RTLED2X4-39NW/D10
RTLED2X4-39NW/D10 - spec sheet
Features
- 0-10V dimming standard
- Equivalency
- Warranty
- Frosted polycarbonate lens provides a uniform distribution and reduces glare
- Trade Agreements Act Compliant
- Buy American Act Compliance
- Troffer Retrofit can be installed in under 3 minutes by 1 person
- 5-Year, No-Compromise Warranty
RTLED2X4-39NW/D10 - spec sheet
Manufacturer Resources
Product Specs
- 208v:
- 0.20A
- 277v:
- 0.15A
- Ambient Temperature:
- Suitable for use in up to 40°C (104°F)
- Color Stability:
- LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
- Efficacy:
- 135 lm/W
- Finish:
- Formulated for high durability and long-lasting color
- Green Technology:
- Mercury and UV free. RoHS-compliant components.
- Housing:
- Steel sheet metal
- Input Watts:
- 39W
- Lumens:
- 5,269 lm
- Note:
- All values are typical (tolerance +/- 10%)
- Reflector:
- High-reflectance, powder-coated finish, optimized for uniform light distribution
- Thd:
- 7.9% at 120V, 9.5% at 277V
- Watts:
- 39W
- Weight:
- 19.2 lbs
- Product Group:
- Lighting
- Product Subgroup:
- LED Fixtures
- Department:
- Electrical
