Spec Sheet
Product Specs
- Field color:
- Red
- Legend:
- Blank legend
- Lettering Color:
- White
- Notes:
- Has a satin aluminum field. Color is on lower portion. Cannot be used on cast enclosures except for top row. Suitable for most sheet metal enclosures.
- Series:
- 10250T
- Used With:
- 10250T Series, All Operator Types
- Department:
- Electrical
- Product Size:
- Jumbo, square
- Product Length:
- 2.2 IN
- Product Height:
- .1 IN
- Product Weight:
- .02 LB
- Product Width:
- 2.2 IN
B-LINE 10250TL37 – Frequently Asked Questions
1) Will the B-Line 10250TL37 legend plate fit my 10250T pushbutton or selector switch?
The 10250TL37 square legend plate is made for the 10250T Series and works with all operator types in that series, so pushbuttons, selector switches and pilot lights all take it. It is the jumbo square size, measuring 2.2 by 2.2 inches with a .1 inch thickness.
2) Can I mount the 10250TL37 legend plate on a cast enclosure?
No, not generally. The 10250TL37 cannot be used on cast enclosures except in the top row. It is intended for most sheet metal enclosures. If your station is a cast device box, plan on a different plate style for anything below the top row.
3) Does this B-Line legend plate come with text on it, or do I engrave it myself?
It ships blank. The 10250TL37 carries a blank legend, so there is no factory wording to work around if you need to mark it for your own function. The lettering color for the series marking is white on the red field area.
4) What does the red on the 10250TL37 legend plate actually look like on the panel?
The plate has a satin aluminum field with the red color running across the lower portion, and white lettering. So on a control panel it reads as a brushed metal square with a red band at the bottom, which is the usual convention for stop or emergency functions.
5) I'm standardizing legend plates across a plant, is the 10250TL37 the square or the round style?
Square, and in the jumbo size at 2.2 by 2.2 inches. If your existing stations use the round jumbo plates, this will not match them visually even though both mount to the same 10250T operators. Order to whichever shape is already on the panel face.
6) What part number do I order for the B-Line square jumbo legend plate?
Order by MPN 10250TL37. That is the single model for this square jumbo plate with the red lower field and blank legend.
How fast can I get the B-LINE 10250TL37 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the B-LINE 10250TL37 come with a warranty?
Absolutely. The B-LINE 10250TL37 is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the B-LINE 10250TL37?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
