3M Scotch 130C Linerless Rubber Splicing Tape 3/4 in x 30 ft Premium Grade Electrical Insulation

3M Scotch 130C Linerless Rubber Splicing Tape 3/4 in x 30 ft Premium Grade Electrical Insulation

Professional Grade Electrical Insulation & Splicing Solution

The 3M Scotch 130C Linerless Rubber Splicing Tape delivers professional-grade electrical insulation and splicing performance with its highly conformable rubber-resin adhesive and self-fusing ethylene propylene rubber backing. This premium grade tape provides excellent UV resistance, thermal dissipation, and moisture sealing capabilities for high-voltage applications up to 69 kV, making it ideal for demanding electrical installations and repairs.

Professional Features & Benefits

• 69 kV Voltage Rating: Handles high-voltage applications safely with superior dielectric strength of 750 V/mil for reliable electrical isolation.
• Premium Grade Construction: Self-fusing ethylene propylene rubber backing with rubber-resin adhesive ensures long-lasting, void-free buildups and excellent mechanical properties.
• Temperature Performance: Withstands operating temperatures up to 194�F (90�C) while maintaining electrical and mechanical integrity for demanding environments.
• UV Resistant Design: Ethylene propylene rubber backing provides excellent UV resistance for outdoor and exposed applications.
• Linerless Application: Self-sticking design eliminates liner waste and enables quick, efficient installation with superior conformability.
• Moisture Sealing: Creates excellent moisture seal and thermal dissipation properties to protect electrical connections from environmental factors.
• ASTM Approved: Meets ASTM standards and RoHS 2011/65/EU compliance for professional electrical applications.

Technical Specifications

• Adhesive Material: Rubber Resin
• Application: Insulation
• Backing Material: Ethylene Rubber
• Backing Thickness Metric: 0.76 mm
• Breaking Strength Imperial: 7.5 lb/in
• Color Family Incorporate Product Color: Black
• Dielectric Strength: 750 V/mil
• Dielectric Strength V Mil: 750
• Elongation: 850%
• Elongation At Break: 850%
• High Temperature Rating: 194�F (90�C)
• Insulated: Yes
• Insulation Resistance: >10^15 Ohm
• Liner Linerless: Linerless
• Manufacturer Catalog Number: 7000006085
• Manufacturing Origin: USA
• Maximum Operating Temperature Celsius: 90 Degree Celsius
• Maximum Operating Temperature Fahrenheit: 194 Degree Fahrenheit
• Minimum Operating Temperature Celsius: 0 Degree Celsius
• Operating Temperature Celsius: Up to 90 �C
• Operating Temperature Fahrenheit: Up to 194 �F
• Overall Length Imperial: 30 ft
• Overall Length Metric: 9.1 m
• Overall Width Imperial: 0.75 in
• Overall Width Metric: 19 mm
• Package Height: 0.95000 in
• Package Length: 4.60000 in
• Package Weight: 0.4150 LBS
• Product Material: Linerless EPR
• Self Extinguishing: No
• Self Sticking: Yes
• Shelf Life: 5 Year
• Suitable For High Voltage: Yes
• Tape Color: Black
• Tape Grade: Premium
• Tape Type: Professional Grade Rubber Tape
• Tape Width Imperial: 0.75 in
• Tape Width Metric: 19.1 mm
• Tensile Strength Imperial: 250 psi
• Tensile Strength Metric: 1723 kPa
• Total Tape Thickness Without Liner Metric: 0.76 mm
• Total Thickness: 0.76 mm
• Uv Resistant: Yes
• Voltage Application: High Voltage
• Voltage Rating: 69 kV
• Vulcanizing: Yes

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• High-Voltage Electrical Splicing and Insulation
• Utility Power Line Maintenance and Repair
• Industrial Electrical System Installations
• Commercial Building Electrical Infrastructure
• Outdoor Electrical Connection Protection
• Emergency Electrical Repair Services
• Professional Electrical Contractor Applications

Why Choose 3M Quality?

3M Scotch 130C tape delivers proven reliability with ASTM approval, RoHS compliance, and a 5-year shelf life. The premium grade construction and USA manufacturing ensure consistent performance in demanding electrical applications, backed by 3M's reputation for professional-grade electrical products.
