OVERVIEW
The 7 Line key-in-lever lock exceeds ANSI/BHMA A156.2 standards for cycling and durability. This product is designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities.
FEATURES
- Combines durability and aesthetics with a solid feel and attractive design
- Conveniently installs in one minute or less; user-friendly packaging and instructions
- Available with all SARGENT key systems (Degree, Signature, KESO, and XC)
- Internal through-bolts minimize additional door preparation
- Complete offering of architectural grade finishes
- 15 architectural grade finishes and Microshield® antimicrobial coating
BENEFITS
- Flexible: Ideal for many applications with 10 functions; fits modified 161 door preps
- Strength: Internal through-bolts supply strength and stability without requiring additional door preparation
CERTIFICATIONS
- ANSI/SDI 250.13 Certified
- ASTM E330 Certified
- Florida Building Code Approved FL# 2998
- Americans with Disabilities Act (ADA) Compliant
- UL-cUL Fire-Rated Up to 3 Hours
- ASTM E1996 Certified
- ASTM E1886 Certified
- NFPA 80 Compliant
- TAS 201 Certified
- TAS 202 Certified
- TAS 203 Certified
- ICC A117.1 Compliant
PRODUCT SPECIFICATIONS
- ANSI/BHMA Code: A156.2
- ANSI/BHMA Series: Series 4000
- Backset Depth (Standard): 2 3/4"
- Door Thickness (Standard): 1 3/4"
- Grade: Grade 2
- Handing: Non-handed
- Latchbolt Throw: 1/2"
- Maximum Backset: 2 3/4"
- Minimum Backset: 2 3/8"
- Maximum Door Thickness: 1 3/4"
- Minimum Door Thickness: 1 3/8"
- Number of Keys: 2
- Strike Type (Standard): T-Strike Curved Lip
- UL Listed: Yes
- ULC Listed: Yes
- Warranty: 5-year limited warranty
Manufacturer Resources
Product Specs
- Category:
- Mechanical Locks
- Series:
- 7 Line Series
- Grade:
- Grade 2
- Handing:
- Non-Handed
- Keyed Function:
- Single Cylinder
- Subcategory:
- Bored Locks
- Keyed:
- Yes
- Function:
- Classroom
- Commercial/Residential:
- Commercial
- Lock Type:
- Cylindrical
- Lock Function:
- Classroom
- Product Group:
- Mechanical Locks
- Product Subgroup:
- Bored Locksets
- Product Type:
- Bored Locks
- Duty Level:
- Standard Duty
- Handle Type:
- Lever
- Product Attribute:
- Cylindrical Locks
