Spec Sheet
Product Specs
- Bus Material:
- Zinc die cast
- Number Of Elements:
- 2
- Product Category:
- Deep cover
- Series:
- 10250T
- Department:
- Electrical
- Product Type:
- 30.5 mm, Heavy-Duty Watertight/Oiltight
- Product Length:
- 6.2 IN
- Product Details:
- 30.5 mm, Heavy-Duty Watertight/Oiltight
- Mounting Method:
- Flush
- Performance Rating:
- NEMA 1
- Product Height:
- 4.1 IN
- Product Weight:
- 1.25 LB
- Product Width:
- 5.3 IN
B-LINE 10250TF12 – Frequently Asked Questions
1) How many pushbuttons or operators will the B-Line 10250TF12 cover hold?
The 10250TF12 cover is a two-element cover, so it takes two 30.5 mm operators, whether that is two pushbuttons, a pushbutton and a selector switch, or a pushbutton and a pilot light. If your enclosure needs three or more holes, this is the wrong cover.
2) What NEMA rating does the B-Line 10250TF12 pushbutton cover carry?
NEMA 1. That is an indoor, general-purpose enclosure rating covering incidental contact with the enclosed equipment and falling dirt. It is not a washdown or outdoor rating, so if the station sits where it gets hosed down or sees weather, specify a higher-rated enclosure cover.
3) Do the pushbuttons and contact blocks come with this cover?
No. The 10250TF12 is the cover only, a two-hole zinc die cast plate for 30.5 mm operators. Order the operators, legend plates and contact blocks separately to complete the station.
4) Is this a flush cover or does it stand off the enclosure?
It is a flush-mounting deep cover. The deep profile gives clearance behind the plate for the operator bodies and wiring, while the mounting itself sits flush to the box. If your panel layout needs a flat shallow cover, this is not it.
5) What are the dimensions of the 10250TF12 enclosure cover?
It measures 6.2 inches long, 5.3 inches wide and 4.1 inches high, and weighs 1.25 lb. Check those against the box you are covering before ordering, particularly the 4.1 inch height, which reflects the deep profile needed to clear the operator bodies.
6) What material is the B-Line 10250TF12 cover made from?
Zinc die cast. That gives a rigid cover that holds the operator threads square under repeated actuation, which is why it is used on industrial stations rather than a stamped sheet metal plate.
