Cooper Wiring Devices 50A Range Power Receptacle, NEMA 10-50R, Black

Cooper Wiring Devices 50A Range Power Receptacle, NEMA 10-50R, Black

(No reviews yet) Write a Review

Model: COOPCOO-112

In Stock (leaves warehouse same day if ordered before 3pm ET)

$5.79
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Cooper Wiring Devices 50A Range Power Receptacle, NEMA 10-50R, Black

The Cooper Wiring Devices 50A Range Power Receptacle is a heavy-duty, three-pole, three-wire, non grounding electrical receptacle engineered for dedicated range and oven circuits. Rated 125/250V and 50A, this device is built to the NEMA 10-50R configuration, the standard pattern for electric range power cords. Constructed from glass-filled nylon, the receptacle offers strength and heat resistance suited to high-draw kitchen appliance circuits, while its flush mounting design and back and bottom wiring method allow for straightforward installation in a standard wall box. Screw-type connection terminals accommodate wire sizes from #12 AWG up to 4 AWG, giving installers flexibility when matching wire gauge to circuit demand. Finished in black and designed for use with S80 range cordsets, this receptacle is a practical solution for replacing worn range outlets or wiring new kitchen circuits.

Key Features

  • Amperage & Voltage Rating: 50A at 125/250V supports the demanding electrical load of range and cooking-appliance circuits.
  • NEMA 10-50R Configuration: Three-pole, three-wire, non grounding design matched to standard electric range power cords.
  • Durable Construction: Molded glass-filled nylon body provides strength and heat resistance for long-term reliability.
  • Wiring Method: Back and bottom wiring with screw connection terminals accepts wire sizes from #12 to 4 AWG.
  • Mounting Type: Flush mounting for clean, standard wall box installation.
  • Compatibility: Designed for use with S80 range cordsets for a dependable connection.
  • Finish: Black finish for a clean, uniform appearance on range and appliance installations.

Technical Specifications

  • Amperage Rating: 50A
  • Used With: S80
  • Receptacle Type: Three-pole, three-wire, non grounding
  • Voltage Rating: 125/250V
  • Allowable Wire Size: #12 - 4 AWG
  • Wiring Method: Back and bottom
  • Connection Type: Screw
  • Mounting Type: Flush
  • Material: Glass-filled nylon
  • Color: Black

Typical Applications

  • Electric Range and Oven Power Circuits
  • Residential Kitchen Wiring
  • Replacement of Worn or Damaged Range Receptacles
  • New Construction and Kitchen Renovation Projects
  • Light Commercial Kitchen Installations

Why Cooper Wiring Devices?

Cooper Wiring Devices is a trusted name in professional-grade wiring devices, and this range receptacle reflects that standard with durable glass-filled nylon construction and a 50A, 125/250V rating built for heavy-duty appliance circuits. Its NEMA 10-50R configuration, screw-terminal wiring, and flush mounting design make it a dependable, straightforward choice for electricians and contractors wiring or replacing range and oven receptacles.

Manufacturer Resources

Product Specs

Receptacle Type:
Three-pole, three-wire, non grounding
Voltage Rating:
125/250V
Wiring Method:
Back and bottom
Number Of Poles:
Three-pole
Allowable Wire Size:
#12 - 4 AWG
Connection Type:
Screw
Amperage Rating:
50A
Installation Category:
Flush
Special Features:
Range
Nema Configuration:
10-50R
Used With:
S80
Product Style:
Power
Number Of Wires:
Three-wire
Design Type:
Receptacle
Product Type:
Receptacle
Product Material:
Glass-Filled Nylon
Product Color:
Black
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Receptacles & Outlets

Cooper Wiring Devices COOPCOO-112 – Frequently Asked Questions

1) Can I replace an old 3-prong range outlet with this Cooper receptacle on the existing wiring?
Yes, that is the usual use for the Cooper 112. It matches the existing three-pole, three-wire non grounding 10-50R pattern, so an existing 3-wire range circuit lands straight on it with no cord change. Terminals are screw type with back and bottom wiring, and it is flush mounted in a standard wall box. Note that new range circuits are generally run as 4-wire today, so this is for keeping an existing 3-wire installation in service.
2) Does this range receptacle have a ground terminal?
No ground terminal. The Cooper 112 is a non grounding three-wire device, so the neutral conductor serves as the bonded return in the legacy 3-wire range arrangement. If your installation requires a separate equipment ground at the appliance, you need a 4-wire 14-50R device instead.
3) What wire gauge can I land on the terminals of this 50A range receptacle?
Screw terminals on the Cooper 112 accept #12 AWG through 4 AWG. That covers the 6 AWG copper typically pulled for a 50A range circuit as well as larger aluminum conductors if that is what is in the wall.
4) Is a 125/250V 50A receptacle right for an electric range, or do I need a 240V-only device?
The 125/250V rating is what a residential electric range wants. The 10-50R configuration carries two hot legs and a neutral, giving 240V to the heating elements and 120V to clocks, lights and controls off the same device. A straight 250V two-pole receptacle cannot supply the 120V side.
5) I need a 50A receptacle for industrial equipment, not a range. Is this the right one?
Not likely. The Cooper 112 is a flush-mount straight-blade range device for dedicated range and oven circuits. For industrial 50A service where the plug must not pull out, the Eaton 7379 industrial locking receptacle is rated 50A at 600V/250V AC/DC in black, and for hazardous locations the Appleton FSQC Series interlocked explosionproof receptacle is the category to look at.
6) Can I mount this 50A range receptacle on the surface instead of in a wall box?
No. It is a flush-mount device, wired from the back and bottom, so it is built to drop into a standard recessed wall box. A surface installation needs a surface-mount range receptacle or a box extension, not this one.
7) The kitchen has a 240V appliance in a wet or washdown area. Is the Cooper 112 the right device?
The Cooper 112 is a flush-mount, glass-filled nylon range receptacle for a standard wall box on a dedicated 50A, 125/250V circuit, which suits residential and light commercial kitchens. For hazardous or washdown environments, Appleton offers sealed alternatives: the FSQC Series interlocked explosionproof receptacle and the U-Line ECS factory-sealed 15 and 20 amp three-pole plug and receptacle set.
8) Does the Cooper 112 offer an isolated ground option like the Pass & Seymour IG5362-I?
No. The Cooper 112 is a three-pole, three-wire non grounding device, which is the standard arrangement for the NEMA 10-50R range pattern. An isolated ground device such as the Pass & Seymour IG5362-I, a heavy-duty spec-grade isolated ground duplex rated 20A at 125V, serves sensitive 125V equipment circuits rather than range outlets.
9) Will the Bryant 430R9W work where the Cooper 112 is specified?
No. The Bryant 430R9W 4750DR is a 2-pole, 3-wire 277V motor-duty receptacle, intended for motor loads on a 277V circuit. The Cooper 112 is a three-pole, three-wire 50A device at 125/250V in the NEMA 10-50R configuration for range and oven cords. The pole count and voltage differ, so the two are not interchangeable.
10) What cordset pairs with the Cooper 112 range receptacle?
It is specified for use with S80 range cordsets. Any 3-wire 10-50P range cord of that type plugs in; order the cordset separately since only the receptacle is supplied.
11) Will the body hold up behind a range that runs hot?
The housing is molded glass-filled nylon, chosen for strength and heat resistance on high-draw appliance circuits, and the device is black. For property managers standardizing kitchens, the same device and color can be repeated across units on existing 3-wire range circuits.
