Sargent F1826415 Keso F1 Rim Type Security Cylinder with Satin Nickel Finish

(No reviews yet) Write a Review

Model: F1826415

In Stock (leaves warehouse same day if ordered before 3pm ET)

$308.85
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Sargent Keso F1 Rim Type Security Cylinder with Grade 1 Certification and Satin Nickel Finish

Professional High-Security Cylinder Solution

The Sargent Keso F1 Rim Type Security Cylinder delivers ANSI/BHMA A156.8 Grade 1 certified performance with premium satin nickel finish for demanding commercial applications. This high-security cylinder features advanced Keso F1 technology designed for rim-type installations where maximum security and durability are essential. Grade 1 certification ensures reliable operation in high-traffic commercial environments with professional-grade construction and precision manufacturing for long-term reliability.

Professional Features & Benefits

  • Grade 1 Security Certification: ANSI/BHMA A156.8 Grade 1 certified for maximum security and durability in commercial applications.
  • Advanced Keso F1 Technology: High-security cylinder design provides superior pick resistance and key control for critical access points.
  • Rim Type Configuration: Specifically engineered for rim cylinder applications with precise dimensional tolerances for proper fit and function.
  • Premium Satin Nickel Finish: Durable satin nickel finish provides corrosion resistance and maintains professional appearance in high-use environments.
  • Commercial-Grade Construction: Heavy-duty materials and precision manufacturing ensure long-term reliability in demanding commercial installations.
  • Professional Key Control: Keso F1 system provides restricted keyway access and enhanced key control for security-sensitive applications.
  • Manufacturer Warranty: 2 Year Limited warranty provides added confidence and protection for commercial installations.

Technical Specifications

  • ANSI/BHMA: Certain Models ANSI/BHMA A156.8, Grade 1 Certified
  • Arm Specification: Slide Track
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Swing: Single or Double Acting
  • Duty Level: Standard Duty
  • Fasteners: Torx Screws Optional
  • Grade: Grade 1
  • Hold Open Feature: Yes
  • Mounting Method: Concealed
  • Product Category: Door Controls
  • Product Group: Door Controls
  • Product Subgroup: Overhead Stops and Holders
  • Product Type: Overhead Stops and Holders - Concealed Mount
  • Series: 10 Series
  • Subcategory: Concealed
  • Warranty: 2 Year Limited

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Financial Institutions
  • Industrial and Warehouse Facilities
  • High-Security Access Control Points

Why Choose Sargent Quality?

Sargent security cylinders deliver professional-grade reliability with ANSI/BHMA A156.8 Grade 1 certified performance and advanced Keso F1 high-security technology. The 2 Year Limited warranty provides added confidence for commercial installations. Engineered for demanding commercial applications where dependable security performance and key control are essential.

Manufacturer Resources

SARGENT Full Line Catalog

Product Specs

Commercial/Residential:
Commercial
Product Group:
Mechanical Locks
Product Subgroup:
Parts and Accessories
Product Type:
Cylinders
Parts and Accessories Type:
Replacement Parts
Product Attribute:
Parts and Accessories
Department:
Door Hardware
Product Category:
Mechanical Locks
Subcategory:
Parts and Accessories

Sargent F1826415 – Frequently Asked Questions

1) Is the Sargent F1826415 a rim cylinder or a mortise cylinder?
It's a rim cylinder. The Sargent Keso F1 F1826415 is built for rim-type installations, meaning it mounts through the door and drives a rim device or rim exit device with a tailpiece rather than threading into a mortise lock body. If your lock body takes a threaded mortise cylinder with a cam, this is the wrong style and you want a Keso F1 mortise cylinder instead.
2) Can I get keys cut for a Keso F1 cylinder at a hardware store?
No. Keso F1 is a restricted, high-security keyway with factory key control, so blanks are not sold over the counter and duplication runs through an authorized Sargent channel. That's the point of the system for a property manager or facility with sensitive doors: nobody copies a key at a kiosk. Plan your keying and key records with your Sargent dealer before the cylinders go in.
3) Will the Keso F1 rim cylinder key into my existing Sargent LA or RA keyway master system?
No. Keso F1 is its own high-security platform and does not interchange with Sargent's conventional pin tumbler keyways. If you're adding secure doors to a building that runs a standard Sargent keyway, those doors become a separate key system unless you convert the whole facility to Keso. Budget for that decision before you buy a single cylinder.
4) Is this a complete lock or just a replacement cylinder?
Just the cylinder. The F1826415 is a replacement part, so the rim exit device, rim lock, or auxiliary lock body has to already be on the door. You're swapping the cylinder to upgrade key control or to rekey a door into a Keso system, not buying a latching device.
5) How do I order the right Sargent Keso F1 rim cylinder for a job?
Call out the model, the finish, and the keying. This one is F1826415 in satin nickel. Beyond that, your order needs to state whether the cylinders are keyed alike, keyed different, or mastered into an existing Keso F1 system, and the tailpiece required by the rim device you're mounting it in. A locksmith ordering a single replacement still needs the key records on file to have it cut to an existing system.
6) Is the Sargent Keso F1 cylinder suitable for residential use?
It's built and rated for commercial duty, and that's where it makes sense. High-security cylinders like this go on office buildings, schools, healthcare, government facilities, banks, and controlled access points where key duplication has to be locked down. A homeowner can install one, but the restricted key program is aimed at organizations that manage keys as an ongoing process.
