Schlage Commercial 12-289 - B500 Series Deadbolt Adjustable 2-3/8" or 2-3/4" Backset, 1" x 2-1/4" Face, 1/4" Round Corner

Both, from the same part. The 12-289 bolt adjusts between a 2-3/8 inch and a 2-3/4 inch backset, which are the two standard bore centers used on North American doors, so you don't have to know which one the door is drilled to before you order. To confirm what you have, measure from the door edge to the center of the cross bore, then set the adjustment before the bolt goes into the edge bore.

S200 and B500 Series deadbolts. Model 12-289 is the bolt assembly on its own, so it's what you order when the housing and cylinder are still good but the bolt is binding, chewed up at the strike, or set to the wrong backset for the door it has to go into.

The face measures 1 x 2-1/4 inches. If the bolt you're pulling out has a face that size, the 12-289 goes back into the same edge mortise with no rework. Larger and you're chiselling the pocket out; smaller and you're left with a gap around the plate that has to be filled.

626 satin chrome. Finish matters more than people expect on a service part like this, because Schlage parts are finish specific and the faceplate is the piece that stays visible on the door edge whenever the door is open. On a building already standardized on 626 trim it drops in without an odd plate showing.

Stainless steel, and it's a commercial-duty part rather than a residential one. Stainless is what you want on an opening that sees weather or salt air, since it won't rust out the way a plated steel bolt does once the plating wears through where the bolt rubs the strike.

Just the bolt. The 12-289 is a replacement bolt for S200 and B500 deadbolts, so there's no cylinder, no thumbturn and no keying supplied with it. If what you actually need is a complete standalone unit, the Lockey M230 is a keyless mechanical combination deadlocking spring latch lock with an adjustable backset that covers doors from 1-1/8 to 2 inches thick.

Two different jobs. The 12-289 is the bolt for a Schlage S200 or B500 deadbolt and adjusts to either standard backset. Deltana's Grade 1 regular latches are spring latches for a knob or lever, and they're ordered backset specific: G1RLE238 and G1RLE275 in the entry function at 2-3/8 and 2-3/4 inch, G1RLP238 and G1RLP275 in passage/privacy at the same two backsets. If the opening has a lever below and a separate deadbolt above, you're buying one of each, not one instead of the other.

A sidelite is its own application and has its own hardware. The Accentra YSSL10 is a security sidelite auxiliary latch with an ADA compliant thumbturn, built for 1-3/4 inch doors and fire rated, which is what a sidelite or narrow panel in a rated opening typically calls for. The Schlage 12-289 is the adjustable-backset deadbolt latch for Schlage S200 and B500 Series hardware in the main door leaf. On a storefront or institutional entry it is common to need both - the 12-289 behind the Schlage deadbolt on the active leaf and the YSSL10 in the sidelite.

They are two different parts serving two different sides of the opening. The Schlage 12-289 is a B500 Series deadbolt latch that adjusts between 2-3/8 inch and 2-3/4 inch backset and goes back into Schlage S200 and B500 Series hardware. The Deltana G1RLE275 is a Grade 1 regular latch with an entry function fixed at 2-3/4 inch backset, so it serves a keyed knob or lever rather than the deadbolt, and Deltana splits the backsets across two part numbers - G1RLE238 for 2-3/8 inch and G1RLE275 for 2-3/4 inch. If the door has both a lockset and a deadbolt, confirm which of the two you are actually pulling out before you order.

For an opening that only needs to hold the door closed or take a thumbturn, Deltana makes a Grade 1 regular latch in a passage/privacy function - the G1RLP238 for a 2-3/8 inch backset and the G1RLP275 for a 2-3/4 inch backset. Those pair with passage or privacy trim. The Schlage 12-289 is the deadbolt latch for Schlage S200 and B500 Series hardware and covers both 2-3/8 inch and 2-3/4 inch backset in a single adjustable part, which is the difference to weigh if you are stocking one part number for mixed backsets across a building.

The adjustable backset is the only thing the two have in common. The Lockey M230 is a complete mechanical keyless digital combination deadlocking spring latch lock with an adjustable backset, sized for doors 1-1/8 inch to 2 inch thick, so you are installing an entire keypad lock. The Schlage 12-289 is a replacement latch that goes back into Schlage S200 and B500 Series hardware already hanging on the door. Keep the existing Schlage trim and cylinder and you want the 12-289; convert the opening to keyless code entry and the M230 replaces the lock outright.

Latches of this kind are matched to the lock series they came out of, not just to the backset. The Dexter C1000-DL-630 is the deadlatch built for the Dexter C1000 Series, and the Schlage 12-289 is a certified Schlage part for the S200 and B500 Series. Identify the lock body actually in the door before either one leaves the shelf. One more check on the Schlage side: the 12-289 is stainless steel and supplied in 626 satin chrome, so it has to match the trim it seats behind.
