Schlage Electronics 46929303 AD Series Tailpiece Kit for Escutcheon Into Exit Device

It is the tailpiece kit that links a Schlage AD Series escutcheon to an exit device, so the AD escutcheon can drive the exit device's mechanism rather than a standard lock chassis. It ships as a replacement/service part for AD Series electronic access control openings, not as a complete trim or lock.

Just the tailpiece kit. The escutcheon itself, the exit device, and the cylinder are all ordered separately. If you are building a new AD Series exit device opening from scratch, this is one of several pieces you need, not the assembly.

No. It is built for the AD Series escutcheon-into-exit-device application. Other Schlage lines and other manufacturers' trim use their own tailpiece lengths and drive geometry, so a kit from a different family will not seat correctly. Match the part to an AD Series escutcheon.

They solve related problems on different platforms. The Schlage Electronics 46929303 is an AD Series tailpiece kit for driving an escutcheon into an exit device, so it is the linkage part that ties an AD Series electronic escutcheon to the exit device it is trimming. The Corbin Russwin CLX33905 packs are electrified tailpieces sold by cylinder type - for example the CR2000-E34 and Yale key-in-lever fixed core version for a 6-pin cylinder on a 1-3/8 inch to 2 inch door. If you are working on an AD Series opening, the 46929303 is the kit written for it; the CLX33905 packs are chosen by the cylinder you are installing, not by the AD trim.

Not necessarily. The 46929303 is an AD Series tailpiece kit for driving an escutcheon into an exit device, matched to the AD Series trim rather than to a keyway. If what you actually need is an electrified tailpiece sized to a Schlage or Sargent keyway fixed core cylinder, the Corbin Russwin CLX33905 pack built for Schlage and Sargent keyway fixed core cylinders covers a 1-3/8 inch to 2 inch door and is selected by that cylinder.

Often yes. The tailpiece is the mechanical link between the AD escutcheon and the exit device, so a worn, bent or mis-set tailpiece breaks the connection even when the electronics read the credential correctly. Kit 46929303 is the service part for that link.

Commercial. It is an AD Series electronic access control service part, and AD Series trim is commercial-grade hardware used on exit device openings in offices, schools, healthcare and multi-family common areas.

There is one configuration, model 46929303. No finish or length options to specify, since the tailpiece is concealed inside the trim and device.

Decide by what is already on the opening. Doors carrying Schlage AD Series electronic trim over an exit device take the 46929303 kit, which is the commercial AD Series replacement part for that escutcheon-to-exit-device connection. Doors where the electrified function runs through the cylinder take a CLX33905 pack matched to that cylinder - 6-pin CR2000-E34 and Yale key-in-lever, 7-pin CR2000-7-E34 and Yale fixed core, Schlage and Sargent keyway fixed core, or Yale LFIC - each sized for a 1-3/8 inch to 2 inch door. Stocking is usually a matter of counting how many of each opening type you have rather than picking one part for all of them.
