BEST CECSFBB168-54 Steel Full Mortise Concealed Bearing Electrified Hinge with 4-Wire Concealed Switch

BEST CECSFBB168-54 Steel Full Mortise Concealed Bearing Electrified Hinge with 4-Wire Concealed Switch

(No reviews yet) Write a Review

Model: BEST-CECSFBB168-54LH-652-5x5
$315.45
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$315.45
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEST CECSFBB168-54 Steel Full Mortise Concealed Bearing Electrified Hinge with 4-Wire Concealed Switch

Heavy-Duty Electrified Hinge with Concealed Switch Technology

The BEST CECSFBB168-54 is a heavy-weight electrified hinge engineered for commercial door applications, featuring steel construction with full mortise design and concealed bearings. This electrified hinge incorporates a concealed switch (CS) feature that allows for discreet integration of electrical monitoring within the hinge itself. The 4-wire configuration provides increased versatility and compatibility for integrating electronic access control systems, enabling secure and controlled access monitoring while maintaining tamper-proof operation.

Professional Features & Benefits

  • Concealed Switch Technology: "CS" (Concealed Switch) allows opening monitoring with switch operation when door is either open or closed for discreet security integration.
  • Heavy-Duty Steel Construction: Steel full mortise design with concealed bearings provides exceptional durability for demanding commercial applications.
  • 4-Wire Configuration: Enhanced wiring capability offers increased versatility and compatibility for electronic access control system integration.
  • Tamper-Proof Design: No electrical parts are exposed when hinge is installed, providing secure monitoring without visible electrical components.
  • Single Pole Double Throw Switch: Versatile switching capability for activating alarms, monitoring devices, or other security equipment applications.
  • Complete Installation Package: Packed one per box with screws and installation instructions for professional installation.
  • 5-Knuckle Full Mortise Design: Professional-grade construction with concealed bearings for smooth operation and long-term reliability.

Technical Specifications

  • Bearing Type: Concealed Bearing
  • Commercial/Residential: Commercial
  • Corner Style: Square Corners
  • Department: Door Hardware
  • Duty Level: Heavy Duty
  • Electronic: Yes
  • Hinge Type: Electrified
  • Knuckles: 5
  • Lock Type: Mortise
  • Number of Wires: 4
  • Package Includes: Concealed Switch, Concealed Conductor
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: CECSFBB168-54
  • Product Subgroup: Electrified Hinges
  • Product Type: Electrified Hinges
  • Series: Electrified Hinges
  • Subcategory: Hinges

Installation & Operation

  1. Verify electrical requirements and confirm compatibility with existing access control systems before proceeding with installation.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Install hinge in the center hinge location as specified by manufacturer guidelines for proper electrical function and door operation.
  4. Route and connect 4-wire configuration according to manufacturer wiring diagrams, ensuring proper connections for concealed switch operation.
  5. Configure switch settings for door open/closed monitoring per application requirements and security system specifications.
  6. Restore power and test all functions including concealed switch operation, door monitoring capabilities, and integration with connected alarm or monitoring systems.
  7. Complete final inspection and document wiring configuration. Refer to manufacturer documentation for complete installation specifications and troubleshooting.

Professional Applications

  • Commercial Building Security Systems
  • Healthcare Facility Access Control
  • Educational Institution Safety Systems
  • Government and Municipal Buildings
  • Industrial Facility Monitoring
  • Retail Loss Prevention Systems
  • Multi-Tenant Commercial Properties

Tamper-Resistant Design

The concealed switch design ensures no electrical parts are exposed when the hinge is installed, providing tamper-proof monitoring capability. This feature is essential for applications requiring secure door monitoring without visible electrical components that could be compromised or tampered with.

Why Choose BEST Quality?

BEST electrified hinges deliver professional-grade reliability with heavy-duty steel construction and concealed bearing design engineered for demanding commercial applications. The concealed switch technology provides tamper-proof monitoring capability while maintaining the aesthetic integrity of the door installation. Engineered for commercial environments where dependable performance and security monitoring are essential.

Product Specs

Subcategory:
Hinges
Series:
Electrified Hinges
Hinge Type:
Electrified
Knuckles:
5
Bearing Type:
Concealed Bearing
Corner Style:
Square Corners
Product Group:
Door Hinges and Pivots
Product Subgroup:
Electrified Hinges
Product Type:
Electrified Hinges
Number of Wires:
4
Duty Level:
Heavy Duty
Commercial/Residential:
Commercial
Electronic:
Yes
Lock Type:
Mortise
Package Includes:
Concealed Switch, Concealed Conductor
Product Model:
CECSFBB168-54
Product Category:
Door Hinges and Pivots
Department:
Door Hardware

