Rittal 3114200 Digital Enclosure Temperature Display and Thermostat

The Rittal 3114200 Digital Enclosure Temperature Display and Thermostat installs directly in the enclosure door or wall, giving panel builders and maintenance techs a real-time reading of internal cabinet temperature. It combines a three-digit, 7-segment display with a switchable C/F readout, an 1800 mm long NTC sensor, and a rated operating voltage of 100 V - 230 V, 1~, 50 Hz/60 Hz or 24 V - 60 V (DC) for flexible power compatibility. Two relay outputs with a freely selectable switching difference let the unit drive cooling or heating equipment across a 5 C-55 C setting range, while the housing itself is rated for a 0 C-50 C operating temperature range and a -20 C-70 C storage temperature range.

Key Features

  • Digital Display: Three-digit, 7-segment display with the option of switching between C/F for quick, accurate readouts.
  • Long-Reach NTC Sensor: 1800 mm long NTC sensor positions temperature sensing precisely where it is needed inside the enclosure.
  • Dual Relay Outputs: Two relay outputs, a change-over contact and a normally open contact, with max contact load of 230 V, 6 A and a freely selectable switching difference.
  • Rated Operating Voltage: 100 V - 230 V, 1~, 50 Hz/60 Hz, or 24 V - 60 V (DC), supporting both AC and DC control circuits.
  • Setting Range: Thermostat setpoint adjustable from 5 C to 55 C to match enclosure climate requirements.
  • Operating Temperature Range: 0 C-50 C for reliable performance in industrial environments.
  • Storage Temperature Range: -20 C-70 C.
  • Finish: RAL 7035 housing color for consistent appearance on Rittal enclosures.

Technical Specifications

  • Refer to manufacturer documentation for complete specifications.

Typical Applications

  • Electrical and Industrial Enclosure Climate Monitoring
  • Panel and Cabinet Internal Temperature Control
  • Enclosure Door or Wall-Mounted Installations
  • Commercial and Industrial Control Panels
  • Thermal Management for Sensitive Electronic Components

Why Rittal?

Rittal engineers the 3114200 with a precision long-reach NTC sensor, dual relay outputs, and a wide 100 V - 230 V / 24 V - 60 V (DC) voltage range so it fits directly into existing enclosure control schemes. The switchable C/F display and freely selectable switching difference give installers flexible, dependable temperature control for panels and cabinets built to Rittal's enclosure standards.

Manufacturer Resources

Rittal Product Catalog

Product Specs

Product Type:
Thermostat
Voltage Rating:
100-230V AC / 24-60V DC
Amperage Rating:
6A
Configuration:
Door/Wall Mount
Product Color:
RAL 7035
Department:
Electrical
Product Group:
Wiring Devices

Rittal 3114200 – Frequently Asked Questions

1) Can the Rittal 3114200 enclosure thermostat run both a heater and a cooling unit at the same time?
Yes. The 3114200 has two relay outputs, one change-over contact and one normally open contact, so you can drive cooling equipment off one and heating off the other. The switching difference is freely selectable, so you set the deadband between the two yourself rather than living with a fixed hysteresis. Max contact load on the outputs is 230 V, 6 A, so anything bigger than that needs to go through a contactor.
2) Will a Rittal 3114200 thermostat work on a 24 VDC control panel?
It will. The 3114200 accepts either 100 V - 230 V, 1~, 50/60 Hz, or 24 V - 60 V DC, so it drops into AC line-powered panels and low-voltage DC control schemes without a separate supply. Note the supply rating is separate from the contact rating: the relay contacts are rated 230 V, 6 A regardless of which supply you feed the unit from.
3) Does the Rittal 3114200 mount in the enclosure door or on the wall of the cabinet?
Either. The 3114200 is a door/wall mount unit, so it installs through the enclosure door or through a cabinet side wall depending on where you want the display readable. The sensor is a separate NTC lead 1800 mm long, so the display can sit where an operator sees it while the sensing point goes wherever the hot spot actually is inside the cabinet.
4) Can I switch a 1500 W panel heater directly from the Rittal 3114200 thermostat?
Not directly at 120 V. The relay contacts on the 3114200 are rated 230 V, 6 A, which is about 1380 W at 230 V and roughly 720 W at 120 V. A 1500 W heater needs a contactor or relay sized for the load, with the thermostat contact driving the coil. Small enclosure heaters and fan units inside the contact rating can be wired straight to the output.
5) What temperature setpoints can I dial in on the Rittal 3114200, and does it read in Fahrenheit?
Setpoints are adjustable from 5 C to 55 C (41 F to 131 F). The readout is a three-digit, 7-segment display that switches between C and F, so a US maintenance tech can work in Fahrenheit even though the unit is specified in Celsius.
6) Can I install a Rittal 3114200 in an unheated outbuilding or a cold storage area?
The housing is rated for a 0 C to 50 C ambient operating range (32 F to 122 F), so an unheated space that drops below freezing is outside what the unit is rated to run in. Storage is wider, -20 C to 70 C, which covers shipping and a cold warehouse shelf, but that is not an operating rating.
7) Should I use a digital thermostat with a display like the 3114200 or a plain mechanical enclosure thermostat?
A mechanical dial thermostat just switches at a setpoint. The Rittal 3114200 adds a numeric readout of actual cabinet temperature, which is what you want when you are troubleshooting a thermal trip or proving to a customer that the panel is running hot. It also gives two outputs instead of one, so a single unit handles heating and cooling, and the switching difference is adjustable rather than fixed. If all you need is on/off control of one fan and nobody ever looks at the panel, the display is not buying you anything.
8) Will the Rittal 3114200 match the other components on my Rittal enclosure?
The housing is RAL 7035, the light grey Rittal uses across its enclosure line, so a door-mounted 3114200 reads as part of the cabinet rather than an add-on. For a facility standardizing on one thermostat across a fleet of panels, the same part number covers both AC and DC panels because it takes 100-230 V AC or 24-60 V DC.
9) What is the Rittal part number I order this enclosure thermostat by?
Order it as Rittal 3114200. That is the manufacturer part number for the digital enclosure temperature display and thermostat with the 1800 mm NTC sensor, dual relay outputs and 100-230 V AC / 24-60 V DC supply. There is a single configuration, so there is no finish, voltage or sensor-length option to specify on the order.
