Product Specs
- Country Of Origin:
- Canada
- Product Height:
- 12
- Product Weight:
- 66 lbs
- Product Width:
- 12
- Reach Compliant:
- Yes
- Rohs Compliant:
- Yes
- Usmca Compliant:
- Yes
- Product Depth:
- 60
- Department:
- Electrical
- Product Group:
- Conduit & Raceway
- Product Subgroup:
- Wireway
- Product Type:
- Wireway
Hammond Manufacturing CWSC1260NK – Frequently Asked Questions
1) Does the CWSC1260NK come with knockouts punched in it?
No. The NK suffix means without knockouts, so the sides, top and bottom come blank. You drill or punch wherever your conduit lands, which is what you want on a custom layout but means more field work than a pre-punched trough. If you want factory knockouts on set centers, order the knockout version of the same size instead.
2) How heavy is a 12x12x60 Hammond wireway section, and how should it be supported?
66 pounds empty. With conductors filled in it gets heavier, so plan hangers or wall brackets rather than letting the cover flanges carry the load, and figure on two people to set a section at height.
3) Is this wireway RoHS and REACH compliant, and where is it made?
Yes to both, RoHS and REACH compliant. It's manufactured in Canada and qualifies as USMCA compliant, which matters if you're filing origin documentation on a government or institutional job.
4) Do I need anything besides straight sections to finish a wireway run?
Straight sections only cover the runs. A complete installation also needs end plates to close the ends, and elbows, tees or crosses wherever the run changes direction, plus connectors and hangers. Order those as separate 12 x 12 fittings to match this section's cross section.
