3M Scotch Rubber Mastic Electrical Insulation Tape 2228 - 2 in x 10 ft Black EPR with UV Protection

3M Scotch Rubber Mastic Electrical Insulation Tape 2228 - 2 in x 10 ft Black EPR with UV Protection

Professional electrical insulation and vibration padding for demanding applications

3M Scotch Rubber Mastic Electrical Insulation Tape 2228 delivers reliable primary electrical insulation for cable and wire connections up to 1000 volts. This professional-grade tape features ethylene propylene rubber backing with UV protection and operates in temperatures up to 194�F (90�C). The thick construction enables quick application build-up and effective padding over irregular connections, making it ideal for motor leads and vibration-sensitive applications.

Professional Features & Benefits

• 1000 Volt Rating: Provides primary electrical insulation for high-voltage cable and wire connections with reliable dielectric strength of 500 V/mil
• High Temperature Performance: Withstands operating temperatures up to 194�F (90�C) for demanding industrial and commercial environments
• UV Protection: Ethylene propylene rubber backing resists UV degradation for long-lasting outdoor and exposed applications
• Thick Construction: 1.65mm thickness allows rapid application build-up and effective padding over irregular connection points
• Self-Adhesive Design: Self-sticking properties eliminate need for additional adhesives while maintaining strong 15.0 lb/in adhesion to steel
• RoHS Compliant: Meets RoHS 2011/65/EU environmental compliance standards for professional installations
• Vibration Dampening: Specialized mastic formulation provides effective vibration padding for motor leads and sensitive equipment

Technical Specifications

• Adhesion To Steel: 15.0lb/in (26,2N/10mm)
• Application: Insulation
• Backing Material: Ethylene Propylene Rubber
• Breaking Strength Imperial : 150 lb.
• Color Family Incorporate Product Color : Black
• Dielectric Strength V Mil : 500 V/mil
• Elongation: 10%
• Elongation At Break: 10
• Liner Linerless: Liner
• Manufacturer Catalog Number: 7000005986
• Maximum Operating Temperature Celsius : 90 Degree Celsius
• Maximum Operating Temperature Fahrenheit : 194 Degree Fahrenheit
• Minimum Operating Temperature Celsius : 0 Degree Celsius
• Overall Length Imperial : 10 ft
• Overall Length Metric : 3 m
• Overall Width Imperial : 2 in
• Overall Width Metric : 50.8 mm
• Package Height: 4.05000 in
• Package Length: 2.75000 in
• Package Weight: 0.8850 LBS
• Product Material: EPR with Liner
• Self Sticking: Yes
• Tape Color: Black
• Tape Width Imperial : 2 in
• Tape Width Metric : 50.8 mm
• Total Tape Thickness Without Liner Metric : 1.65 mm
• Total Thickness: 1.65 mm
• Uv Resistant: Yes
• Vulcanizing: No

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Primary electrical insulation for cable and wire connections up to 1000 volts
• Vibration padding for motor leads in industrial equipment
• Outdoor electrical connections requiring UV protection
• High-temperature electrical applications up to 194�F
• Commercial and industrial wire splicing and terminations
• Equipment installations requiring environmental compliance

Why Choose 3M Quality?

3M Scotch Rubber Mastic Tape 2228 delivers proven reliability with RoHS 2011/65/EU compliance and professional-grade ethylene propylene rubber construction. The UV-resistant backing and high-temperature performance ensure long-lasting protection in demanding electrical applications, backed by 3M's commitment to quality and innovation.
