Schlage Residential SD10JSTP 78" Sliding Barn Door Track and Hardware Kit with Satin Nickel Finish

Schlage Residential SD10JSTP 78" Sliding Barn Door Track and Hardware Kit with Satin Nickel Finish

(No reviews yet) Write a Review

Model: SD10JSTP66622
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$344.00
$93.93
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schlage Residential SD10JSTP 78" Sliding Barn Door Track and Hardware Kit with Satin Nickel Finish

Complete Sliding Barn Door Hardware Solution for Interior Applications

The Schlage Residential SD10JSTP sliding barn door hardware kit delivers a stylish architectural solution for interior doorways with professional-grade steel construction. This complete 78" track system accommodates doors from 1-3/8" to 1-3/4" thick and supports up to 220 lbs, making it suitable for openings up to 50 inches wide. The durable steel construction with satin nickel finish coordinates with popular neutral color schemes while meeting the highest industry standards for residential applications.

Professional Features & Benefits

  • Complete Track System: 78" steel track with 11-1/8" height and 2-3/4" projection provides comprehensive hardware solution for single door installations.
  • Heavy-Duty Load Capacity: Supports doors weighing up to 220 lbs with door thickness compatibility from 1-3/8" to 1-3/4" for versatile residential applications.
  • Wide Opening Compatibility: 78" track length accommodates openings up to 50 inches wide, with 6 ft track option available for 36 inch openings.
  • Durable Steel Construction: Solid steel components meet highest industry standards for long-term reliability and smooth operation.
  • Complete Installation Kit: Includes all mounting hardware and detailed instructions for easy installation without additional components.
  • Expandable System Design: Compatible with Schlage Sliding Barn Door Track Adapter for bi-parting door configurations and larger openings.
  • Lifetime Warranty Coverage: Lifetime finish warranty with 100,000 cycles rating for added confidence and protection.
  • Coordinated Finish: Satin nickel finish complements popular neutral color schemes including grey for versatile design integration.

Standard Features

  • Affordable way to add privacy and style to open doorways
  • Complete kit with easy to install mounting hardware and detailed instructions
  • The 6 ft track is limited to a 36 inches opening, but the 8 ft track can be used for a wider opening up to 50 inches
  • Durable steel construction meets highest industry standards with limited lifetime warranty
  • Use with 1-3/8in. to 1-3/4in. thick door weighing up to 220lbs
  • Finish coordinates with popular neutrals like grey

Specifications:

  • Height: 11-1/8"
  • Length: 78"
  • Projection: 2-3/4"
  • Door Thickness: 1-3/8" to 1-3/4"
  • Material: Steel
  • Max Door Weight: 220 lbs

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness (1-3/8" to 1-3/4") and maximum weight (220 lbs) compatibility.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and wall surfaces for the 78" track system.
  3. Prepare door and mounting surface by drilling required holes per manufacturer specifications for track brackets and door hardware.
  4. Install track mounting brackets ensuring proper alignment and level installation across the full 78" length with 2-3/4" projection clearance.
  5. Mount door hardware components to door and hang door on track system, adjusting for smooth operation and proper clearances.
  6. Test door operation throughout full range of motion to verify smooth sliding action and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Residential Interior Doorways
  • Home Office Privacy Solutions
  • Master Bedroom Suite Separations
  • Kitchen and Dining Room Divisions
  • Basement and Recreation Room Access
  • Closet and Storage Area Entrances
  • Multi-Purpose Room Configurations

Why Choose Schlage Residential Quality?

Schlage Residential sliding barn door hardware delivers professional-grade reliability with solid steel construction rated for 100,000 cycles and backed by a lifetime finish warranty. The SD10JSTP system combines durability with style, featuring satin nickel finish that coordinates with popular neutral designs. Engineered for demanding residential applications where dependable performance and architectural appeal are essential.

Manufacturer Resources

Product Specs

Series:
SD10
Warranty:
Lifetime Finish 100,000 Cycles
Product Group:
Sliding Door and Barn Door Hardware
Product Subgroup:
Door Track
Product Type:
Door Track
Subcategory:
Door Track
Commercial/Residential:
Residential
Keyed:
No
Product Model:
SD10JSTP
Product Dimension:
78"
Product Category:
Sliding Door and Barn Door Hardware
Department:
Door Hardware

Schlage Residential SD10JSTP66622 – Frequently Asked Questions

1) Will the Schlage SD10JSTP barn door kit work on a 1-3/8 inch door, or does it need a 1-3/4?
Either one. The SD10JSTP hangers mount to doors 1-3/8 to 1-3/4 inches thick, which covers both a standard hollow-core interior slab and a solid 1-3/4 inch door. Weight is the other half of the check: the kit carries a door up to 220 lbs, so a heavy solid-core or reclaimed slab needs to be weighed before you commit.
2) How wide an opening will a 78 inch barn door track cover?
The 78 inch (6 ft 6 in) track handles openings up to 50 inches wide. The rule of thumb behind that is the door has to be wider than the opening and then slide fully clear of it, so the track runs roughly double the opening. If your opening is wider than 50 inches, the 78 inch track is the wrong length and you want a longer track or a bi-parting setup.
3) How much wall clearance do I need behind a Schlage SD10 barn door track?
Plan on 2-3/4 inches of projection off the wall, plus the door thickness itself. That projection is what clears the door slab past casing and trim, so check for anything in the swing path: door casing, base trim, light switches, and any wall art within the slide zone. The mounted assembly stands 11-1/8 inches tall, which is what you need above the opening for the track and brackets.
4) Is the Schlage SD10JSTP a complete kit, or do I need to buy hangers and a floor guide separately?
It ships complete for a single door: the 78 inch steel track, J-strap hangers, all mounting hardware, and instructions. Nothing else is required to hang one door. The one thing you supply is the door itself and appropriate wall anchoring for your framing.
5) Can I run two barn doors that meet in the middle with the Schlage SD10 hardware?
Not out of the box. The SD10JSTP is configured for a single door. For a bi-parting pair or a wider opening, the system takes the Schlage Sliding Barn Door Track Adapter, which joins tracks for that configuration. Order the adapter alongside the kits if that is the layout.
6) Should I get the 6 ft or the 8 ft Schlage barn door track for my doorway?
It comes down to opening width. The 6 ft track is limited to a 36 inch opening. The 8 ft track goes up to a 50 inch opening. Measure the finished opening, not the door, and size up rather than down, since a track that is too short leaves part of the doorway exposed when the door is parked.
7) Does a barn door kit like the Schlage SD10JSTP lock, and is it suitable for a bathroom?
No lock. The SD10 kit is track and hangers only, with no keying and no latch, so it gives visual separation and privacy of sight but not a secured opening. For a bathroom or any door that needs to latch, plan on a separate barn door privacy lock or pull-with-latch, and confirm it works with the 2-3/4 inch wall projection this track sets.
8) Is Schlage SD10 barn door hardware rated for a commercial building or apartment corridor?
This is residential-rated hardware, steel construction rated to 100,000 cycles. That suits apartments, offices in a home, and unit interiors. For a high-traffic commercial corridor or an opening that has to be fire rated or code-compliant egress, a sliding barn door setup is the wrong solution entirely and you want a swinging fire door assembly.
9) What finishes does the Schlage SD10JSTP barn door track come in?
Four: 619 Satin Nickel, 622 Matte Black, 630 Satin Stainless Steel, and 716 Aged Bronze. If you are matching hardware across a unit or a floor of apartments, those are standard Schlage finish codes, so the track can be specified to line up with the lever and hinge finishes already on the job.
