Sioux Chief ProPlate 699 Serie...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$18.83
Sioux Chief ProPlate 699 Series Rough-In Valve, Replaceable Valve

Sioux Chief ProPlate 699 Series Rough-In Valve, Replaceable Valve

(No reviews yet) Write a Review

Model: 699-A1-WR

In Stock (leaves warehouse same day if ordered before 3pm ET)

$18.83
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Sioux Chief ProPlate 699 Series Rough-In Valve with Replaceable Valve

The Sioux Chief ProPlate 699 Series Rough-In Valve is an all-in-one rough-in valve assembly built for plumbers who need to set a fixture stub out fast and walk away from a clean, code-ready connection. This single installed unit combines a quarter-turn ball valve, an escutcheon, a stub out, and a mounting bracket, and the ProPlate line is available in two outlet connection options to match the rough-in method on the job: a 3/8" OD Compression connection or an F1960 PEX Stub Out connection. A debris cover is included on every configuration to keep the valve body protected from drywall mud, paint overspray, and job-site grit during the rough-in phase of construction, so the valve is ready to use once walls are finished and trim-out begins. Sioux Chief engineered the ProPlate line with a patented, replaceable valve design, meaning the internal valve cartridge can be serviced or swapped without re-cutting into the wall or disturbing the stub out behind it — a significant time saver for callbacks and future repairs. Whether the installation calls for a compression fitting for appliance or fixture supply, or a PEX expansion connection feeding into a PEX rough-in system, the ProPlate configuration simplifies supply points for ice makers, washing machines, or other single-point fixture connections. Packaging is supplied 10 EA per case for distributor and contractor stocking.

Key Features

  • Connection Options: available with a 3/8" OD Compression outlet connection or an F1960 PEX Stub Out connection, selectable to match the rough-in method on the job.
  • Quarter-Turn Ball Valve: allows quick on/off shutoff at the stub out without needing a separate supply stop.
  • All-in-One Rough-In Assembly: combines the valve, escutcheon, stub out, and mounting bracket into one installed component, reducing the number of separate parts a plumber has to source and set.
  • Patented, Replaceable Valve Design: the valve cartridge can be replaced in the field without disturbing the surrounding wall finish or the stub out.
  • Debris Cover Included: protects the valve and connection point from construction debris between rough-in and trim-out.
  • Mounting Bracket: secures the stub out assembly to framing for a stable, properly positioned rough-in point.
  • Packaging: supplied 10 EA per case for distributor and contractor stocking.

Technical Specifications

  • Country of Origin: China
  • Packaging: 10 EA per case
  • Connection Options: 3/8" OD Compression or F1960 PEX Stub Out

Typical Applications

  • Residential and Commercial Rough-In Plumbing
  • Washing Machine and Ice Maker Supply Stub Outs
  • PEX Supply Line Fixture Connections
  • Appliance and Fixture Compression Supply Connections
  • New Construction Framing Rough-In
  • Renovation and Remodel Supply Line Replacement

Why Sioux Chief?

Sioux Chief designed the ProPlate 699 Series to simplify rough-in plumbing by consolidating the valve, escutcheon, stub out, and bracket into a single installed part, with a patented valve design that can be replaced in the field if service is ever needed. The included debris cover and the choice of a 3/8" OD Compression or F1960 PEX Stub Out connection make this a practical, job-site-ready solution for plumbers setting fixture supply points behind the wall, whether the rough-in method calls for compression or PEX expansion connections, with cases packed 10 EA for distributor and contractor stocking.

Manufacturer Resources

Spec Sheet

Product Specs

Product Subgroup:
Fittings and Valves
Country of Origin:
China
Product Size:
3/8"
Product Type:
Rough-In Valve
Product Group:
Rough-In and Supports
Department:
Plumbing
Configuration:
Replaceable Valve Cartridge

Sioux Chief 699-A1-WR – Frequently Asked Questions

1) Does the Sioux Chief 699-A1 ProPlate connect to PEX, and which PEX system?
The 699-A1EWR version of the ProPlate rough-in valve uses an F1960 PEX connection on the rough-in side, so it is made for F1960 PEX expansion fittings (the cold-expansion system). It is not a crimp or press connection. The 699-A1-WR version instead comes with a 3/8 inch compression connection.
2) What size is the outlet on the ProPlate rough-in valve for hooking up an ice maker or washer line?
The outlet is a 3/8 inch OD compression connection, which is the standard size for an ice maker or washing machine supply line and for most 3/8 inch braided appliance connectors. No separate supply stop is needed because the quarter-turn ball valve is built into the assembly.
3) Do I still need to buy an escutcheon, bracket and stop separately with the Sioux Chief ProPlate?
No. The ProPlate is a single assembly that includes the quarter-turn ball valve, the escutcheon, the stub out, and the mounting bracket, plus a debris cover for the rough-in phase. The only thing you add at trim-out is the fixture or appliance supply line itself, which lands on the 3/8 inch OD compression outlet.
4) If the valve fails after the wall is closed up, do I have to open the drywall?
No. The ProPlate uses a patented replaceable valve design, so the valve cartridge can be swapped in the field without disturbing the wall finish or the PEX stub out behind it. That is the main reason property managers and maintenance crews spec it over a plain stub out with a separate stop sweated or crimped on.
5) Can the ProPlate be used on a remodel, or is it only for new framing?
Both. The ProPlate is used for new construction framing rough-in and for renovation or remodel supply line replacement, as well as washing machine and ice maker stub outs and general PEX fixture supply connections. The mounting bracket needs framing to fasten to, so on a remodel you need access to a stud or blocking behind the wall.
6) How does the Sioux Chief ProPlate ship for stocking?
The ProPlate rough-in valve is packaged 10 each per case, which is how most distributors and plumbing contractors stock it. It is made in China.
7) Does the ProPlate valve protect itself from drywall mud and paint during construction?
A debris cover ships with the assembly and stays on the valve body through rough-in, keeping drywall mud, paint overspray, and job-site grit out of the valve and the connection point until trim-out begins.
