Sioux Chief 613-57X Tub Spout Ell, 5" x 7" MIP Swivel, Type L Copper

Sioux Chief 613-57X Tub Spout Ell, 5" x 7" MIP Swivel, Type L Copper

(No reviews yet) Write a Review

Model: 613-57X

In Stock (leaves warehouse same day if ordered before 3pm ET)

$13.94
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
"

Sioux Chief 613-57X Tub Spout Ell, 5\" x 7\" MIP Swivel, Type L Copper

The Sioux Chief 613-57X Tub Spout Ell is a full-flow, Type L copper tube fitting built for connecting a tub valve to the spout nipple in a single step. Sized 5\" x 7\" with an MIP swivel connection, this fitting features a 1-1/4\" radius designed to fit all standard valve rough-ins, making it a dependable choice for tub installations behind the finished wall. Manufactured with NL/DZR (no-lead, dezincification-resistant) construction, the 613-57X is built for rough-in plumbers who need a reliable, code-conscious connector between the tub spout and the supply valve.

Key Features

  • Trade Size: 5\" x 7\" MIP swivel configuration sized to common tub rough-in dimensions.
  • Full-Flow Construction: Built from Type L copper tube for consistent flow and durability in tub supply applications.
  • 1-1/4\" Radius: Engineered to fit all valve rough-ins, simplifying installation across a range of tub valve setups.
  • MIP Swivel Connection: Connects the tub valve to the spout nipple in one easy step, reducing installation time.
  • NL/DZR Material: No-lead, dezincification-resistant construction for long-term durability in potable water contact applications.
  • Installation Note: Do NOT use thread sealant on the FIP swivel threads — the swivel connection is designed to seal without it.

Technical Specifications

  • Country of Origin: United States
  • Cubic Volume: 0.38145
  • Packaging: 50 EA

Typical Applications

  • Residential Tub Valve-to-Spout Rough-In Connections
  • New Construction Bathtub Plumbing Installations
  • Tub Valve Replacement and Remodel Work
  • Behind-the-Wall Supply Connections for Tub Spouts

Why Sioux Chief?

Sioux Chief builds rough-in plumbing components for professionals who need parts that go together right the first time. The 613-57X's full-flow Type L copper tube construction, NL/DZR material, and 1-1/4\" radius designed to fit all valve rough-ins reflect a focus on practical jobsite performance. For plumbers and contractors handling tub valve connections, this fitting offers a straightforward, one-step connection between valve and spout nipple.

Prop 65 WARNING

"

Manufacturer Resources

Product Specs

Product Type:
Tub Spout Elbow
Connection Type:
Threaded
Standards:
No-Lead
Country of Origin:
United States
Department:
Plumbing
Product Group:
Rough-In and Supports
Product Subgroup:
Fittings and Valves
Product Material:
Copper
Product Size:
5" x 7"

Sioux Chief 613-57X – Frequently Asked Questions

1) What does the Sioux Chief 613-57X tub spout ell actually do in a tub rough-in?
The 613-57X is the copper ell that carries water from the tub valve down to the spout nipple behind the wall. It is a 5 inch by 7 inch leg configuration in Type L copper tube with an MIP swivel connection, so it joins the valve to the spout nipple in one piece instead of building the drop out of loose fittings. It sits concealed in the wall cavity; the only visible part of the assembly is the spout itself.
2) Should I use pipe dope or Teflon tape on the swivel threads of this tub spout ell?
No. Sioux Chief specifically says not to use thread sealant on the FIP swivel threads of the 613-57X. The swivel is designed to seal on its own, and sealant on those threads can keep it from seating properly. Sealant still applies to ordinary threaded joints elsewhere in the assembly, just not the swivel.
3) Is the Sioux Chief 613-57X ell approved for potable water and lead-free codes?
The fitting is NL/DZR, meaning no-lead and dezincification-resistant, and it carries a No-Lead standards designation. That is what inspectors look for on potable water contact in tub supply rough-ins. It is made in the United States.
4) Can I use this copper tub spout ell on a remodel, or is it only for new construction?
Both. The 613-57X is used for new construction bathtub rough-ins and for tub valve replacement and remodel work. On a remodel you need wall access behind the valve to make up the swivel connection and solder the Type L copper leg, so it suits open-wall or access-panel situations rather than a trim-only swap.
5) Why pick a one-piece copper tub spout ell over assembling the drop from a nipple and a street elbow?
A one-piece ell like the 613-57X gives you a single full-flow copper path from valve to spout nipple with one swivel joint to make up, instead of two or three threaded joints buried in a wall. Fewer joints behind finished tile means fewer places to leak, and the fixed 1-1/4 inch radius means the geometry is already correct for standard valve rough-ins rather than something you have to fit up on site.
6) How does this come packaged if I am buying for a multi-family or production job?
The 613-57X ships 50 each per pack, which is how production plumbers and multi-family rough-in crews buy it. Order by model 613-57X.
