Schneider 9065SF/SFB/SFC/ST Series Overload Relay Heaters — 20A Rating

Schneider Electric 9065SF/SFB/SFC/ST Series Overload Relay Heaters - 20A 3-Phase Solid State Motor Protection

(No reviews yet) Write a Review

Model: 9065SFB20

In Stock (leaves warehouse same day if ordered before 3pm ET)

$312.94
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schneider Electric 9065SF/SFB/SFC/ST Series Overload Relay Heaters - 20A 3-Phase Solid State Motor Protection

Professional Motor Protection with Solid State Technology

Schneider Electric 9065SF/SFB/SFC/ST Series Overload Relay Heaters deliver reliable 20A motor protection with advanced solid state thermal overload technology. Part of the Motor Logic range, these 3-phase overload relay heaters provide precise motor protection with mounting plate installation for professional electrical applications. The compact design measures 3.26" W x 2.69" H x 3.9" D, offering space-efficient protection for motor control systems.

Professional Features & Benefits

  • 20A Rating: Provides precise current protection for medium-duty motor applications with reliable overload detection.
  • 3-Phase Configuration: Ensures comprehensive protection across all three phases for balanced motor operation and system reliability.
  • Solid State Thermal Overload: Advanced electronic protection technology delivers faster response times and enhanced accuracy compared to traditional bimetallic designs.
  • Motor Logic Range: Part of Schneider Electric's comprehensive motor control system for integrated protection and control solutions.
  • Mounting Plate Support: Standard mounting configuration enables secure installation in control panels and motor control centers.
  • Compact Dimensions: Space-efficient 3.26" x 2.69" x 3.9" footprint maximizes panel space utilization while maintaining full protection capability.
  • RoHS Compliant: Meets environmental standards with exemptions for professional electrical equipment applications.

Technical Specifications

  • China Rohs In Scope: No
  • Circularity Profile: ENVEOLI1312002EN
  • Country Of Origin: Mexico
  • End Of Life Doc Ref: ENVEOLI1312002EN
  • Environmental Disclosure: ENVPEP1312002EN
  • Eoli Availability Display: Yes
  • Eu Rohs Directive: Compliant with Exemptions
  • Function Option: Standard
  • Function Option Id: STANDARD
  • Legacy Weee Scope: In
  • Manufacturer: Schneider Electric
  • Mercury Free: Yes
  • Mounting Support: mounting plate
  • Packaging Made With Recycled Cardboard: Yes
  • Packaging Without Single Use Plastic: No
  • Phase: 3 phase
  • Product Availability: Stock - Normally stocked in distribution facility
  • Product Contributes To Saved And Avoided Emissions: No
  • Product Depth: 3.9 in
  • Product Height: 2.69 in
  • Product Width: 3.26 in
  • Range Of Product: Motor Logic
  • Recycled Metal Content At Cr Level: 0%
  • Relationshiptype: Compatible relationship
  • Return Indicator: Y
  • Returnability: Yes
  • Rohs Eur Conformity Date: 1925
  • Rohs Eur Full Compliance Status: Compliant with Exemptions
  • Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
  • Rohs Eur In Scope: Yes
  • Rohs Eur Status: Compliant with Exemptions
  • Rohs Exemption Information: Yes
  • Scope Perimeter: At least in Europe
  • Sustainable Packaging: No
  • Take Back: No
  • Thermal Overload Type: solid state
  • Tier: 1
  • Tier Id: 1
  • Use Carbon Footprint: 5.06903703
  • Wd Status: 1 - GSC certified
  • With Recycled Cardboard: Yes
  • Without Single Use Plastic: No