BEST BEST-CECSFBB168-54LH-652-5x5 – Frequently Asked Questions

1) Do I need to specify handing when ordering the BEST CECSFBB168-54 electrified hinge?
Yes, handing is part of the order. The CECSFBB168-54 comes left-handed or right-handed, both in 5 x 5 inch size and 652 satin chrome. Because the switch and conductor are built into the hinge body, a left-hand hinge won't serve a right-hand opening, so determine the door's hand at the frame before you order.
2) What does the CS concealed switch in this BEST hinge actually do for a monitored opening?
It gives you door position monitoring without a surface contact. The switch is a single pole double throw type built inside the hinge, so it can signal whether the door is open or closed and drive an alarm, annunciator, or access control input. Nothing electrical shows once the hinge is mortised in, which is why it gets used where a surface-mounted contact would be picked at or defeated.
3) Where in the door does the electrified hinge go, and can I use it as the only hinge?
It replaces one hinge in the stack, not all of them. Install the CECSFBB168-54 in the center hinge position and hang the rest of the door on standard hinges of the same size and finish. Center placement keeps the wire run short and the flex at the leaf minimal. Power gets disconnected before you start, and the wire routing follows the manufacturer wiring diagram.
4) Will a 5 x 5 electrified hinge drop into my existing hinge prep?
Only if that prep is already 5 x 5 with square corners. The CECSFBB168-54 is a full mortise hinge with square corners in a 5 x 5 size, so it mortises into a square-cut 5 inch pocket. If your frame and door are prepped 4.5 x 4.5, or cut with radius corners, this leaf won't seat without rework. Electrified hinges in 4.5 x 4.5 include the Design Hardware ETW2-BB5 and the Detex EWH8.
5) What can I use instead of the BEST CECSFBB168-54 if I need more than four conductors through the hinge?
The CECSFBB168-54 carries a 4-wire concealed conductor with a concealed switch. If the opening needs more conductors for an electric lock plus monitoring plus a request-to-exit input, the Detex EWH8 five-knuckle electric hinge in 4.5 inch by 4.5 inch runs 8 wires, and the RCI 952 electrified hinge is a 6-conductor ball bearing hinge. Count every device on the door leaf before choosing: each latch retraction, monitoring contact, or handle switch consumes conductors.
6) Is the Design Hardware ETW2-BB5 a direct replacement for a BEST CECSFBB168-54?
They are not interchangeable on the same opening. The CECSFBB168-54 is a heavy duty commercial hinge and is sold in a 5 inch by 5 inch size with square corners. The Design Hardware ETW2-BB5 is a medium duty electrified ball bearing hinge in a 4.5 inch by 4.5 inch size, so the mortise cutout in the frame and door edge is a different width and height. Match the existing hinge prep dimensions first, then match duty level to the door weight.
7) I only need to move power to an electric lock, not monitor the door. What should I look at instead?
The CECSFBB168-54 pairs its conductors with a concealed switch so the hinge both feeds power and reports door position. If you only need a path for power across the gap, a straight power transfer hinge such as the SDC PTH Series is the simpler part, and the Securitron EH Double Duty electric hinge is another transfer-only option. Choose the concealed switch version only if your panel needs a door position input from the hinge itself rather than from a separate contact.
8) Will this BEST hinge hold up on a heavy commercial door in high traffic?
It's a heavy duty, commercial-rated hinge: steel, full mortise, five knuckle, with concealed bearings rather than exposed ball bearings. That construction is what you put under a heavy or high-cycle leaf. Lighter-duty electrified hinges exist for interior office doors, such as the Design Hardware ETW2-BB5 4.5 x 4.5 standard weight unit, which is listed as medium duty.
9) What comes in the box with this electrified hinge?
Packed one hinge per box with the concealed switch and concealed conductor already in it, plus screws and installation instructions. You supply everything on the building side: the balance of the hinges for the door, low-voltage cable back to the panel, and any power supply or monitoring input the switch reports to.
10) Should I use an electrified hinge or a separate power transfer for getting wire through a door?
An electrified hinge like the CECSFBB168-54 does both jobs at once, carrying conductors and giving you a built-in position switch in a single mortise, with nothing visible at the door edge. A dedicated power transfer such as the SDC PTH Series carries power across the gap as its whole function. Pick the hinge when you want the door status signal and the wire path in one prep; pick a transfer device when the hinges are already set and you only need conductors across.
11) What is a lighter-duty electrified hinge to use on an interior office door instead of the CECSFBB168-54?
The CECSFBB168-54 is built heavy duty for commercial openings. For a lighter interior leaf, the Design Hardware ETW2-BB5 is a medium duty electrified standard weight ball bearing hinge in 4.5 inch by 4.5 inch, and the RCI 952 is also a medium duty electrified ball bearing hinge. Both carry power through the hinge the same way; the difference is the leaf thickness and bearing rating behind it.
12) Which electrified hinge should I standardize on for a high-traffic opening with a published cycle rating?
If your specification calls for a stated cycle life, the SDC PTH Series power transfer hinges are rated to 800,000 cycles. The BEST CECSFBB168-54 is the choice when the requirement is written around heavy duty steel full mortise construction with concealed bearings and a built-in concealed switch for door monitoring, which the PTH does not provide.
13) What finish does the BEST CECSFBB168-54 come in, and will it match my other hinges?
One finish: 652 satin chrome over steel. That is the standard commercial hinge finish and it pairs with 626 satin chrome trim and locksets, so it blends on most existing openings where the rest of the hardware is brushed chrome. If your building standardized on brass or oil-rubbed finishes, this hinge won't match.
14) Does the Detex EWH8 match the satin chrome finish of the BEST CECSFBB168-54?
Both are offered in satin chrome: the CECSFBB168-54 is supplied in 652 satin chrome steel, and the Detex EWH8 electric hinge is listed with a satin chrome finish. Sizes differ, though, with the BEST at 5 inch by 5 inch and the Detex at 4.5 inch by 4.5 inch, so mixing them on adjacent doors will show a visible difference in leaf size even with the finishes aligned.
15) Do I need to order handing on electrified hinges the way I do on the BEST CECSFBB168-54?
The CECSFBB168-54 is ordered as left-handed or right-handed because the concealed switch and conductor exit has to face the correct side of the opening. Confirm the door hand before ordering rather than assuming a swing. Straight power transfer products such as the SDC PTH Series and the Securitron EH are sold as series parts, so verify their ordering requirements separately against your opening.
