Quazite PG/PC Series Precast P...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$175.15
Quazite PG/PC Series Precast Polymer Concrete Underground Box

Quazite PG/PC Series Precast Polymer Concrete Underground Box

(No reviews yet) Write a Review

Model: PC0608BA06

In Stock (leaves warehouse same day if ordered before 3pm ET)

$175.15
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Quazite PG/PC Series Precast Polymer Concrete Underground Box, Fiberglass Reinforced

The Quazite PG/PC Series is a family of precast, fiberglass-reinforced polymer concrete underground boxes engineered for below-grade cable, splice, and equipment access in electrical, telecommunications, and utility distribution systems. This model line is available in a range of straight-wall box sizes — from the compact PC0608BA06 up through the large-format PG3636BA36 — covering options such as PC0608BA06, PC1118BA12, PC1212BA12, PG1118BA12, PG1118BA18, PG2424BA24, and PG3636BA36, so contractors can select the footprint that matches the job's cable, splice, or equipment access requirements. Every box in the series shares a standard open bottom and is built from polymer concrete reinforced with fiberglass, delivering the structural strength and long-term durability required for buried applications while resisting the corrosion, cracking, and degradation common to traditional concrete boxes exposed to moisture and soil chemistry. Quazite underground boxes are a standard choice among contractors and utilities for creating accessible, protected below-grade compartments for wiring, connectors, and splices across a wide range of project sizes.

Key Features

  • Range of Box Sizes: Available across the PG/PC Series lineup, from smaller straight boxes like PC0608BA06 up to large enclosures such as PG3636BA36, to fit varying below-grade installation footprints.
  • Durable Construction: Precast polymer concrete reinforced with fiberglass for high structural strength and resistance to cracking, corrosion, and moisture damage in buried environments.
  • Standard Open Bottom: Shared across the series, this configuration facilitates natural drainage and simplifies cable entry and routing directly from the surrounding earth.
  • Straight Box Configuration: Uniform straight-wall design across all models supports consistent below-grade cable and splice access.
  • Precast Manufacturing: Factory-precast construction ensures consistent dimensional accuracy and structural integrity across every unit in the series.
  • Lightweight Relative to Traditional Concrete: Polymer concrete composition offers easier handling and installation compared to conventional poured concrete enclosures, regardless of the size selected.

Technical Specifications

  • Model Options: PC0608BA06, PC1118BA12, PC1212BA12, PG1118BA12, PG1118BA18, PG2424BA24, PG3636BA36
  • Material: Polymer Concrete, Fiberglass Reinforced
  • Bottom Configuration: Standard Open Bottom
  • Box Style: Straight

Typical Applications

  • Underground Electrical Cable and Splice Access
  • Telecommunications and Data Cable Enclosures
  • Utility Distribution System Access Points
  • Below-Grade Wiring Compartments for Commercial and Municipal Projects
  • New Construction and Underground Infrastructure Upgrades

Why Quazite?

Quazite underground enclosures are built from fiberglass-reinforced polymer concrete, a material chosen specifically for its resistance to the corrosion and structural fatigue that affect traditional concrete boxes over years of below-grade exposure. Across the PG/PC Series, contractors and utilities get a consistent, factory-manufactured straight box with a standard open bottom for dependable cable and splice access, with a size available for nearly every underground installation need.

Manufacturer Resources

Product Specs

Product Type:
Underground Box
Configuration:
Straight Box, Open Bottom
Department:
Electrical
Product Group:
Boxes & Enclosures
Product Subgroup:
Underground Pull Boxes
list_batch:
QZT-20260924
Product Material:
Fiberglass-Reinforced Polymer Concrete
Series:
PG/PC Series

Quazite PC0608BA06 – Frequently Asked Questions

1) Does a Quazite PG/PC Series underground box come with a cover, or do I order that separately?
The PG/PC Series order here is the box itself, a precast fiberglass-reinforced polymer concrete straight box with an open bottom. Covers are a separate item on Quazite enclosures, so plan on specifying a matching cover sized to the box you pick (PC0608BA06 through PG3636BA36) along with the legend and load rating your job calls for.
2) Do I need to pour a concrete base or gravel bed under a Quazite open bottom box?
Open bottom is the standard configuration on every box in the PG/PC Series, so the box sits on compacted bedding, not a sealed floor. Normal practice is a compacted crushed stone bed under the box for drainage and to keep the walls from settling out of level with the grade. Conduits and cable enter from the earth side rather than through a precast knockout.
3) Which Quazite PG/PC size should I use for a simple low voltage or irrigation pull point versus a utility splice?
For a small pull or junction point the PC0608BA06 is the compact option in the line. Mid-size pulls and telecom splices usually land on PC1212BA12, PC1118BA12, or the deeper PG1118BA18. For primary cable splicing or equipment access where a lineman needs room to work, the PG2424BA24 and PG3636BA36 are the large-format choices. Pick on cable bend radius and splice volume first, then depth.
4) Can I use a Quazite polymer concrete box in a driveway or parking lot?
Traffic capability is set by the cover and box rating you specify, not by the material alone. The PG/PC Series boxes are precast fiberglass-reinforced polymer concrete, strong enough for buried service, but anything in a drive lane or parking area needs a box and cover assembly rated for vehicular load. For landscaped areas, walkways, and non-traffic shoulders a pedestrian-rated cover is the usual pick.
5) Why choose a Quazite polymer concrete box over a standard precast concrete handhole?
Two reasons contractors give: weight and corrosion. Polymer concrete reinforced with fiberglass is substantially lighter than poured or precast concrete of the same footprint, so a crew can often set the smaller sizes without a crane. It also resists the cracking, corrosion, and moisture degradation that work on conventional concrete sitting in wet or chemically aggressive soil. If you need a buried box you will have to open again in ten years, that matters more than the first-day cost.
6) Is the PC prefix box different from the PG prefix box on a Quazite underground enclosure?
Both are straight-wall, open-bottom precast polymer concrete boxes in the same Quazite family. The prefix marks the product line tier rather than a change in material or bottom configuration, and the sizes overlap: an 11 x 18 x 12 is offered as both PC1118BA12 and PG1118BA12. If a drawing or utility spec calls out one prefix specifically, order that prefix, since inspectors do check it.
7) Will a Quazite PG/PC box work for fiber and communications cable, not just power?
Yes. The PG/PC Series is used for underground electrical cable and splice access, telecommunications and data cable enclosures, and utility distribution access points. The non-conductive polymer concrete body is one reason communications crews favor it. For fiber, size on bend radius and slack storage rather than cable count, which typically pushes you to PG1118BA18 or larger.
