Square D Linergy FT GV2G Series Comb Busbar, 63A 3P

Square D Linergy FT GV2G Series Comb Busbar, 63A 3P

(No reviews yet) Write a Review

Model: GV2G245

In Stock (leaves warehouse same day if ordered before 3pm ET)

$37.63
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Square D Linergy FT GV2G Series Comb Busbar, 63A 3P

The Square D Linergy FT GV2G Series Comb Busbar is a TeSys GV busbar set built for the upstream parallel wiring of groups of motor starters composed of GV2 motor circuit breakers or LS1D32 fuse carriers. Rated 3-phase (3P) with a 63A conventional free air thermal current (Ith) and 690V rated insulation voltage (Ui), this busbar is designed for use with screw clamp terminal devices. This family is available in 2, 3, or 4 tap-off outlet configurations on a 45mm pitch, giving panel builders the flexibility to wire small or larger groups of motor starters off a single compact busbar run.

Key Features

  • Pitch & Tap-Offs: 45mm pitch with a choice of 2, 3, or 4 tap-off outlets for connecting multiple motor starter groups off a single busbar run.
  • Screw Clamp Connection: Compatible with screw clamp terminal devices, including GV2 motor circuit breakers or LS1D32 fuse carriers.
  • Electrical Rating: 63A conventional free air thermal current (Ith) and 690V rated insulation voltage (Ui) for reliable 3-phase (3P) power distribution.
  • Range Compatibility: Compatible with TeSys K, TeSys GV2, TeSys U, TeSys Deca, and TeSys fuse-disconnector product ranges.
  • Sustainable Materials: Toxic heavy metal free and mercury free construction, part of the Green Premium product line.
  • Sustainable Packaging: Packaged with recycled cardboard content to reduce environmental impact.

Certifications & Compliance

  • RoHS Eur Compliant
  • Mercury Free
  • Toxic Heavy Metal Free
  • REACH: Free of Substances of Very High Concern (SVHC) above the threshold

Technical Specifications

  • Amperage Rating: 63A
  • Configuration: 3P
  • Insulation Voltage: 690V
  • Fixing Mode: terminals
  • Warranty: 18 months
  • Country of Origin: Romania
  • Green Premium Status: Green Premium product
  • Mercury Free: Yes
  • Toxic Heavy Metal Free: Yes
  • Sustainable Packaging: Yes, with recycled cardboard content

Typical Applications

  • Motor Control Center (MCC) Panel Wiring
  • Upstream Parallel Wiring of Motor Starter Groups
  • Industrial and Commercial Electrical Panels
  • TeSys GV2, K, U, and Deca Motor Circuit Breaker Assemblies
  • Fuse-Disconnector Group Wiring

Why Square D?

Square D backs the Linergy FT GV2G Series Comb Busbar with an 18-month warranty and Green Premium environmental credentials, including toxic heavy metal free and mercury free construction. Built for compatibility across the TeSys K, GV2, U, Deca, and fuse-disconnector ranges, and available with 2, 3, or 4 tap-off outlets, it delivers dependable, code-compliant power distribution rated 63A 3P at 690V for professional motor control panel builds.

Manufacturer Resources

Product Specs

Product Type:
Motor Starter Busbar
Voltage Rating:
690V
Amperage Rating:
63A
Configuration:
3P
Connection Type:
Screw Clamp
Department:
Electrical
Product Group:
Motor Control & Automation
Product Subgroup:
Motor Starters & Contactors

Square D GV2G245 – Frequently Asked Questions

1) Which motor starters does the Square D GV2G comb busbar feed?
The Linergy FT GV2G comb busbar is built for upstream parallel wiring of groups of GV2 motor circuit breakers or LS1D32 fuse carriers, and it is compatible across the TeSys K, TeSys GV2, TeSys U, TeSys Deca, and TeSys fuse-disconnector ranges. The devices it connects to must have screw clamp terminals.
2) How many motor starters can I mount on one GV2G busbar?
Two, three, or four, depending on which version you order. The GV2G comb busbar comes with 2 tap-off outlets (GV2G245), 3 tap-offs (GV2G345), or 4 tap-offs (GV2G445). Tap-offs sit on a 45mm pitch, so your starter spacing in the panel has to match that pitch.
3) What is the current limit on a Square D GV2G busbar for sizing my feeder?
It carries a 63A conventional free air thermal current (Ith) across three phases, with a 690V rated insulation voltage (Ui). Total load of the starter group tapping off the bar has to stay within that 63A, so it suits small motor groups rather than a high-current MCC section.
4) How does the GV2G busbar attach to the starters, and do I need extra hardware?
Fixing is through the terminals themselves. The comb teeth land in the screw clamp terminals of the GV2 breakers or LS1D32 fuse carriers and are tightened down, so the bar is held by the device terminals rather than a separate mounting bracket. That also means it only works with screw clamp terminal devices, not spring-clamp or lug versions.
5) Will the GV2G comb busbar work on a 480V or 600V three-phase panel?
Yes. The rated insulation voltage (Ui) is 690V, which covers 480V and 600V three-phase distribution. It is a 3-pole bar, so it is for three-phase groups, not single-phase runs.
6) Does the Square D GV2G busbar meet RoHS and REACH for a green building spec?
It is a Green Premium product: RoHS Eur compliant, mercury free, toxic heavy metal free, and free of REACH Substances of Very High Concern above the threshold. Packaging uses recycled cardboard content. Country of origin is Romania.
