. Will a dummy bar match them?
That is what the 671DR is for. It is part of the Apex 2000 Series, so the pushbar profile and finish line up with the working devices on the rest of the openings. Order it in the same finish, 628 or 630, and in the length matching the device on the active leaf.
8) Where does a rigid dummy push bar like the 671DR get used instead of a real exit device?
Three common cases: the inactive leaf of a door pair where only one side needs to open, a door that is pushed open and held by a closer with no latch, and an opening where the owner wants the exit device look on both leaves for appearance. Any door that is part of an egress path and needs to unlatch under push should get a functioning device, not a dummy.
